MP3 Player

Model Name : YP-U5

Model Code : YP-U5JQR/XAA

MP3 Player

Refer to the service manual in the GSPN (see the rear cover) for the more information.

CONTENTS

1. Precaution

2. Product Specification

3. Disassembly & Reassembly

4. Troubleshooting

5. Exploded View & Part List

6. PCB Diagram

7. Schematic Diagram

YP-U5

This Service Manual is a property of Samsung Electronics

Co.,Ltd. Any unauthorized use of Manual can be punished

under applicable International and/or domestic law.

GSPN (Global Service Partner Network)

Area Web Site

North America service.samsungportal.com

Latin America latin.samsungportal.com

CIS cis.samsungportal.com

Europe europe.samsungportal.com

China china.samsungportal.com

Asia asia.samsungportal.com

Mideast & Africa mea.samsungportal.com

Printed in Korea

Contents

1. Precaution

1-1 Safety Precautions...........................................................................................1-1

1-2 Static Electricity Precautions............................................................................1-2

2. Product Specification

2-1 Product Feature ...............................................................................................2-1

2-2 Specifications...................................................................................................2-2

2-3 Specifications Analysis.....................................................................................2-3

2-4 Accessories......................................................................................................2-5

3. Disassembly & Reassembly

3-1 Overall Disassembly & Reassembly ................................................................3-1

4. Troubleshooting

4-1 Checkpoints by Error Mode..............................................................................4-2

4-2 Upgrade Methods.............................................................................................4-18

5. Exploded View & Part List

5-1 Exploded View .................................................................................................5-2

5-2 Electrical Part List ............................................................................................5-4

6. PCB Diagram

6-1 MAIN PCB Top .................................................................................................6-2

6-2 MAIN PCB Bottom ...........................................................................................6-4

7. Schematic Diagram

7-1 Overall Block Diagram .....................................................................................7-2

7-2 MAIN ................................................................................................................7-3

Samsung Electronics 1-1

Precaution

1. Precaution

1-1 Safety Precautions

1. To remove dust from cabinet, use a dry cloth without using liquid and aerosol cleaner.

2. You should not use attachments not recommended by the company. Otherwise, it may cause critical damage.

3. You should not use this product near water such as bathtub, swimming pool or lake etc.

4. Power supply: A type of battery as displayed on the label should be only used.

5. You should not put any object or liquid into product. Otherwise, it may cause failure or mal-operation.

6. If replacement material is required, service engineer should use materials with the same standard.

The use of non-standardized materials may cause failure of product.

1-2 Samsung Electronics

Precaution

1-2 Static Electricity Precautions

Some semi-conductor parts may be easily damaged due to static electricity.

These elements are generally called as static electricity sense device (ESD). Typically examples of EST include

IC, some transistor and chip element for semi-conductor with electrical field effect.

The following methods should be used to reduce damage of elements occurred due to static electricity:

1. Contact and emit all the grounding objects with static electricity from your body before handling with elements

for semi-conductor or devices with elements for semi-conductor. You should purchase and use static electricity

arm rings or commercially available. You should remove it due to potential shock before supplying power to the

device under test.

2. You should place appliance on the conductive surface like aluminum film to prevent that static electricity is

accumulated or the device is disclosed outside after removing electrical appliance with the ESD device.

3. You should use only soldering iron that is ground when soldering the ESD device.

4. Minimize physical operation when handling with the ESD device for replacement without packing (Otherwise,

namely friction between cloth fibers or lifting of the foot from the carpet floor may cause static electricity enough

to damage the ESD device).

Samsung Electronics 2-1

Product Specification

2. Product Specification

2-1 Product Feature

Fitness Mode

- A suitable mode for walking, jogging and other exercise.

(provides information such as timer, AUI and estimated burned calories)

PopCon (Pop art + icon: User selectable character)

- Not just a simple device, but recognized as one’s personal possession like an avatar.

→ Personalization

Slim Design

- Aimed at creating an entirely slim body, and actualizing the ‘clip concept’.

- Device thickness: 11.8 mm

2-2 Samsung Electronics

Product Specification

2-2 Specifications

Basic Specification

Rating DC 5.0V / 500mA

Built-in Battery Power 160mAh / DC 3.7V

File Compatibility

MPEG1 Layer3 (8kbps ~ 320kbps, 32kHz ~ 48kHz),

MPEG2 Layer3 (32kbps ~ 160kbps, 16kHz ~ 24kHz),

MPEG2.5 Layer3 (32kbps ~ 160kbps, 8kHz ~ 12kHz),

WMA(48kbps ~ 320kbps, 8kHz ~ 48kHz),

ASF(Audio) (8kbps ~ 192kbps, 8 ~ 48kHz)

Supported Number of

Folders/Files File: Max. 3000 (Including folder)

Earphone Output 18mW/Ch. (based on 16Ω)

Output Frequency Range 40Hz ~ 20kHz

Signal to Noise Ratio 88dB with 20kHz LPF (based on 1kHz 0dB)

Play Time Music: Max. 20 hours (MP3 128kbps, Volume: 15, Normal Sound Mode ,

LCD Off)

Temperature Range for

Operation 23 ~ 95°F (-5 ~ 35°C)

Case Plastics

Weight 0.81 oz

Dimensions (WxHxD) 0.98˝ x 3.46˝ x 0.46˝

FM Frequency 87.5 ~ 108.0 MHz

FM Signal to

Noise Ratio 50 dB

FM T.H.D 1%

FM Useable

Sensitiivity 32dBμ

Samsung Electronics 2-3

Product Specification

2-3 Specifications Analysis

Model YP-U5 YP-U4


Basic

Storage Type Flash memory (MLC) Flash memory (MLC)

Display 16Gray 4Line OLED (128x64) 16Gray 4Line OLED (128x64)

Platform STMP3770 STMP3650

Battery Li-Polymer Li-Polymer

Battery Capacity 160mAh 300mAh

Playback Time

(Earphone) 20hrs 16hrs

Color Black / White / Red / Pink / Blue Black / Red / Blue

Memory

512M X X

1G X

2G  

4G  

8G X

Files

Supported

MP3  

WMA  

OGG (up to Q10) (up to Q10)

WAV X X

AAC X X

Audible X X

JPEG  

FLAC X

APE X X

WMV X X

MPEG4 (SVI) X X

Swf X X

Others X X

Sound

Field

Preset EQ Normal, Rock, R&B, Dance Normal, Rock, Classical ,Jazz Ballad,

R&B, Dance

User EQ (7 Band Control) (7 Band Control)

Special Effect DNSe Portable:

3D-Studio, 3D-Concert Hall

DNSe Portable:

3D-Studio, 3D-Club,

3D-Concert Hall

Street Mode / Clearity

Sound Feedback (AUI) (AUI)

Speed Control  

Alarm X X

Output Power 18mW/CH 20mW / CH

: application, X: non-application

2-4 Samsung Electronics

Product Specification

Model YP-U5 YP-U4


Encoding

FM  

FM REC.  

Line In X X

Video X X

Tuner

FM  

RDS  

DMB X X

Etc. X X

Voice

Recording

Voice Recording  

Recording Format MP3 MP3

Recording Mode 4 Mode (32Kbps ~ 128Kbps) 4 Mode (32Kbps ~ 128Kbps)

Additional

Functions

(Sound)

Playlist



Mobile Playlist (Favorite)

PC Playlist (SPL, WPL)



Mobile Playlist (Favorite)

PC Playlist (SPL, WPL)

Folder Play (Browser)  

Library

(Artist, Album, Genre,

Title DB sorting)

(Artist, Album, Genre,

Title DB sorting)

File Navigation  

Additional

Functions

(Video)

Photo Viewer X X

Text Viewer X X

Game X X

Wallpaper X X

Clock X X

Etc. Screen Saver Screen Saver

Additional

Functions

(Other)

Multi Language Menu

30 Language

- KOREA, ENG, FRA, GER, ITA, JPN,

CHA-S, CHA-T, RUS, HUG, POR,

SPA, DUT, POL, SWEDISH, Thai

30 Language

- KOREA, ENG, FRA, GER, ITA, JPN,

CHA-S, CHA-T, RUS, HUG, POR,

SPA, DUT, POL, SWEDISH, Thai

Multi Language tag

Display

(31 Languages) + tag (31 Languages) + tag

Resume (Audio) (Audio)

Bookmark X X

DRM

Netsync (Korea)  

SKT Melon (Korea) X X

WMA DRM  

Janus  

: application, X: non-application

Samsung Electronics 2-5

Product Specification

2-4 Accessories

2-4-1 Supplied Accessories

Accessories Item Item Code Remark

Earphones AH30-00111A

Samsung Service

Center

Clip AH61-02742A

User’s Manual AH68-02172Q
