Samsung SyncMaster 720NA Manuel utilisateur

Install drivers Install programs

SyncMaster 720NA

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

Power

When not used for an extended period of time, set your computer to DPMS.

If using a screen saver, set it to the active screen mode.

Image Retention Free

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment damage.

Insert the power plug firmly so that it does not come loose.

zA bad connection may cause fire.

Do not excessively bend the plug and wire nor place heavy objects upon them,

which could cause damage.

zThis may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause fire.

Installation

Be sure to contact an authorized service center, when installing your monitor in a

location with the heavy dust, high or low temperatures, high humidity, chemical

substance and where it operates for 24 hours such as the airport, the train station or etc.

Failure to do so may cause a serious damage to your monitor.

Put your monitor in a location with low humidity and a minimum of dust.

zFailure to do so may cause an electric shock or fire inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Install the monitor base in a showcase or shelf so that the end of the base does

not project beyond the showcase or shelf.

zDropping the product may cause damage to the product or personal injury.

Do not place the product on an unstable or small surface area.

zPlace the product on an even, stable surface, as the product may fall and

cause harm to someone walking by, specifically children.

Do not place the product on the floor.

zSomeone, specifically children could trip over it.

Keep any flammable objects such as candles, insecticides or cigarettes away

from the product.

zOtherwise, this may cause a fire.

Keep any heating devices away from the power cable.

zA melted coating may lead to electric shock or fire.

Do not install the product in places with poor ventilation, for instance, a

bookshelf, closet, etc.

zAny increase in internal temperature may cause fire.

Set down the monitor carefully.

zThe monitor could be damaged or broken.

Do not place the monitor face down.

zThe TFT-LCD surface may be damaged.

Installing a wall bracket must be done by a qualified professional.

zInstallation by unqualified personnel may result in injury.

zAlways use the mounting device specified in the owner's manual.

When installing the product, make sure to keep it away from the wall (more

than 10cm/4inch ) for ventilation purposes.

zPoor ventilation may cause an increase in the internal temperature of the

product, resulting in a shortened component life and degraded performance.

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a

slightly moistened, soft fabric.

Do not spray water or detergent directly on the monitor.

zThis may cause damage, electric shock or fire.

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty, clean it properly

with a dry cloth.

zA dirty connector may cause an electric shock or fire.

Make sure to unplug the power cord before cleaning the product.

zOtherwise, this may cause electric shock or fire.

Unplug the power cord from the power outlet and wipe the product using a

soft, dry cloth.

zDo not use any chemicals such as wax, benzene, alcohol, thinners, insecticide,

air freshener, lubricant or detergent.

Contact the Service Center or Customer Center for interior cleaning once a

year.

zKeep the product's interior clean. Dust which has accumulated in the interior

over an extended period of time may cause malfunction or fire.

zThe quantity of an anion may be decreased.

Other

Do not try to remove the anion cap without referring to qualified service

personnel.

Do not put a pin or wire inside of the anion cap.

zThis may cause static electricity.

zWhen separating the monitor, turn off the power and then contact the Service

Center.

Do not remove cover (or back).

zThis may cause an electric shock or fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are any

unusual sounds or smells coming from it - unplug it immediately and contact

an authorized dealer or service.

zThis may cause an electric shock or fire.

Keep the product away from places exposed to oil, smoke or moisture; do not

install inside a vehicle.

zThis may cause malfunction, an electric shock or fire.

zEspecially avoid operating the monitor near water or outdoors where it could be

exposed to snow or rain.

If the monitor is dropped or the casing is damaged, turn the monitor off and

unplug the power cord. Then contact the Service Center .

zThe monitor may malfunction, causing an electric shock or fire.

Disconnect the plug from the outlet during storms or lightening or if it is not

used for a long period of time.

zFailure to do so may cause an electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal cable.

zThis may cause a breakdown, electric shock or fire due to damage to the

cable.

Do not move the monitor right or left by pulling only the wire or the signal

cable.

zThis may cause a breakdown, electric shock or fire due to damage to the

cable.

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Do not place water containers, chemical products or small metal objects on the

monitor.

zThis may cause malfunction, an electric shock or fire.

zIf a foreign substance enters the monitor, unplug the power cord and contact

the Service Center.

Keep the product away from combustible chemical sprays or inflammable

substances.

zThis may cause an explosion or fire.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Do not insert metal objects such as chopsticks, wire and gimlet or inflammable

objects such as paper and match into the vent, headphone port or AV ports.

zIt may cause a fire or an electric shock. If an alien substances or water flows

into the product, turn the product off, unplug the power connector from the wall

outlet and contact service center.

If you view a fixed screen for an extended period of time, residual image or

blurriness may appear.

zChange the mode to energy save or set a screensaver to moving picture when

you need to be away from the monitor for an extended period of time.

Adjust the resolution and frequency to the levels appropriate for the model.

zInappropriate resolution may cause undesirable picture quality.

17 inch - 1280 X 1024

Watching the monitor continuously at a too close angle may result in eyesight

damage.

To ease eye strain, take at least a five-minute break after every hour of using

the monitor.

Do not install the product on an unstable, uneven surface or a location prone

to vibrations.

zDropping the product may cause damage to the product or personal injury.

Using the product in a location prone to vibrations may shorten the lifetime of

the product or may catch fire.

When moving the monitor, turn off and unplug the power cord.

Make sure that all cables, including the antenna cable and cables connecting to

other devices, are disconnected before moving the monitor.

zFailure to disconnect cables may damage it and lead to fire or an electric

shock.

Place the product out of children’s reach, as they could damage it by hanging

onto it.

zA falling product could cause physical damage even death.

When not using the product for an extended time period, keep the product

unplugged.

zOtherwise, this may cause heat emission from the accumulated dirt or

degraded insulation, leading to electric shock or fire.

Do not place children’s favorite objects (or anything else that may be tempting)

on the product.

zChildren may try to climb on the product to retrieve an object. The product

could fall, causing physical damage or even death.

Please make sure the following items are included with your monitor.

If an

items are missin

, contact

our deale

Unpacking

Monitor

Monito

Bottom

Manual

Quick Setup Guide Warranty Card

(Not available in all locations)

User's Guide,

Monitor Driver,

Natural Color software,

icTune™ software

Cable

D-Sub Cable Power Cord Dedicated Anion Cleaning

Brush

Front

1. Menu button [ ] Use this button for open the on-screen menu and exits from the menu

screen or closes screen adjustment menu.

2. MagicBright™

button [ ] MagicBright™ is a new feature providing optimum viewing environment

depending on the contents of the image you are watching.

Currently four different modes are available: Custom, Text, Internet, and

Entertain.

Each mode has its own pre-configured brightness value. You can easily

select one of four settings by simply pressing MagicBright control buttons.

1) Custom

Although the values are carefully chosen by our engineers, the pre-

configured values may not be comfortable to your eyes depending on

your taste.

If this is the case, adjust the brightness and contrast by using the

OSD menu.

2) Text : Normal brightness

For documentations or works involving heavy text.

3) Internet : Medium brightness

For working with a mixture of images such as text and graphics.

4) Entertain : High brightness

For watching motion pictures such as a DVD or VCD.

>>Click here to see an animation clip

3. Power button [ ] /

Power indicator

Use this button for turn the monitor on and off./

When the monitor is operated normally and the anoin is 'On', blue light

will glow.

When the monitor is operated normally and the anoin is 'Off', green light

will glow.

When the monitor is in energy saving mode, green light will be blinking.

4. Brightness button [ ] When OSD is not on the screen, push the button to adjust brightness.

2,4. Adjust buttons [ ] Use this button for navigate and select menus or adjust the menu items in

the menu screen.

5. Enter button [ ]/

Auto button Activates a highlighted menu item. /

Use this button for auto adjustment.

Table des matières

Autres manuels Samsung Moniteur

Samsung

Samsung SyncMaster 930ND Manuel utilisateur

Samsung

Samsung SAM-21M Manuel utilisateur

Samsung

Samsung SyncMaster 400UX-2 Manuel utilisateur

Samsung

Samsung 931C - SyncMaster - 19" LCD Monitor Manuel utilisateur

Samsung

Samsung SAMTRON 76P Manuel utilisateur

Samsung

Samsung SyncMaster 700S Manuel utilisateur

Samsung

Samsung S22C650P Manuel utilisateur

Samsung

Samsung 570DX - SyncMaster - 57" LCD Flat Panel... Manuel utilisateur

Samsung

Samsung SyncMaster FX2490HD Manuel utilisateur

Samsung

Samsung SyncMaster 460UTn-2 Manuel utilisateur

Samsung

Samsung SyncMaster C24A650X Manuel utilisateur

Samsung

Samsung SyncMaster S23B550V Manuel utilisateur

Samsung

Samsung HP-S4253 Manuel utilisateur

Samsung

Samsung AQ17HS Manuel utilisateur

Samsung

Samsung UltraView iAP3200W Manuel utilisateur

Samsung

Samsung OH24B Manuel utilisateur

Samsung

Samsung S22F35 series Manuel utilisateur

Samsung

Samsung 400UXn-M - 40" LCD Public Info Display Guide de l'utilisateur

Samsung

Samsung SyncMaster C23A750X Manuel utilisateur

Samsung

Samsung SMT-4011 Manuel utilisateur

Samsung

Samsung SyncMaster 540B Manuel utilisateur

Samsung

Samsung 570DX - SyncMaster - 57" LCD Flat Panel... Manuel utilisateur

Samsung

Samsung SyncMaster C23A750X Manuel utilisateur

Samsung

Samsung 400MX - SyncMaster - 40" LCD Flat Panel... Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
