Installation Guide

ML-85G/85G plus

P/N. JC68-60945A

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ2

Contents

Installing the Toner Cartridge ..... .... .... .... .... . 1

Supplying Paper ..... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .2

Connecting Computer and Power Cables. ... . ... . ... .... ... . ..3

Installing Printer Driver and Printing . ... ... . ... ... . ... ... . ... ... 4

Before using

Driver

Setup Printing (Windows®95) . ............ 5

Installing Driver .............................................. 5

Setting as Default Printer ................................................7

Printing .........................................................................8

Uninstalling Drivers ........................................................9

Printing (Windows 3.x)............ 10

Installing Driver ............................................ 10

Setting as Default Printer .............................................. 12

Printing ........................................................................ 13

Uninstalling Drivers ...................................................... 14

Printing to a Network Printer ... 15

Setting up a Host PC .................................... 15

Setting up WPS Driver onto the Client PC ...................... 17

Client PC Sharing Setup ............................................... 18

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ4

Installing the Toner Cartridge

- Remove contents and packing material.

1 2 3

Place the cartridge on a

stable surface, then pull out

the tape attached to top of

cartridge, as shown.

•Place a protective sheet of paper

underneath the cartridge, in case of

toner leakage.

•Be careful not to tear the tape while

removing.

•Be careful not to spill toner

material when removing the

tape.

•Follow the above steps to install the

toner cartridge.

•Rock the toner cartridge to distribute

toner material evenly, as shown

below:

•Close the cover by pressing down

until it clicks.

Open the Top Cover by

pressing the release button. Insert the cartridge and

close the cover.

Supplying the Paper

1 2 3

Remove the sealing tapes

and slide out the Paper

Cassette.

•Refer to page 4-1 in Operator’s Guide to

set the paper size.

•Insert the corner of the paper stack

under metal tab (A).

Place blank paper into the

Cassette. Push the Cassette back

into place.

Note

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ6

From this point forward, you will be guided through driver

installation and printing documents.

The setup program is compatible with Windows 3.x and

Windows 95.

This Installation Guide describes only setup and printing

examples. To learn more details about the product, read

the Operator’s Guide supplied with the printer.

System Requirement

(Note that the ML-85G/85G plus printer does not support

switchbox connections.)

- IBM or compatible with 386 or higher processor

- Free disk space of at least 4Mb

- More than 8Mb RAM memory (16Mb recommended,

and note print speed will increase as system memory is

increased.)

Before Installation

Remove all other printer drivers before running Setup

program, or change the printer ports to ‘FILE’.

If not, printing operation may fail.

Connecting Computer

and Power Cables

- Be sure to remove power from both computer and printer.

Connect printer to computer.

•A printer cable is not included with the printer, and must be supplied by the

user.

•For best performance, use a good quality shielded cable with

IEEE 1284-compatible pin configuration (Centronics).

At temperatures below 50˚F (10˚C), apply

printer power at least an hour before

using.

•This will help maintain print quality.

• In winter time, it is recommended to keep

printer on (Power Save mode).

Installing Printer Driver and

Printing

Plug in the power cord.

• Note that this printer does not

have a power switch. It will

automatically shut off after a

period of non-use.

Note

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ8

Printing (Windows 95)

Installing driver

1 2

When Windows 95 senses the

printer and alerts you with the

message below, click OK.

Turn on printer and computer.

• If no message appears: Select Run under Start

menu and type a:\setup (or b:\setup) on the

command line, then press Enter.

Insert diskette #1 into the floppy

drive and click OK.

5 6

Setup resumes the

installation. When installation is

complete, click Finish.

3 4

Type your name and company

•The information is the same as entered when

Windows 95 was installed. Change and/or

click Next if correct.

If the below message appears

during installation, insert next

diskette and click OK.

• Setup exits and Windows 95 restarts.

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ10

7 8

Printing (Windows 95)

Setting as default printer Printing (Windows 95)

Printing

1 2

Select Printers under Settings

in Start menu. Double-click the

ML-85G/85G plus icon.

Select Set As Default. A

check mark will confirm the

selection next time you open

the Printer menu.

1 2

Open the file you want to

print.

The following sample instructions show how to print

using Microsoft®Word.

Select Print in File menu.

Enter the number of copies

and pages to print, and

click OK.If printing fails, there may be a

problem with the

PC CMOS setup.

To solve this problem:

- Uninstall the previous printer

driver (see next page), then

re-install it. If set to output

only, printing may fail.

- Reboot your PC, run CMOS

setup, and set the LPT mode to

bi-directional.

Set as default printer.

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ12

Printing (Windows 3.x)

Installing driver

Windows 95

Uninstalling driver

1 2

Select ML-85G&85G plus

uninstaller.Click Yes.

Uninstaller removes printer

driver program, and restarts

Windows 95.

1 2

Insert diskette #1 into the

drive. Select Run from the Program

Manager File menu.

Type your name and company

name, and click Next.

•The information is the same as entered when

Windows was installed. Chanhe and/or click

Next if correct.

Type a:\setup (or b:\setup) on

the command line, then

click OK.

Turn on printer and computer.

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ14

11 12

Printing (Windows 3.x)

Installing driver Printing (Windows 3.x)

Setting as default printer

5 6

When the following message

appears, insert the next

diskette and click OK.

• Setup exits, and Windows restarts.

Setup resumes the

installation.

When installation is

complete, click Finish.

1 2

Double-click the Printers icon

in Control Panel. Select ML-85G/85G plus, click

Set As Default Printer, then

Close.

Set as default

printer.

01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ16

13 14

Printing (Windows 3.x)

Printing Windows 3.x

Uninstalling driver

1 2

Open a file to print.

The following sample instructions show how to

print using the Microsoft®Word application.

Select Print from the

File menu.

If printing fails, reboot your PC,

and run CMOS setup to set the

LPT mode to bi-directional. If set

to output only, printing may fail.

Uninstall the previous printer driver

(see next page), then re-install it.

Enter the number of

copies and pages to print,

then click OK.

1 2

Open Program Manager and

double-click the ML-85G/85G

plus uninstaller.

Click Yes.

Uninstaller removes printer

driver program and restarts

Windows.

02ML-85G/85G 99.2.18 12:6 PM ∆‰¿Ã¡ˆ2

Printing on a network printer

Setting up a Host PC printer

Install the print driver before

setting up sharing.

See pages 5 through 14

for instructions on

installing drivers.

Click Start menu, select Control

Panel, and double-click the

Network icon.

Click the Sharing tab, check

Shared As, fill in the Shared

Name field, and click OK.

Select Properties in Printer

menu.

2 3

Click File and Print Sharing,

check box(es), then click OK.Click Start menu and select

Printers in Settings, then double-

click the ML-85G/85G plus.

Finish
