SyncM aster 460DX (LH46BPP)

SyncM aster 520DX (LH52BPP)

Training M anual

SAMSUNG ELECTRONICS CO.,LTD

Visual Display Division

LCD Monitor Group

Index

Overview

Introduction

Block Di gr m

M in Bo rd P rt

Service Mode P rt

Troubleshooting

DDC Entry

Wh t To Do fter Bo rd Repl cement

Overview

1. Background of Development

▶To expand the large LCD product market (Public facilities like Airport, Theater, etc.)

▶ To enhance image uality, and additional functions

comparing with the existing model

▶ To provide more convenience for user

▶ To achieve competitive power by improving optional network function

Overview

2. Product Features

▶VMB (Vertical Marketing Business) Model

▶MFM (Multi Function Monitor) :

Receives diverse support other than PC (DVI, HDMI, AV, S-video, Component)

▶Response Time 8ms SPVA adopted

▶Sound function reinforced by adopting SRS Trusurround

▶ RS232 Remote Control (MDC software provided)

▶Video input: PC(D_SUB,DVI), BNC, DVI, HDMI, Component, AV, S-Video

▶Audio input: PC(D_SUB,DVI) Stereo, Video(AV, S-Video), Component, BNC, HDMI

▶Image & sound output: PC, BNC, AV, S-Video, Component out, speaker out

▶10W x 2 speaker

▶PIP automatic switch timer function: PIP automatically pops-up when setting time

▶PIP, OSD menu transparency control

▶Sleep timer (automatic switch-off) function

▶Wall & Ceiling Mounting (Optional VESA Wall Mount Kit)

Overview

3. Specifications

LH40MST / LH46MST

Model Name SyncMaster 400UXn / 460UXn

Panel AMLCD 46” ( LTI460AA01-V01 )

AMLCD 52” ( LTI520AA01-V01 )

Optimum Resolution 1366 x 768 (WXGA) 60Hz

Display Size 46” / 52” (16:9)

Bri htness 700cd/m2

Contrast Ratio 1200:1

Response Time 8 ms

Viewin An le Left/Right/Up/Down : 89/89/89/89

PC Input D-SUB, DVI

Video System AV, S-Video, Component

Supported Resolution

(Component) 1080I(50/60), 480I, 480P, 576I, 576P, 720P(50/60)

Power Consumption Less than 240 W(40”), 340 W(46”)

DPMS 1 W

Sound Output Max. 10W x 2

Introduction (Front)

MENU :

Use this button to open the on-screen menu and exit from the menu screen or

close screen adjustment menu.

Up/Down button :

Moves from one menu item to another vertically or adjusts selected menu values.

Adjust / Volume button :

Moves from one menu item to another horizontally or adjusts selected menu values.

Also adjusts the audio volume.

ENTER : Activates a highlighted menu item.

SOURCE :

Changing the source is allowed only in external devices that are connected to the

monitor at the time. To switch Screen modes:

[PC] -> [BNC] -> [DVI] -> [AV] -> [S-Video] -> [Component] -> [HDMI] -> [MagicNet]

PIP :

Push the PIP button to turn PIP screen On/Off.

More than one PIP couldn't be overlapped on screen as BNC and the component use

the same terminal.

• PC / DVI : AV / S-Video / Component Mode

• BNC: AV / S-Video Mode

• AV / S-Video : PC / BNC / DVI Mode

• Component: PC / DVI Mode

POWER : Use this button to turn the monitor on and off.

LED : Power Indicator shows Power Saving mode by green blinking.

Remote Control Sensor : Aim the remote control towards this spot on the

Monitor.

Viewin the Control Panel

1. MENU 5. SOURCE

2. Navi ate button (Up-Down button) 6. PIP

3. Adjust button (Left-Ri ht button) 7. Power button

Volume button 8. Power indicator

4. ENTER 9. Remote Control Sensor

Introduction (Rear)

Rear

1. POWER S/W

2. POWER IN

Connection Terminal

OFF

Introduction (Rear)

Connection Terminal

Rear

3. REMOTE OUT/IN (Remote Control Port)

4. RS232C OUT/IN (RS232C Serial Port)

: MDC(Multiple Device Control) Program Port

5. PC/DVI/BNC AUDIO IN

(PC/DVI/BNC Audio Connection Terminal(Input))

6. HDMI IN(HDCP)

7. PC IN(RGB) (PC Video Connection Terminal)

: Using D-Sub (15 Pin) Cable - PC Mode (Analog PC)

8. DVI IN (PC Video Connection Terminal)

: Using DVI Cable (DVI-D to DVI-D) - DVI Mode (Digital PC)

Introduction (Rear)

Rear

9. COMPONENT AUDIO IN [L-AUDIO-R]

(Component Audio Connection Terminal (Input))

10. BNC/COMPONENT OUT

(BNC/Component Connection Terminal (Output))

- BNC (Analo PC) Connection :

connecting R, G, B, H, V port

- Component Connection :

connecting Pr, Y, Pb port

11. BNC/COMPONENT IN

(BNC/Component Connection Terminal (Input))

BNC COMPONENT

Connection Terminal

12. AV AUDIO IN [L-AUDIO-R]

(Monitor Audio Connection Terminal (Input))

13. AV OUT [VIDEO] (Video Connection Terminal)

: AV mode (Output)

14. AV IN [VIDEO] (Video Connection Terminal)

: AV mode (Input)

15. AV OUT [S-Video] (S-Video Connection Terminal)

: S-Video mode (Output)

16. AV IN [S-Video] (S-Video Connection Terminal)

: S-Video mode (Input)

17. EXT SPEAKER(8 Ω) (EXT Speaker Connection Terminal)

18. AUDIO OUT [L-AUDIO-R]

(Monitor Audio Connection Terminal (Output))

: MONITOR OUT is the terminal for sound output of PC, DVI or BNC

Introduction (Rear)

Rear

Connection Terminal
