Samsung SyncMaster S24B420BW Manuel utilisateur

User Manual

S24B420BW

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00232C-01

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

17 Correct posture to use the product

PREPARATIONS 18 Checking the Contents

18 Checking the Components

19 Parts

19 Frontal Buttons

21 Reverse Side

22 Installation

22 Attaching the Stand

23 Adjusting the Product Tilt and Height

23 Rotating the Monitor

24 Installing a Wall-mount Kit or Desktop Stand

26 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

27 Before Connecting

27 Pre-connection Checkpoints

27 Connecting and Using a PC

27 Connecting to a PC

28 Connecting the Power

29 Driver Installation

30 Setting Optimum Resolution

Table Of Contents

Table Of Contents 3

SCREEN SETUP 31 Brightness

31 Configuring Brightness

32 Contrast

32 Configuring Contrast

33 Sharpness

33 Configuring Sharpness

34 SAMSUNG MAGIC Bright

34 Configuring SAMSUNG MAGIC Bright

35 Image Size

35 Changing the Image Size

37 Response Time

37 Configuring Response Time

38 H-Position & V-Position

38 Configuring H-Position & V-Position

39 Coarse

39 Adjusting Coarse

40 Fine

40 Adjusting Fine

CONFIGURING TINT 41 Red

41 Configuring Red

42 Green

42 Configuring Green

43 Blue

43 Configuring Blue

44 Color Tone

44 Configuring the Color Tone Settings

45 Gamma

45 Configuring Gamma

Table Of Contents

Table Of Contents 4

RESIZING OR

RELOCATING THE

SCREEN

46 Language

46 Changing the Language

47 Menu H-Position & Menu V-Position

47 Configuring Menu H-Position & Menu V-

Position

48 Display Time

48 Configuring Display Time

49 Transparency

49 Changing Transparency

SETUP AND RESET 50 Reset

50 Initializing Settings (Reset)

51 Eco Saving

51 Configuring Eco Saving

52 Off Timer

52 Configuring Off Timer

53 Turn Off After

53 Configuring Turn Off After

54 PC/AV Mode

54 Configuring PC/AV Mode

55 Key Repeat Time

55 Configuring Key Repeat Time

56 Source Detection

56 Configuring Source Detection

57 Customized Key

57 Configuring Customized Key

INFORMATION MENU AND

OTHERS

58 INFORMATION

58 Displaying INFORMATION

59 Configuring Brightness and Contrast in

the Initial Screen

Table Of Contents

Table Of Contents 5

INSTALLING THE

SOFTWARE

60 Magic Tune

60 What is MagicTune?

60 Installing the Software

61 Removing the Software

62 MultiScreen

62 Installing the Software

63 Removing the Software

64 MagicRotation

64 Installing the Software

66 Removing the Software

TROUBLESHOOTING

GUIDE

67 Requirements Before Contacting

Samsung Customer Service Center

67 Testing the Product

67 Checking the Resolution and Frequency

67 Check the following.

70 Q & A

SPECIFICATIONS 72 General

74 PowerSaver

75 Standard Signal Mode Table

APPENDIX 77 Contact SAMSUNG WORLD WIDE

83 Responsibility for the Pay Service (Cost

to Customers)

83 Not a product defect

83 A Product damage caused by customer's fault

83 Others

84 Correct Disposal

84 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

85 Terminology

Table Of Contents

Table Of Contents 6

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 77) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

10 cm(3.93 inches)

10 cm

(3.93

inches)

10 cm

(3.93

inches)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance

has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
