RS21**

RS23**

Model:

SIDE-BY-SIDE REFRIGERATOR

SAMSUNG Home Appliance Service

For the latest parts information,

please access to our service web site

(http://www.e4buyer.com/refrigerator)

IMPORTANT SAFETY NOTICE

The service guide is for service men with adequate backgrounds of

electrical, electronic, and mechanical experience. Any attempt to repair

a major appliance may result in personal injury and property damage.

The manufacturer or dealer cannot be responsible for the interpretation

of this information.

SAMSUNG ELECTRONICS

Technical Service Guide

part in any form without written permission from the SAMSUNG ELECTRONICS

Company.

WARNING

Contents

1. SAFETY WARNINGS ·······································5

2. INSTRUCTION ···········································8

3. INSTALLATION ···········································9

4. NOMENCLATURE ········································10

5. SPECIFICATIONS·········································11

6. INTERIOR VIEWS AND DIMENSIONS ···························14

7. FREEZING CYCLE AND COOL AIR CIRCULATION ROUTE·············19

8. MECHANICAL DISASSEMBLY ································21

9. FUNCTIONS AND OPERATION ·······························29

10. CIRCUIT DESCRIPTION ···································43

11. DIAGNOSIS AND TROUBLESHOOTING·························52

●APPENDIX ⅠⅠ(REFERENCE FOR CIRCUIT DIAGNOSTICS) ··········64

●APPENDIX ⅡⅡ(CIRCUIT DIAGRAM) ···························67

12. ILLUSTRATED PARTS CATALOGUE ···························73

13. MACHINE ROOM ASSEMBLY SPECIFICATION ···················96

1. SAFETY WARNINGS

●

Pull the power plug out already for the change or repair of electric

parts.

→

Be careful the electric shock.

●

When exchanging the parts, use the correct parts.

→

Check the model name, rating voltage, rating current, running

temperature symbols.

●

When troubleshooting, connect firmly the types of harness.

→

Make not to be separated when some power is imposed.

●

Check the traces of water infiltration at the electric parts.

→

If there is a trace of water infiltration, exchange or tape the parts.

●

Check the assemble status of parts after troubleshooting.

→

It should be done indiscriminately as before the repair.

●

Check the use circumstance of refrigerator.

→

If the refrigerator is installed at the place that is damp or wet, or

status of installation is unstable, change the installation place.

●

Do earth in case of need.

→

Particularly, Be sure to earth when there is a risk of an electric

leakage by humidity or wetness.

●

Do not use multi plugs in a plug socket at the same time.

Check the power cord and socket is damaged, pressed, squeezed, or

fired.

→

If the plug or plug socket is damaged, repair or exchange that

immediately.

●

Do not store the foods unstable or bottles in the freezing room.

●

Do not repair the refrigerator by user himself.

●

Do not store another materials except the foods.

→

Drugs or scientific materials : difficult to keep a precise temperature.

→

The inflammables(alcohol, benzene, ether, LP gas, butane gas etc.):

have a risk of explosion.

1. SAFETY WARNINGS

Read all instructions before repairing the product and keep to the instructions

in order to prevent danger or property damage.

CAUTION/WARNING SYMBOLS DISPLAYED

SYMBOLS

Indicates that a

danger of death

or serious injury

exists.

Indicates that a risk

of personal injury

or material damage

exists.

means “Prohibition”.

means “Do not disassemble”.

means “No contact”.

means ”The things to

be followed”.

means “Earth to prevent Electric

shock”.

means “Power cord should be

unplugged from the consent”

Pull the power plug out to

exchange the interior lamp

of the refrigerator.

●

It may cause electric shock.

Warning

Warning & Caution

Caution

Earth

Unplug

Use the rated components

on the replacement.

●

Check the correct model, rated

voltage, rated current, operating

temperature and so on.

On repair, make sure that the

wires such as harness are

bundled tightly.

●

Bundle tightly wires in order not to be

detached by the external force and then not

to be wetted.

Check if there is any trace

indicating the permeation

of water.

●

If there is that kind of trace, change

the related components or do the

necessary treatment

such as taping

using the

insulating tape.

After repair, check the

assembled state of components.

●

It must be in the same assembled state

when compared with the state before

disassembly.

On repair, remove completely dust

or other things of housing parts,

harness parts, and check parts.

●

Cleaning may prevent the possible fire by

tracking or short.

Rated

components

1. SAFETY WARNINGS

❈

Please ler users know following warnings & cautions in detail.

Do not allow users to put bottles or

kinds of glass in the freezer.

●

Freezing of the contents may inflict a wound.

Do not allow users to store narrow

and lengthy bottles or foods in a

small multi-purpose room.

●

It may hurt you when refrigerator door is

opened and closed resulting in falling stuff

down.

Do not allow users to store

pharmaceutical products, scientific

materials, etc., in the refrigerator.

●

The products which temperature control

should not be stored in the refrigerator.

Do not allow users to store

articles on the product.

●

Opening or closing the door may cause

things to fall down, with may inflict a

wound.

Prohibition Prohibition Prohibition

Prohibition

Warning & Caution

Do not allow users to

disassemble, repair or alter.

●

It may cause fire or abnormal

operation which leads to injury.

Do not

disassemble

Do not allow users to insert the

power plugs for many products

at the same time.

●

May cause abnormal generation of

heat or fire.

Prohibition

Do not allow users to bend the

power cord with excessive force

or do not have the power cord

pressed by heavy article.

●

May cause fire.

Do not allow users to install the

refrigerator in the wet place or

the place which water splashes.

●

Deterioration of insulation of electric

parts may cause electric shock or fire.

Make sure of the earth.

●

If earthing is not done, it will cause

breakdown and electric shock.

Earth

2. INSTRUCTION

●●SAMSUNG side by side refrigerator has the following characteristics.

Twin Cooling System

• The refrigerator and the freezer have two

evapora

tors. Given this independent system, the freezer

and the refrigerator are cooled individually as

required and are, therefore, more efficient. Food

odor from the refrigerator does not affect food in

the freezer due to separate of air flow circulation.

Multi-Flow System

• Cool air circulates through multiple vents on

every

shelf level. This provides even distribution of

cooling inside cabinets to keep your food fresh

longer.

Door Alarm

• A beeper reminds you if the door is left open.

High humidity for fresher food

• You can keep food, fruit and vegetables fresh for

longer because your refrigerator supplies highly

humidified cold air. This can be up to four or five

times more effective than a normal refrigerator.

Energy-saving fridge/freezer

• Power consumption is kept to a minimum by

distributing cool air separately to the refrigerator

and freezer.

Faster cooling times

• The power freeze function allow you to freeze food

more quickly.

Abundant supply of ice and cold water

• The ice and water dispenser provides ice and cold

water at any time.

Beverage Station (optional)

• You do not have to open the main door to access

frequently used food in the extra

refrigerating compartment. This saves time

and money.

Deodorizer (optional)

• Reusable deodorizer keeps the refrigerator air

fresh and odor free.

CoolSelect ZoneTMDrawer (optional)

• User can select Quick Cool, Thaw and Select

buttons for quickly chill, thaw and cools items.

Select Soft Freeze, Cool or Chill to control the

temperature of drawer.

NOTE

This operation instruction covers various models.

The characteristics of your appliance may differ slightly from those described in this

manual.

3. INSTALLATION

1) To protect refrigerator in movement

Use padded hand truck as shown. If entrance width is

less than 30〃

, remove doors prior to installation and

reattach doors according to procedure below.

2) Remove all protective tape and pad in refrigerators.

Please adjust the clearance between the doors.

3) Set the temperature control to the temperature and

wait for an hour.

The refrigerator should get slightly chilled and the motor

runs smoothly.

4) Once the refrigerator temperature is sufficiently cool

You can store food in the refrigerator. After starting the

refrigerator, it takes a few hours to reach the appropriate

temperature.

●●Disassemble the refrigerator

1) With the door closed, disassemble screw(①) by

using (+) screw driver and then disassemble the

upper hinge cover(②).

2) Disassemble bolts (③) and screws (④) to the

counter-clockwise by using a tool, and take off the

upper hinge (⑤) along the arrow (⑥). Take care

when you disassemble the door to ensure that it does

not fall on you.

3) Disassemble the door from the lower hinge (⑦) by

lifting the door (⑧).

4) Disassemble the lower hinge (⑨) from the bracket

lower hinge (⑩) by lifting the lower hinge (⑨) in the

direction of the arrow.

●●Assemble the refrigerator

1) Insert the lower hinge (①) in the bracket lower

hinge (②).

2) Assemble the door (④) in the lower hinge (③).

3) Insert the upper hinge shaft (⑤) into the hole (⑥). After

leveling between the upper hinge hole (⑦) and the

hole of the refrigerator (⑧), assemble bolts (⑨)

and screws (⑩) to the clockwise by using a tool.

4) Put the front part of the upper hinge cover (⑪) on the

front part of the upper hinge (⑫) and assemble,

starting with the front part of the upper hinge

cover. Assemble the screw to the clock wise by

using a tool.

3) 4)

2) 1) 2)

R S 21 SWF C

BRAND : R-SAMSUNG REFRIGERATOR

VOLUME CAPACITY: 21,23 (cu.ft)
