Samsung S22F354FH Manuel utilisateur

User Manual

The color and the appearance may differ depending on the product, and the specifications are subject to change without prior

notice to improve the performance.

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Trademarks other than that of Samsung Electronics are owned by their respective owners.

S22F350FH* S22F352FH* S22F354FH* S24F350FH* S24F352FH* S24F354FH* S24F356FH* S24F359FH*

S27F350FH* S27F352FH* S27F354FH* S27F358FW* S27F359FH* S32F351FU*

•An administration fee may be charged if either

‒(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

‒(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

•The amount of such administration charge will be advised to you before any work or home visit is carried out.

Table of contents

Before Using the Product

Securing the Installation Space 4

Precautions for storage 4

Safety Precautions 4

Symbols 4

Cleaning 5

Electricity and Safety 5

Installation 6

Operation 7

Preparations

Parts 9

Control Panel 9

Direct Key guide 10

Function Key Guide 11

Changing Brightness, Contrast and Sharpness

settings 12

Reverse Side 13

Adjusting the Product Tilt 14

Anti-theft Lock 14

Installing a Wall-mount Kit or Desktop Stand

(S22F350FH*/S22F352FH*/S22F354FH*/

S24F350FH*/S24F352FH*/S24F354FH*/

S24F356FH*/S24F359FH*/S27F350FH*/

S27F352FH*/S27F354FH*/S27F358FW*/

S27F359FH*) 15

Installing a Wall-mount Kit or Desktop Stand

(S32F351FU*) 17

Installation 19

Attaching the Stand (S22F350FH*/S22F352FH*/

S22F354FH*/S24F350FH*/S24F352FH*/S24F354FH*/

S24F359FH*/S27F350FH*/S27F352FH*/S27F354FH*/

S27F359FH*/S32F351FU*) 19

Removing the Stand (S22F350FH*/S22F352FH*/

S22F354FH*/S24F350FH*/S24F352FH*/

S24F354FH*/S24F359FH*/S27F350FH*/

S27F352FH*/

S27F354FH*/S27F359FH*/S32F351FU*) 20

Attaching the Stand (S24F356FH*/S27F358FW*) 21

Removing the Stand (S24F356FH*/S27F358FW*) 22

Connecting and Using a Source Device

Pre-connection Checkpoints 23

Connecting and Using a PC 23

Connection Using the D-SUB Cable (Analog Type) 23

Connection Using the HDMI or HDMI-DVI Cable 24

Connection Using an DP Cable 24

Connecting the Power 25

Correct posture to use the product 26

Driver Installation 26

Setting Optimum Resolution 26

Screen Setup

SAMSUNG MAGIC Bright 27

Brightness 28

Contrast 28

Sharpness 28

Color 28

SAMSUNG MAGIC Angle

(S22F350FH*/S22F352FH*/S22F354FH*) 29

SAMSUNG MAGIC Upscale 29

HDMI Black Level 29

Eye Saver Mode 30

Game Mode 30

Response Time (S24F350FH*/S24F352FH*/

S24F354FH*/S24F356FH*/S24F359FH*/

S27F350FH*/S27F352FH*/S27F354FH*/

S27F358FW*/S27F359FH*/S32F351FU*) 30

Picture Size 30

Screen Adjustment 31

Table of contents

Adjusting OSD (On Screen Display)

settings

Transparency 32

Position 32

Language 32

Display Time 32

Setup and Reset

FreeSync (S24F350FH*/S24F352FH*/S24F354FH*/

S24F356FH*/S24F359FH*/S27F350FH*/

S27F352FH*/S27F354FH*/S27F358FW*/

S27F359FH*) 33

Eco Saving Plus 35

Off Timer 35

PC/AV Mode 35

Source Detection 35

Key Repeat Time 35

Power LED On 36

Reset All 36

Information 36

Installing the Software

Easy Setting Box 37

Troubleshooting Guide

Requirements Before

Contacting Samsung Customer Service Center 38

Testing the Product 38

Checking the Resolution and Frequency 38

Check the following. 38

Q & A 40

Specifications

General 41

Standard Signal Mode Table 42

Appendix

Responsibility for the Pay Service

(Cost to Customers) 44

Not a product defect 44

A Product damage caused by customer's fault 44

Others 44

Securing the Installation Space

Ensure some space around the product forventilation. An internal temperature rise may cause fire and

damage the product. Be sure to allow the amount of space as shown below or greaterwhen installing

the product.

―The exterior may differ depending on the product.

10 cm (3.93 Inches)

10 cm

(3.93 Inches)

10 cm

(3.93 Inches)

10 cm

(3.93 Inches)

10 cm

(3.93 Inches)

10 cm (3.93 Inches)

10 cm

(3.93 Inches)

10 cm

(3.93 Inches)

10 cm

(3.93 Inches)

10 cm

(3.93 Inches)

Precautions for storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used

nearby.

―Contact your nearest Samsung Customer Service Center if you want to clean the inside of the product (Service

fee will be charged.)

Safety Precautions

Caution RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.

(OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this

product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Symbols

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Before Using the Product

Chapter 01

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock

may result.

Wipe the monitorwith a clean, soft and dry cloth.

‒Do not apply a cleaning agent that contains alcohol, solvent, or surfactant to the monitor.

‒Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Electricity and Safety

Warning

•Do not use a damaged power cord or plug, or a loose power socket.

•Do not use multiple products with a single power socket.

•Do not touch the power plug with wet hands.

•Insert the power plug all the way in so it is not loose.

•Connect the power plug to a grounded power socket (type 1 insulated devices only).

•Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy

object.

•Do not place the power cord or product near heat sources.

•Clean any dust around the pins of the power plug or the power socket with a dry cloth.

Caution

•Do not disconnect the power cord while the product is being used.

•Only use the power cord provided with your product by Samsung. Do not use the power cord with

other products.

•Keep the power socket where the power cord is connected unobstructed.

‒The power cord must be disconnected to cut off power to the product when an issue occurs.

•Hold the plug when disconnecting the power cord from the power socket.

Warning

•DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF THE PRODUCT. DO NOT

INSTALL THE PRODUCT NEAR HEAT SOURCES.

•Do not install the product in poorly ventilated spaces such as a bookcase or closet.

•Install the product at least 10 cm away from the wall to allow ventilation.

•Keep the plastic packaging out of the reach of children.

‒Children may suffocate.

•Do not install the product on an unstable orvibrating surface (insecure shelf, sloped surface, etc.)

‒The product may fall and become damaged and/or cause an injury.

‒Using the product in an area with excess vibration may damage the product or cause a fire.

•Do not install the product in a vehicle or a place exposed to dust, moisture (water drips, etc.), oil, or

smoke.

•Do not expose the product to direct sunlight, heat, or a hot object such as a stove.

‒The product lifespan may be reduced or a fire may result.

•Do not install the product within the reach of young children.

‒The product may fall and injure children.

•Edible oil (such as soybean oil) may damage or distort the product. Keep the product away from oil

pollution. And do not install or use the product in the kitchen or near the kitchen stove.

Caution

•Do not drop the product while moving.

•Do not set down the product on its front.

•When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of

the product is not protruding.

‒The product may fall and become damaged and/or cause an injury.

‒Install the product only on cabinets or shelves of the right size.

•Set down the product gently.

‒Product failure or personal injury may result.

•Installing the product in an unusual place (a place exposed to a lot of fine dust, chemical substances,

extreme temperatures or a significant presence of moisture, or a place where the product will

operate continuously for an extended period of time) may seriously affect its performance.

‒Be sure to consult Samsung Customer Service Center if you want to install the product at such a

place.

Installation

Warning

•There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.

‒Contact Samsung Customer Service Center for repairs.

•To move the product, first disconnect all the cables from it, including the power cable.

•If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord

immediately and contact Samsung Customer Service Center.

•Do not let children hang from the product or climb on top of it.

‒Children may become injured or seriously harmed.

•If the product is dropped or the outer case is damaged, turn off the power and disconnect the power

cord. Then contact Samsung Customer Service Center.

‒Continued use can result in a fire or electric shock.

•Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.

‒The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a

serious injury.

•During a lightning or thunderstorm, power off the product and remove the power cable.

•Do not drop objects on the product or apply impact.

•Do not move the product by pulling the power cord or any cable.

•If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area

immediately.

•Do not lift or move the product by pulling the power cord or any cable.

•Do not use or keep combustible spray or an inflammable substance near the product.

•Ensure the vents are not blocked by tablecloths or curtains.

‒An increased internal temperature may cause a fire.

•Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper,

matches, etc) into the product (via the vent or input/output ports, etc).

‒Be sure to power off the product and disconnect the power cord when water or other foreign

substances have entered the product. Then contact Samsung Customer Service Center.

•Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the

product.

‒Be sure to power off the product and disconnect the power cord when water or other foreign

substances have entered the product. Then contact Samsung Customer Service Center.

Operation

Caution

•Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage

burn-in or defective pixels.

‒Activate power-saving mode or a moving-picture screen saver if you will not be using the product

for an extended period of time.

•Disconnect the power cord from the power socket if you do not plan on using the product for an

extended period of time (vacation, etc).

‒Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.

•Use the product at the recommended resolution and frequency.

‒Your eyesight may deteriorate.

•Do not put AC/DC adapters together.

•Remove the plastic bag from the AC/DC adapter before you use it.

•Do not let water enter the power device or get the device wet.

‒An electric shock or fire may result.

‒Avoid using the product outdoors where it can be exposed to rain or snow.

‒Be careful not to get the AC/DC adapter wet when you wash the floor.

•Do not put the AC/DC adapter near to any heating apparatus.

‒Otherwise, a fire may result.

•Keep the AC/DC adapter in a well-ventilated area.

•If you place the AC/DC power adapter so that it is hanging with the cord input facing upwards, water

or other foreign substances could enter the Adapter and cause the Adapter to malfunction.

Make sure to rest the AC/DC power adapter flat on a table or the floor.

•Do not hold the product upside-down or move it by holding the stand.

‒The product may fall and become damaged or cause an injury.

•Looking at the screen too close for an extended period of time can deteriorate your eyesight.

•Do not use humidifiers or stoves around the product.

•Rest your eyes for more than 5 minutes for every1 hour of product use.

•Do not touch the screen when the product has been turned on for an extended period of time as it

will become hot.

•Store small accessories out of the reach of children.

•Exercise caution when adjusting the product angle or stand height.

‒Your hand or finger may get stuck and injured.

‒Tilting the product at an excessive angle may cause the product to fall and an injury may result.

•Do not place heavy objects on the product.

‒Product failure or personal injury may result.

Parts

Control Panel

―The color and shape of parts may differ from what is shown. Specifications are subject to change without

notice to improve quality.

S24F356FH*/S27F358FW*

S22F350FH*/S22F352FH*/S22F354FH*/S24F350FH*/S24F352FH*/S24F354FH*/

S24F359FH*/S27F350FH*/S27F352FH*/S27F354FH*/S27F359FH*

S32F351FU*

Power LED

LEFT

Return

JOG Button

Function Key Guide

RIGHT

DOWN

PRESS(ENTER)

Power LED

Icons Description

JOG Button

Multi directional button that helps navigate.

―The JOG button is located on the rear left side of the product. The

button can be used to move up, down, left or right, or as Enter.

Power LED

This LED is power status indicator and works as

•Power On (Power button): Off

•Power saving mode: Blinking

•Power Off (Power button): On

―The power Indicator operation can be swapped by changing in the

menu. (System Power LED On) Actual models because of functional

variation maybe haven’t this function.

Function Key Guide

Press the JOG button when the screen is turned on. The Function Key

Guide will appear. To access the onscreen menu when the guide is

displayed, press the corresponding direction button again.

―Function Key Guide may vary depending on the function or product

model. Please refer to the actual product.

Preparations

Chapter 02

S22F350FH*/S22F352FH*/S22F354FH*/S24F350FH*/S24F352FH*/S24F354FH*/S24F356FH*/

S24F359FH*/S27F350FH*/S27F352FH*/S27F354FH*/S27F359FH*

Brightness

Auto Adjustment

Features

Eye Saver Mode Off

•/ : Adjust Brightness, Contrast, Sharpness.

•: Adjust Auto Adjustment.

―Changing the resolution in Display Properties will activate the Auto Adjustment function.

―This function is only available in Analog mode.

•: Display Function Key Guide.

S32F351FU*/S27F358FW*

Brightness

Features

Eye Saver Mode Off

•/ / / : Adjust Brightness, Contrast, Sharpness.

•: Display Function Key Guide.

Direct Key guide

―The shortcut button screen (OSD menu) shown below is displayed only when the monitor screen is turned on, the computer resolution changes, or the input source changes.

―The function buttons page shows if Eye Saver Mode is enabled.

: On

: Off

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung 2233RZ - Syncmaster 22" 3D Gaming LCD Monito Manuel utilisateur

Samsung

Samsung SyncMaster 305TPLUS Manuel utilisateur

Samsung

Samsung IW008R Manuel utilisateur

Samsung

Samsung SyncMaster 150N Mode d’emploi

Samsung

Samsung 913N - SyncMaster - 19" LCD Monitor Manuel utilisateur

Samsung

Samsung 916V - SyncMaster - 19" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 450Nb Manuel utilisateur

Samsung

Samsung SyncMaster T27A300 Manuel utilisateur

Samsung

Samsung SyncMaster B2230HD Manuel utilisateur

Samsung

Samsung MJ15AS* 510N Manuel utilisateur

Samsung

Samsung DM82D Manuel utilisateur

Samsung

Samsung SyncMaster BX2031 Guide de l'utilisateur

Samsung

Samsung S27C750P Manuel utilisateur

Samsung

Samsung SyncMaster S19A350N Manuel utilisateur

Samsung

Samsung SyncMaster 230MXN Manuel utilisateur

Samsung

Samsung S22C450D Manuel utilisateur

Samsung

Samsung MD65C Manuel utilisateur

Samsung

Samsung 2263DX - SyncMaster - 22" LCD Monitor Manuel utilisateur

Samsung

Samsung LH85WMRWLGCXEN Manuel utilisateur

Samsung

Samsung 520DXN - SyncMaster - 52" LCD Flat Panel... Guide de l'utilisateur

Samsung

Samsung SyncMaster S23B370H Manuel utilisateur

Samsung

Samsung S34C50 Series Manuel utilisateur

Samsung

Samsung S19C350NW Manuel utilisateur

Samsung

Samsung SyncMaster 2343BWX Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
