Samsung U28D590D Manuel utilisateur

User manual

U28D590D

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00410A-01

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

18 Correct posture to use the product

PREPARATIONS 19 Checking the Contents

19 Checking the Components

20 Parts

20 Control Panel

21 Direct Key guide

22 Function Key Guide

24 Reverse Side

25 Installation

25 Attaching the Stand

26 Removing the Stand

27 Adjusting the Product Tilt

27 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

28 Before Connecting

28 Pre-connection Checkpoints

Table Of Contents

Table Of Contents 3

28 Connecting and Using a PC

28 Connection Using the HDMI Cable

29 Connection Using the HDMI-DVI Cable

29 Connection Using the DP Cable

30 Connecting to Headphones or Speakers

31 Connecting the Power

33 Driver Installation

34 Setting Optimum Resolution

SCREEN SETUP 35 Brightness

35 Configuring Brightness

36 Contrast

36 Configuring Contrast

37 Sharpness

37 Configuring Sharpness

38 Game Mode

38 Configuring Game Mode

39 SAMSUNG MAGIC Bright

39 Configuring SAMSUNG MAGIC Bright

41 SAMSUNG MAGIC Angle

41 Configuring SAMSUNG MAGIC Angle

43 Color

43 Configuring Color

45 HDMI Black Level

45 Configuring the HDMI Black Level Settings

46 Response Time

46 Configuring the Response Time

SCREEN ADJUSTMENT 47 Image Size

47 Changing the Image Size

49 H-Position & V-Position

49 Configuring H-Position & V-Position

Table Of Contents

Table Of Contents 4

50 PIP/PBP

51 Configuring PIP/PBP Mode

52 Configuring Size

53 Configuring Position

54 Configuring Sound Source

55 Configuring Source

57 Configuring Image Size

61 Configuring Contrast

COORDINATING OSD 63 Language

63 Configuring Language

64 Display Time

64 Configuring Display Time

65 Transparency

65 Changing Transparency

SETUP AND RESET 66 Eco Saving

66 Configuring Eco Saving

67 PC/AV Mode

67 Configuring PC/AV Mode

68 Source Detection

68 Configuring Source Detection

69 Key Repeat Time

69 Configuring Key Repeat Time

70 Off Timer

70 Configuring Off Timer

71 Configuring Turn Off After

72 Power LED On

72 Configuring Power LED On

73 Reset All

73 Initializing Settings (Reset All)

Table Of Contents

Table Of Contents 5

INFORMATION MENU AND

OTHERS

74 Information

74 Displaying Information

75 Configuring Brightness, Contrast and

Sharpness from the Initial Screen

76 Configuring Volume in the Initial Screen

76 Volume

INSTALLING THE

SOFTWARE

77 Easy Setting Box

77 Installing the Software

78 Removing the Software

TROUBLESHOOTING

GUIDE

79 Requirements Before Contacting

Samsung Customer Service Center

79 Testing the Product

79 Checking the Resolution and Frequency

79 Check the following.

82 Q & A

SPECIFICATIONS 84 General

85 PowerSaver

86 Standard Signal Mode Table

APPENDIX 90 Contact SAMSUNG WORLD WIDE

96 Responsibility for the Pay Service (Cost

to Customers)

96 Not a product defect

96 A Product damage caused by customer's fault

96 Others

97 Correct Disposal

97 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

98 Terminology

Table Of Contents

Table Of Contents 6

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 90) if the inside of the monitor needs

cleaning. (A service fee will be charged.)

3.93

inches

(10 cm)

3.93

inches

(10 cm)

3.93 inches(10 cm)

3.93 inches

(10 cm)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
