Samsung SRP-270 Dot Matrix Receipt Printer

Integrator’s Manual

Contents

Driver Installation Information 2

Overview .............................................................................................................................2

Windows 98 SRP-270 Driver Installation.............................................................................3

Windows 98 Generic / Text Driver Settings .........................................................................4

Windows 2000 Generic / Text Driver Settings......................................................................5

Windows XP Generic / Text Driver Settings ........................................................................6

Hexadecimal Dumping 7

Overview .............................................................................................................................7

Hexadecimal Dump Sample Printout....................................................................................9

Troubleshooting................................................................................................................. 10

Cash Drawer 11

Generate Pulse Command.................................................................................................. 11

Connection Information..................................................................................................... 12

Special Application Firmware 13

Overview ........................................................................................................................... 13

CRS, Inc.

2909 Anthony Lane

Minneapolis, MN 55418

(612) 781-3474

All specifications are subject to change without notice 2002, Cash Register Sales, Inc.

2•Driver Installation Information Samsung SRP-270 Setup & Service Information

Driver Installation Information

Overview

If your POS software requires a generic printer driver, you must make the appropriate driver

settings for auto cut and cash drawer opening.

If you are using one of the SRP-270 drivers the generic driver settings shown here do not

apply. The appropriate SRP-270 drivers operate the cutter and cash drawer automatically.

Samsung SRP-270 Setup & Service Information Driver Installation Information •3

Windows 98 SRP-270 Driver Installation

You can download the compressed SRP-270 driver, 270 9xDriver.zip, from the dealer area of

the CRS site, www.crs-usa.com. Unzip (extract) the files srp270.drv and Samsung.inf.

1. Select Start, then Settings, and then Printers.

2. From the printers dialog, right click the Add Printer icon.

3. From the Add Printer wizard window, click Next.

4. Choose Local Printer, click Next.

5. Click the Have Disk command button. From the Install From Disk dialog box, click

the Browse button to locate the driver file SRP270.drv. Click OK. The wizard

displays the list of drivers for several Samsung printers.

6. Select either SRP270 No Cut (use when paper cutter is not used) or SRP Partial Cut

(use when paper cutter is used) click Next.

7. Select the port to which the printer will be connected and click Next.

8. Enter a printer name and select whether you want your windows based program to use

this printer as the default printer. Click Next.

9. Select whether you wish to print a test page and click Finish. The printer driver

installation is complete.

4•Driver Installation Information Samsung SRP-270 Setup & Service Information

Windows 98 Generic / Text Driver Settings

1. Select Start, then Settings, and then Printers.

2. From the printers dialog, right click the Generic / Text Only driver and choose

Properties.

3. From the Generic / Text Only dialog box, click the Device Options tab:

4. For the cash drawer command, in the Begin Print Job field:

Type: ESC (<ESC> will display)

Type: p (lower case)

Type: 0 (drawer 1) or 1 (drawer 2)

Type: 25 (on time)

Type: 125 (off time)

5. For the auto cut command, in the End print Job field:

Press ALT and type: 0010 (line feed) :

Press ALT and type: 0010 (line feed)

Press ALT and type: 0029 (GS) :

Press ALT and type: 0086 (V) :

Press ALT and type: 0001 (ASCII 01)

6. Click OK to save the new settings.

Cash Drawer

Command

Auto Cut

Command

NOTE:

To enter these

commands, it may

be necessary to

activate the Num

Lock and use the

10-key pad on your

keyboard.

Samsung SRP-270 Setup & Service Information Driver Installation Information •5

Windows 2000 Generic / Text Driver Settings

1. Click the Start button, and then choose Settings, and then choose Printers.

2. From the printers dialog, right click the Generic / Text Only driver and choose

Properties.

3. From the Generic / Text Only dialog box, click the Printer Commands tab:

4. For the cash drawer command, in the Begin Print Job field:

Type: “<1B>p<00>”

5. For the auto cut command, in the End print Job field:

Type: “<1B>m”

6. Click OK to save the new settings.

Cash Drawer

Command

Auto Cut

Command

NOTE:

To enter these

commands, it may

be necessary to

activate the Num

Lock and use the

10-key pad on your

keyboard.

6•Driver Installation Information Samsung SRP-270 Setup & Service Information

Windows XP Generic / Text Driver Settings

1. Click the Start button, and then choose Printers and Faxes.

2. From the printers dialog, right click the Generic / Text Only driver and choose

Properties.

3. From the Generic / Text Only dialog box, click the Printer Commands tab:

4. For the cash drawer command, in the Begin Print Job field:

Type: “<1B>p<00>”

5. For the auto cut command, in the End print Job field:

Type: “<1B>m”

6. Click OK to save the new settings.

Cash Drawer

Command

Auto Cut

Command

NOTE:

To enter these

commands, it may

be necessary to

activate the Num

Lock and use the

10-key pad on your

keyboard.

Samsung SRP-270 Setup & Service Information Hexadecimal Dumping •7

Hexadecimal Dumping

Overview

This feature allows experienced users to see exactly what data is coming to the printer. This

can be useful in finding software problems. When you turn on the hexadecimal dump function,

the printer prints all commands and data in hexadecimal format along with a guide section to

help you find specific commands.

SRP-270 Hexadecimal Dump

To use the hexadecimal dump function, follow these steps:

1. Make sure that the printer is off.

2. Open the access panel on the bottom of the printer to expose the dip switches. Set

switch 2-2 to the ON position.

3. Turn on the printer; the printer is in the hexadecimal dump mode.

4. Run any software program that sends data to the printer. The printer will print all the

codes it receives in a two-column format. The first column contains the hexadecimal

codes and the second column gives the ASCII characters that correspond to the codes.

5. When the printing finishes, turn off the printer and return switch 2-2 to the OFF

position.

6. Turn on the printer. Hexadecimal mode is OFF.

8•Hexadecimal Dumping Samsung SRP-270 Setup & Service Information

Epson TM-300/U200 Hexadecimal Dump

It may be useful to compare hexadecimal dumps with a known printer, such as the Epson TM-

300 or U200. To print a hexadecimal dump on the TM-300/U200:

1. Make sure the printer is off and set dip switch 1-2 to ON.

2. Hold down the PAPER FEED button while you turn on the printer, and then release

the PAPER FEED button quickly.

Note: Releasing and pressing the PAPER FEED button should be performed before

the printer finishes initializing, otherwise the printer begins the self test.

3. When the printer enters the hex dump mode, it prints “Hexadecimal Dump”.

4. Run any program the sends data to the printer –the hexadecimal dump will print.

5. When the printing finishes, turn off the printer or reset it to turn off the hex dump

mode.

6. If you changed the dip switch 1-2, return it to the OFF position.

Samsung SRP-270 Setup & Service Information Hexadecimal Dumping •9

Hexadecimal Dump Sample Printout

The sample “No Sale” transaction below is also shown in the two-column hexadecimal dump

format on the right.

The first column contains the hexadecimal codes.

The second column prints the ASCII characters that

correspond to the codes.

•A period is printed for each code that has no

ASCII equivalent.

•Control codes are printed in bold for emphasis.

•During the hex dump, all commands except

DLE EOT and DLE ENG are disabled.

10 •Hexadecimal Dumping Samsung SRP-270 Setup & Service Information

SRP-270 Receipt & Hex Dump

TM-300 Receipt & Hex Dump

Troubleshooting

If you are connecting an SRP-270 to a specific software application for the first time, you may

encounter printing differences from a printer model you are currently supporting. You can

isolate the commands causing the print difference by comparing hex dumps from a working

printer the printer with a problem print format. For example, receipts and the corresponding

hex dumps from two printers, the Samsung SRP-270 and the Epson TM-300 are shown below:
