Samsung SyncMaster 650TS-2 Manuel utilisateur

SyncMaster 650TS-2

LCD Display

User Manual

The color and the appearance may differ depending on the

product, and the specifications are subject to change

without prior notice to improve the performance.

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property dam-

age.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily

harm or damage to the equipment.

Note

Prohibited Important to read and under-

stand at all times

Do not disassemble Disconnect the plug from the

outlet

Do not touch Ground to prevent an electric

shock

Power

When not used for extended period of time, set your computer to DPM.

If using a screen saver, set it to active screen mode.

Theimageshereareforreferenceonly,andarenotapplicableinallcases

(or countries).

Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or

loose power outlet.

• Otherwise, this may result in electric shock or fire.

Do not touch the power plug with wet hands when removing or

plugging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power out-

let.

• Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet

firmly and correctly.

• Otherwise, this may result in fire.

Do not forcefully bend or pull the power plug and do not place

any heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

•Otherwise, this may result in damage to the product due to

electric shock.

To disconnect the apparatus from the mains, the plug must be

pulled out from the mains socket, therefore the mains plug shall

be readily operable.

• Otherwise, this may cause electric shock or fire.

Use only the power cord provided by our company. Do not use

the provided power cord of another product.

• Otherwise, this may result in fire or electric shock.

Connect the power plug to a wall outlet that can be easily

reached.

•When a problem occurs with the product, you must unplug the

power plug to cut the power off completely. You cannot cut the

power off completely using only the power button on the prod-

uct.

Installation

Be sure to contact an authorized Service Center when installing your

monitor in a location with heavy dust, high or low temperatures, high hu-

midity, and exposed to chemical substances and where it operates for 24

hours such as at airports, train stations etc.

Failure to do so may cause serious damage to your monitor.

Ensure that at least two persons lift and move the product.

•Otherwise, it may be dropped and cause personal injury, and/

or damage the product.

When installing the product in a cabinet or rack, make sure that

the front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

Safety Instructions

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIGA-

RETTES AND ANY HEATING APPLIANCES NEAR THE PROD-

UCT.

• Otherwise, this may result in fire.

Keep heatingappliances asfar awayfrom thepower cordor the

product as possible.

• Otherwise, this may result in electric shock or fire.

Do notinstallit inabadly ventilatedlocationsuch asabookcase

or closet.

•Otherwise, this may result in fire due to an increase in the in-

ternal temperature.

When putting the product down, make sure to put it down softly.

• Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall

mount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that

there is a clearance of more than 4 inches (10 cm) from the wall.

•Otherwise,it mayresult infire dueto anincrease inthe internal

temperature.

Ensure that the packaging vinyl is kept away from children.

•Otherwise,itmayresult inseriousharm(suffocation)ifchildren

play with it.

If the height of your monitor is adjustable, do not place any ob-

ject or part of your body on the stand when lowering it.

•This may cause damage to the product or the person carrying

it.

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen,

wipe with a slightly moistened, soft fabric.

Safety Instructions

Do not spray cleaner directly onto the surface of the product.

•Otherwise, this may result in the discoloration and distortion of

the structure and the screen surface may peel off.

When cleaning the power plug pins or dusting the power outlet,

clean it with a dry cloth.

• Otherwise, it may result in fire.

When cleaning the product, make sure to disconnect the power

cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and

clean it softly with a dry cloth.

• (Do not use chemicals such as wax, benzene, alcohol, thinner,

mosquito repellant, lubricant, or cleaner.) These may change

the appearance of the product surface and peel off the indica-

tion labels on the product.

Since the product housing is easily scratched, make sure to use

the specified cloth only.

When cleaning the product, do not spray water directly onto the

main body of the product.

• Ensure that water does not enter the product and that it is not

wet.

•Otherwise, this may result in electric shock, fire or a malfunc-

tion.

Others

The product is a high voltage product. Do not disassemble, re-

pair or modify the product yourself.

•Otherwise,thismayresultinelectricshockorfire.Iftheproduct

needs to be repaired, contact a Service Center.

Ifthere isastrangesmellor astrangesoundor smokeiscoming

fromthe product,disconnectthe powerplug immediatelyand con-

tact a Service Center.

• Otherwise, this may result in electric shock or fire.

Donotplacethisproductinalocationexposedtomoisture,dust,

smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Whenyou droptheproductorthe caseis broken,turn thepower

off and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

If thunder or lightning is occurring, do not touch the power cord

or antenna cable.

• Otherwise, this may result in electric shock or fire.

Do not try to move the monitor by pulling only the wire or the

signal cable.

•Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and

left while only holding the power cord or signal cables.

•Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table

or curtain.

•Otherwise,it mayresult infire dueto anincrease inthe internal

temperature.

Do not place any containers containing water, vases, flower-

pots, medicines as well as any metal on the product.

•Ifwateror aforeign materialenters theproduct, disconnectthe

power cord and contact a Service Center.

•This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material

near the product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and

steel, or flammable objects, such as matches or paper, inside the

product (through the ventilating openings, input and output termi-

nals, etc).

•If water or foreign material enters the product, disconnect the

power cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

Whenusinga fixedscreenforalong time,anafterimage orstain

may occur.

•If you are not using your product for a long period of time, put

it into sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

Safety Instructions

When using headphones or earphones, do not turn the volume

too high.

• Having the sound too loud may damage your hearing.

To avoid eyestrain, do not sit too close to the product.

Take a rest for at least five (5) minutes after using the monitor

for one (1) hour.

This reduces eye fatigue.

Do not install it in an unstable location such as an unstable rack

or uneven surface or a location exposed to vibrations.

•Otherwise,itmayfallandcausepersonalinjuryand/ordamage

the product.

•Ifyouusetheproductin alocationexposedtovibrations,itmay

damage the product and result in fire.

When moving the product, turn the power off and disconnect

thepower plug,antenna cable,and allthe cablesconnectedto the

product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up

onto the product.

• The product may fall and cause personal injury or death.

Ifyoudonotusetheproductforalongperiodoftime,disconnect

the power cord from the power outlet.

•Otherwise, this may result in overheating or fire due to dust,

and may result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as

cookies etc. that may attract the attention of children and to the

product.

•Your children may hang onto the product causing it to fall and

this may result in personal injury or death.

Be careful that children do not place the battery in their mouths

when removed from the remote control. Place the battery in a lo-

cation that children or infants cannot reach.

•If children have had the battery in their mouths, consult your

doctor immediately.

When replacing the battery, insert it with the right polarity (+, -).

•Otherwise, the battery may become damaged or it may cause

fire, personal injury or damage due to leakage of the internal

liquid.

Safety Instructions

Use only the specified standardized batteries, and do not use a

new battery and a used battery at the same time.

•Otherwise, the batteries may be damaged or cause fire, per-

sonal injury or damage due to a leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary re-

fuse and must be returned for recycling purposes. The customer

is responsible for returning the used or rechargeable batteries for

recycling.

•The customer can return used or rechargeable batteries to a

nearby public recycling center or to a store selling the same

type of the battery or rechargeable battery.

Do not place the product in a location exposed to direct sunlight

or near any heat such as a fire or heater.

•This may reduce the lifetime of the product, and may result in

fire.

Do not drop any objects onto the product or cause any impact

to the product.

• Otherwise, this may result in electric shock or fire.

Do not use a humidifier near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power

plug; ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display

panel becomes hot. Do not touch it.

Keep the small accessories in a location out of the reach of chil-

dren.

Be careful when adjusting the angle of the product or the height

of the stand.

•This may result in personal injury as your hand or fingers may

become caught.

•Also,ifyoutilttheproducttoofar,itmayfallandcausepersonal

injury.

Do not install the product in a location low enough for children

to reach.

• Otherwise, it may fall and result in personal injury.

Safety Instructions

•Since the front part of the product is heavy, install the product

on a level and stable surface.

Do not put any heavy objects on the product.

•This may result in personal injury and/or damage to the prod-

uct.

Usingan objectotherthan thesuppliedstylus canleave scratch-

es on the product.

•There is a possibility that using a pen which is too thin (i.e.

ballpoint pen, sharp pencil, PDA pen, etc.) will not be recog-

nized by the touch sensor due to limitations of the device. It is

strongly recommended that you use the supplied stylus pen.

Safety Instructions

Introduction

Package Contents

Checking the Contents of the Package

Remove the lock from the package box, as shown in the figure above.

Lift up the package box by

holding the grooves on

both sides of the package

box.

Check the contents of the

package. Remove the Styrofoam

and vinyl cover.

Note

• After unpacking the package, make sure to check the contents of the package.

• Store the packaging box in case you need to move the Product later.

• If any items are missing, contact your dealer.

• Contact a local dealer to purchase optional items.

Unpacking

LCD Display

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung SyncMaster P2270HD Manuel utilisateur

Samsung

Samsung QM98T Manuel utilisateur

Samsung

Samsung 151MP - SyncMaster 151 MP Manuel utilisateur

Samsung

Samsung SyncMaster C23A750X Manuel utilisateur

Samsung

Samsung SyncMaster 2043BW Manuel utilisateur

Samsung

Samsung SyncMaster 2043WM Manuel utilisateur

Samsung

Samsung Odyssey LC24RG50FZR Manuel utilisateur

Samsung

Samsung SyncMaster B1730NW Manuel utilisateur

Samsung

Samsung ED32D Manuel utilisateur

Samsung

Samsung SyncMaster 933HD Plus Manuel utilisateur

Samsung

Samsung SyncMaster 798MBplus Manuel utilisateur

Samsung

Samsung 932BW - SyncMaster - 19" LCD Monitor Manuel utilisateur

Samsung

Samsung XL2370 - SyncMaster - 23" LCD Monitor Guide de l'utilisateur

Samsung

Samsung SyncMaster 1200NF Manuel utilisateur

Samsung

Samsung SyncMaster 753DF Manuel utilisateur

Samsung

Samsung SyncMaster 773DFX Manuel utilisateur

Samsung

Samsung ML467 series Manuel utilisateur

Samsung

Samsung SyncMaster 920LM Manuel utilisateur

Samsung

Samsung 225UW - SyncMaster - 22" LCD Monitor Manuel utilisateur

Samsung

Samsung 244T - SyncMaster - 24" LCD Monitor Manuel utilisateur

Samsung

Samsung SyncMaster 226UX Manuel utilisateur

Samsung

Samsung SyncMaster 700TSn Manuel utilisateur

Samsung

Samsung SyncMaster 700IFT, 900IFT Manuel utilisateur

Samsung

Samsung VMBL0609CA02HQ-WW Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
