Samsung YP-Z5F Manuel utilisateur

For Your Safety

Read this manual carefully to ensure proper use of the product and

to avoid any danger or physical damage.

WARNING

Product Use

Improper use can result in explosion,

fire or electric shock. To avoid your hearing damage

Do not disassemble, repair

or modify this product on

your own.

Do not get the product wet

or drop it in water.

If the product gets wet,

do not switch it on.

Contact a Service Center.

Do not place the product in

damp, dusty or sooty areas,

as it could result in fire or

electric shock.

Using the earphone or headphone for an extended

time can cause a serious damage to your hearing.

If you are exposed to a sound in higher than 85db for an

extended time, you will be adversely affected on your hearing.

The higher the sound is, the more seriously damaged your

hearing is (an ordinary conversation is made in 50 to 60 db

and the noise level on the road is approximately 80 db).

You are strongly advised to set the volume level to medium

(the medium level is usually less than 2/3 of the maximum).

If you feel a ringing in the ear(s), lower the volume

or stop using the earphone or headphone.

To avoid a risk of traffic accident

Do not use the earphone while you are driving a

bicycle, automobile or motorcycle.

Otherwise it can cause a serious accident and, furthermore, it

is prohibited by the law in some areas.

Using the earphone on the way, in particular, on the crosswalk

can lead to a serious accident.

For your safety, make sure the earphone

cable should not get in the way of your arm

or other surrounding objects while you are

taking exercise or a walk.

Do not leave the product in

areas above 35°C(95°F)

(such as a sauna or inside

a parked car).

During the summer the

temperature inside a car may

rise up to 80°C(176°F).

Failing to heed the product instructions may cause serious injury.

Chapter 1. Preparation

CAUTION

Product Use

Take care to avoid product malfunc-

tion and physical damage.

Management of Important Data

Avoid malfunction

When wearing the product

around your neck, take

care not to exert excessive

force on the neck string.

Be sure to backup

important data.

Please be aware that we claim

no responsibility for damage

from data loss due to break-

down, repair or other causes.

Failure to follow all instructions lead to physical injuries or damage to the product.

Do not cause excessive

impact on the product by

dropping it. Do not place

heavy objects on top of the

product.

Prevent any foreign

particles or dust from

entering into the product.

Always use the accessories

provided by or approved by

Samsung.

Do not spray water on the

product. Never clean the

product with chemical

substances such as

benzene or thinner, as it may

cause fire, electric shock or

deteriorate the surface.

Do not place the product

near magnetic objects, as it

may cause a malfunction.

Product Features........................................7

Checking the Product and Accessories

....8

Components ................................................8

Screen Display Information .......................10

Button Functions........................................11

Charging the battery................................13

Basic Use ...................................................14

Contents

Chapter 1. Preparation

Chapter 2. Loading Your Desired File

Loading Your Desired File......................18

Loading Your Desired File.....................18

Installing Media Studio..........................19

Connecting to your PC..........................21

Adding Files/Folders in Media Studio...22

Adding Files/Folders in

Media Studio with Autoscan..................24

Transferring Files with Media Studio ....26

Using as a Removable Disk ...................28

Disconnecting from your PC..................29

Chapter 3. Multmedio funtion

Listening to Music....................................31

Listening to Music......................................31

To Play a Playlist.......................................34

Shuffle Play (Random Repeat)..................35

Checking the Music Information................38

Picture Viewing.........................................39

Picture Viewing..........................................39

Picture Enlarging/Slideshow Viewing

...........40

Listening to FM Radio .............................41

Listening to FM Radio ...............................41

Setting a Frequency ..................................43

Setting FM Radio.......................................46

Recording...................................................48

Voice Recording ........................................48

For Your Safety ..........................................2

Contents .......................................................4

Chapter 4. Setup

Setup ...........................................................51

Audio Setup ..............................................51

Display Setup ............................................52

Slideshow Setup .......................................53

Repeat Setup.............................................54

Timer Setup...............................................55

Language Setup........................................56

Reset .........................................................57

Checking the System Infomation...............58

Chapter 5. Troubleshooting

System Reset.............................................60

Troubleshooting........................................61

Chapter 6. Appendix

Menu Tree ..................................................65

Manual USB Driver Installation..............66

Product Specifications............................69

Chapter 1. Preparation

Product Features........................................7

Checking the Product and Accessories

....8

Components ................................................8

Screen Display Information .......................10

Button Functions........................................11

Charging the battery................................13

Basic Use ...................................................14

Chapter 1. Preparation

Product Features

Freedom of my favorite

selection with your player! Longer Play Time and Shorter

Downloading!

■

You can easily search for music files by the

artist, album or genre and make you own

selection of favorite songs in Playlist.

■

A fully charged battery can operate the

player in a maximum of 39 hours.

■

The player supports USB 2.0 capability,

much faster than USB 1.1, to enable faster

communication with the PC.

Supporting Various File

Formats! 3D Surround Sound!

High-Definition Quality!

■

Supports various file formats including

MP3, WMA and Ogg.

■

You can enjoy photo files in different

formats on the display by converting them

into JPG.

■

The player has built-in DNSe (Digital

Natural Sound engine), Samsung’s unique

sound technology for richer sound.

Touchpad Mechanism! Ergonomic Design!

■

Put your finger on the touchpad and move

or press it slightly to select a file or function

that you want to use.

■

Experience the good sense of grip and

easy operation.

Components

Checking the Product and Accessories

Front, Right Side and Top

Earphone Connection Port

Neck String Hole

Lock Switch

Screen Display

Volume Control Button

Back Button

Move Track/Quick Search Button

Outer Ring

Touch Pad/Select Button

Power & Play/Pause Button

Chapter 1. Preparation

Checking the Product and Accessories

Bottom

Checking the Accessories

The following diagrams are a guide and may differ slightly from the actual product appearance.

Power/USB Connection Port

Reset Hole

Player Earphones USB Cable

Installation CD

■

Design of accessories is subject to change for the purpose of improvement, without notice.

Screen Display Information

Checking the Product and Accessories

NOTE

■ The screen pictures are for illustration purposes only. The actual screen may differ.

0:49 2/2 1:36

MP3 DNSe STR REP

Rising Sun

Samsung MP3

Samsung

2:10 AM

1Current Time Display

3Album Display

2Album Title Display

4Sound Mode Display

5File Type Display

(MP3, WMA etc)

6Play Status Bar

7Play Time Display

8Play/Pause Display

10 Battery Display

9Music Title Display

11 Street Mode Display

12 Repeat Play Display

13 Total Play Time Display

14 Current Music Number/

Total Number Display
