Samsung CLP 500 Manuel utilisateur

COLOR LASER PRINTER

Setup Guide

ETUP

UIDE

ONTENTS

Step 1.

Unpacking ............................................. 3

Step 2.

Understanding Your Printer ................... 5

Step 3.

Installing the Imaging Unit Transfer Belt

and Toner Cartridges ............................. 7

Step 4.

Loading Paper ..................................... 16

Step 5.

Connecting a Printer Cable .................. 19

Using a Parallel Cable .................................19

Using a USB Cable .....................................20

For Networking Printing ..............................21

Step 6.

Turning the Printer On ........................ 22

Step 7.

Printing a Demo Page .......................... 23

Step 8.

Changing the Display Language .......... 23

Step 9.

Installing the Printer Software ............ 24

Installing Printer So tware in Windows ..........24

Reinstalling Printer so tware ........................26

Removing Printer so tware ..........................26

Changing the Display Language ...................26

Step 10.

Viewing the User’s Guide ................... 27

In Windows ..............................................27

In Macintosh .............................................27

In Linux ...................................................28

ETUP

UIDE

English

Step 1.

Unpacking

Remove the printer and all o the accessories rom the

packing carton. Make sure that the printer has been packed

with the ollowing items:

OTES

• I any items are missing or damaged, noti y your dealer

immediately.

• Components may differ from one country to another.

• The CD-ROM contains the printer driver, the User’s Guide, and

the Adobe Acrobat Reader program.

• The power cord may be di erent depending on your country.

AUTION

This printer weighs 35kg including developer cartridge

and cassette. Use sa e li ting and handling techniques. I you need

to move the printer it must be moved by two people. Use the

li ting handles located as shown in the diagram (see page 5). Back

injury could be caused i a single person attempts to li t the

printer.

Toner Cartridges Power Cord Trans er Belt

Imaging Unit CD-ROM Setup Guide

SyncThru CD-ROM

(CLP-500N only)

SyncThru Quick Guide

(CLP-500N only)

ETUP

UIDE

Care ully remove all o the packing tapes rom the printer.

Pull the paper tray out o the printer and remove the

packing tapes rom the tray.

Select a location or the printer:

•Leave enough room to open the printer trays, covers, and

allow or proper ventilation.

•Provide the proper environment:

– A irm, level sur ace

– Away rom direct air low o air conditioners, heaters, or

ventilators

– Free o temperature, sunlight, or humidity extremes or

luctuations

– Clean, dry, and ree o dust

AUTION

You must place your printer in the level sur ace. I you

do not, the print quality problems can occur.

ETUP

UIDE

English

Step 2.

Understanding Your Printer

These are the main components o your printer:

Output Support

Control Panel

(re er to Chapter

5 in the User’s

Guide which is

on the CD-

ROM.)

Paper Output Tray

Top Cover

(Open to install the imaging unit,

and trans er belt.)

Front Cover

(Open to replace

the waste toner

container.)

Left Cover

(To install the toner cartridges

press the top cover release

button and open ully.)

Tray 1

(250-sheet paper eeder)

Top Cover

Release Button

Optional Tray 2

(500-sheet paper eeder)

Handle

(Li ting handles are

located at the lower

edge o both sides

o the printer.)

ETUP

UIDE

Optional Tray 2 Jam Cover

(Open to remove jams in the optional tray 2.)

Muti-purpose Tray

(Open to load special print materials.)

Right Cover

(Open to remove paper jams.)

Power Switch

USB Port

Power Receptacle

Control Board

Cover

(Open to install optional

accessories.)

Wireless Network

Antenna

Network Port

Parallel Port

***

* This wireless network port is not supplied with the printer. It is an option that must be purchased and

installed separately.

** The network port is fitted as standard on the CLP-500 . CLP-500 users can purchase and install

separately an optional etwork Card. For details, see the User's Guide of the printer in the CD-ROM.

*** The parallel port may not be available depending on your country.

Handle

(Use it to li t the printer.)

ETUP

UIDE

English

Step 3.

Installing the Imaging Unit Transfer

Belt and Toner Cartridges

Using the handle, completely open the le t cover until it is at

right angles to the main rame.

AUTION

I the le t cover is not completely open, the top cover

release button does not press.

Press the top cover release button to unlatch the top cover

and open it all the way.

Top cover release

button

ETUP

UIDE

Take the imaging unit out o the package using the handle.

Remove the paper covering the imaging unit by removing

the tape under the handle o the imaging unit.

CAUTIONS

• Do not use sharp objects, such as a kni e or scissors, to open the

imaging unit package and tape on the protective paper liner. You

could damage the sur ace o the imaging unit.

• To prevent damage, do not expose the imaging unit to light or

more than a ew minutes. Cover it with black paper, i necessary.

• Do not touch the sur ace o the green roller on the imaging unit

or print quality problems can occur.

Locate the imaging unit slots inside the printer, one on each

side.

ETUP

UIDE

English

Hold the handle on the imaging unit with the green roller

acing you. Align the imaging unit with the slots in your

printer so that the colors on both sides o the imaging unit

slide into the corresponding colors o the slots.

CAUTION

Insert the imaging unit care ully so as not to scratch

and damage the sur ace o the green roller.

Slide the imaging unit down into the printer until it cannot

be pushed in any urther and old the handle down.

CAUTION

To prevent damage, do not expose the imaging unit

to light or more than a ew minutes. Close the top and le t

cover should the setup need to be halted or any reason.

ETUP

UIDE

Take the trans er belt out o the package.

Remove the paper covering the trans er belt by removing

the tape.

CAUTION

Don’t use sharp objects, such as a kni e or scissors, to

open the trans er belt package. You could damage the sur ace o

the trans er belt.

Pinch the trans er belt tention levers on both sides o the

trans er belt. Then, pull them out, as shown below.

Locate the trans er belt slots inside the printer, one on each

side.
