Samsung S19C150F Manuel utilisateur

BN46-00338B-01

User manual

S19C150N

S19C150F

S20C150FL

S22C150N

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols for safety precautions

11 Electricity and Safety

12 Installation and Safety

14 Operation

18 Correct posture to use the product

PREPARATIONS 19 Checking the Contents

19 Removing the Packaging

20 Checking the Components

21 Parts

21 Frontal Button

23 Reverse Side

24 Installation

24 Attaching the Stand (S19C150F / S20C150FL)

25 Attaching the Stand (S19C150N / S22C150N)

26 Removing the Stand (S19C150F / S20C150FL)

27 Removing the Stand (S19C150N / S22C150N)

28 Installing a Wall-mount Kit or Desktop Stand

(S19C150F / S20C150FL)

29 Adjusting the Product Tilt

30 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

31 Before Connecting

31 Pre-connection Checkpoints

32 Connecting the Power

Table Of Contents

Table Of Contents 3

33 Connecting and Using a PC

33 Connection Using the D-SUB Cable (Analogue

Type)

34 Driver Installation

35 Setting Optimum Resolution

36 Changing the Resolution Using a PC

SCREEN SETUP 40 Brightness

40 Configuring Brightness

41 Contrast

41 Configuring Contrast

42 Sharpness

42 Configuring Sharpness

43 SAMSUNG MAGIC Bright

43 Configuring SAMSUNG MAGIC Bright

44 SAMSUNG MAGIC Upscale

44 Configuring SAMSUNG MAGIC Upscale

45 Image Size

45 Changing the Image Size

46 H-Position & V-Position

46 Configuring H-Position & V-Position

47 Coarse

47 Adjusting Coarse

48 Fine

48 Adjusting Fine

CONFIGURING TINT 49 Red

49 Configuring Red

50 Green

50 Configuring Green

Table Of Contents

Table Of Contents 4

51 Blue

51 Configuring Blue

52 Color Tone

52 Configuring the Color Tone Settings

53 Gamma

53 Configuring Gamma

COORDINATING OSD 54 Language

54 Configuring Language

55 Menu H-Position & Menu V-Position

55 Configuring Menu H-Position & Menu V-

Position

56 Display Time

56 Configuring Display Time

57 Transparency

57 Changing Transparency

SETUP AND RESET 58 Reset

58 Initializing Settings (Reset)

59 Eco Saving

59 Configuring Eco Saving

60 Off Timer

60 Configuring Off Timer

61 Turn Off After

61 Configuring Turn Off After

62 Key Repeat Time

62 Configuring Key Repeat Time

63 Customized Key

63 Configuring Customized Key

Table Of Contents

Table Of Contents 5

INFORMATION MENU AND

OTHERS

64 INFORMATION

64 Displaying INFORMATION

65 Configuring Brightness and Contrast in

the Initial Screen

INSTALLING THE

SOFTWARE

66 MagicTune

66 What is "MagicTune"?

66 Installing the Software

67 Removing the Software

68 MultiScreen

68 Installing the Software

69 Removing the Software

TROUBLESHOOTING

GUIDE

70 Requirements Before Contacting

Samsung Customer Service Center

70 Testing the Product

70 Checking the Resolution and Frequency

70 Check the following.

73 Q & A

SPECIFICATIONS 75 General (S19C150N / S22C150N)

77 General (S19C150F / S20C150FL)

79 PowerSaver

80 Standard Signal Mode Table

APPENDIX 83 Contact SAMSUNG WORLD WIDE

89 Responsibility for the Pay Service (Cost

to Customers)

89 Not a product defect

89 A Product damage caused by customer's fault

89 Others

Table Of Contents

Table Of Contents 6

90 Correct Disposal

90 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

91 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

2013 Samsung Electronics

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product.

(i.e. where you have failed to read this user manual)

(b) you bring the unit to a repair centre and there is no defect in the product.

(i.e. where you have failed to read this user manual)

The amount of such administration charge will be advised to you before any work or home visit

is carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor with a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire and

damage the product. Be sure to allow the amount of space as shown below or greater when installing

the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 83) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

3.93

inches

(10 cm)

3.93

inches

(10 cm)

3.93 inches(10 cm)

3.93 inches

(10 cm)

Before Using the Product

Safety Precautions

Symbols for safety precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
