Samsung SyncMaster 910TM Manuel utilisateur

Please make sure the following items are included with your monitor.

If any items are missin

, contact your deale

Unpacking

Monitor

Manual

Cable

Quick Setup Guide Warranty Card

(Not available in all

locations)

User's Guide,

Monitor Driver,

Natural Color software,

MagicTune software,

Magic software



D-Sub Cable Power Cord Audio Cable

Sold separatel

DVI Cable(option)

Front

Menu button [ ]

Opens the OSD menu. Also use to exit the OSD menu or return

to the previous menu.

MagicBright button

[ ]

MagicBright is a new feature providing optimum viewing

environment depending on the contents of the image you are

watching. Currently four different modes are available: Custom,

Text, Internet, and Entertain. Each mode has its own

preconfigured brightness value. You can easily select one of four

settings by simply pressing MagicBright control buttons.

1) Custom

Although the values are carefully chosen by our engineers,

the pre-configured values may not be comfortable to your

eyes depending on your taste.

If this is the case, adjust the Brightness and Contrast by

using the OSD menu.

2) Text : Normal Brightness

For documentations or works involving heavy text.

3) Internet : Medium Brightness

For working with a mixture of images such as text and

graphics.

4) Entertain : High Brightness

For watching motion pictures such as a DVD or VCD.

>>Click here to see an animation clip

Volume button[ ] When OSD is not on the screen, push the button to adjust

volume.

Adjust buttons [ ] Adjust items in the menu.

Enter button [ ] /

Source button Activates a highlighted menu item. /

Push the 'Source' and then select the Video signal while the

OSD is off. (When the Source button is pressed to change the

input mode, a message appears on the upper left of the screen

displaying the current mode -- analog or digital input signal.)

Note : If you select the Digital mode, you must connect your

monitor to the graphic card's port using the DVI cable.

Auto button Use this button for auto adjustment.

Power button [ ] Use this button to turn the monitor on and off.

Power indicator

This light glows green during normal operation, and blinks green

once as the monitor saves your adjustments.

See PowerSaver described in the manual for further information regarding power saving

functions. For energy conservation, turn your monitor OFF when it is not needed or when

leaving it unattended for long periods.

Rear

(The configuration at the back of the monitor may vary from product to product.)

Power port Connect the power cord to the power port on the back of the monitor.

DVI port Connect the DVI Cable to the DVI Port on the back of your Monitor.

D-sub 15-pin port Connect the signal cable to the 15-pin, D-sub connector on the back

of your monitor.

Power on/off Switch Use this button for turn the monitor on and off.

Kensington Lock The Kensington lock is a device used to physically fix the system

when using it in a public place. (The locking device has to be

purchased separately. )

Headphone connection

terminal Connect your headphone to the Headphone-out port.

AUDIO IN Connect the audio cable for your monitor to the audio port on the

back of your computer.

See Connecting the Monitor for further information regarding cable connections.
