Samsung QBH Series Manuel utilisateur

User Manual



to change without prior notice to improve the performance.

Recommended hours of use per day for the DBJ, QBH, QHH models is less than 16 hours.



DBJ (DB43J DB49J)

QBH (QB65H QB75H)

QHH (QH55H QH65H)

QMH (QM49H QM55H QM65H)

Table of contents

Before Using the Product

Safety Precautions 7

Cleaning 7

Storage 8

Electricity and Safety 8

Installation 9

Operation 11

Preparations

Checking the Components 14

Components 14

Parts 15

Control Panel 15

Reverse Side 19

Anti-theft Lock 22

Remote Control 23

Before Installing the Product (Installation

Guide) 25

Tilting Angle and Rotation 25

Ventilation 25

Installing the Wall Mount 27

 

 

 

Remote Control (RS232C) 30

 

Connection 33

Control Codes 34

Connecting and Using

a Source Device

Before Connecting 42

Pre-connection Checkpoints 42

Connecting to a PC 42

 

 

 

 

Connecting an External Monitor 45

Connecting to a Video Device 46

 

 

Connecting to an Audio System 47

Power cord connection guide 48

Attaching the Network box (Sold separately) 49

Connecting the Network box (Sold

separately) 50

 

Changing the Input source 52

Source 52

 Browser 53

Remote orkspace 54

Using MDC

MDC Programme Installation/Uninstallation 55

Installation 55

Uninstallation 55

Connecting to MDC 56

Using MDC via RS-232C (serial data

communications standards) 56

Using MDC via Ethernet 57

Player feature

Player 59

Viewing content 59

 

 

Player 61

Schedule 66

Clone Product 67

ID Settings 68

Device ID 68

Device ID Auto Set 68

PC Connection C 68

Video Wall 69

Video all 69

Table of contents

Horizontal x Vertical 69

Screen Position 

Format 

Network Status 71

Picture Mode 72

On/Off Timer 73

On Timer 73

Off Timer 74

Holiday Management 74

Ticker 75

URL Launcher 76

URL Launcher Settings 77

Approving a connected device from the server 78

Setting the current time 79



Picture Mode 80

Backlight / Contrast / Brightness / Sharpness /

Colour / Tint (G/R) 81

Colour Temperature 82

White Balance 83

2 Point 83

 Point Settings 83

Gamma 84

HLG / ST. / BT.1886 84

Calibrated value 84

Advanced Settings 85

Contrast Enhancer 85

Black Tone 85

Flesh Tone 85

RGB Only Mode 85

Colour Space Settings 86

HDMI UHD Color 86

Motion Lighting 86

HDR+ Mode 86

Picture Options 87

Colour Tone 87

Digital Clean View 87

HDMI Black Level 88

Film Mode 88

Auto Motion Plus Settings 89

Local Dimming 89

Dynamic Backlight 

Picture Size Settings 91

Picture Size 91

Fit to screen 91

Zoom and Position 91

Reset Picture 92

OnScreen Display

Display Orientation 93

Onscreen Menu Orientation 93

Source Content Orientation 93

Aspect Ratio 93

Screen Protection 94

Auto Protection Time 94

Screen Burn Protection 94

Message Display 97

Source Info 97

No Signal Message 97

MDC Message 97

Download Status Message 97

Language 98

Reset OnScreen Display 98



Sound Mode 99

Balance 100

Equaliser 100

HDMI Sound 100

Sound on Video Call 100

Sound Output 101

Auto Volume 101

Table of contents

Reset Sound 101

Network

Network Status 102

Open Network Settings 102

Network Type 

 

 

Use  

IPv6 107

IPv6 Status 107

Server Network Settings 108

Connect to server 

MagicInfo Mode 

Server Access 

FTP Mode 

Proxy server 

Device Name 108

System

Accessibility 109

High Contrast 

Enlarge 

Start Setup 110

Touch Control 110

Touch Control 

Admin Menu Lock 

Time 111

Clock Set 111

NTP Settings 111

DST 111

Power On Delay 111

Auto Source Switching 112

Primary Source Recovery 112

Primary Source 112

Secondary Source 112

Power Control 113

Auto Power On 113

PC module power 113

Max. Power Saving 113

S Control 114

Network S 114

Power Button 114

Eco Solution 115

Energy Saving Mode 115

Eco Sensor 115

Screen Lamp Schedule 116

No Signal Power Off 116

Auto Power Off 116

Temperature Control 117

External Device Manager 118

 Manager 118

Device Connection Manager 118

Play via 119

Change PIN 119

Security 120

Safety Lock On 

Button Lock 

USB Auto Play Lock 

M Connection Lock 121

Remote Management 121

Secured Protocol 121

Network Port 121

USB Port 121

General 122

Smart Security 122

Anynet+ (HDMI-CEC)122

HDMI Hot Plug 124

Custom Logo 124

Game Mode 125

Empty Storage 125

Irregular Video all 125

Reset System 126

Table of contents

Support

Software Update 127

Update Now 127

Auto update 127

Contact Samsung 127

Reset All 127



Requirements Before Contacting Samsung

Customer Service Centre 128

Testing the Product 128

Checking the Resolution and Frequency 128

Check the followings. 129

Q & A 135

Specifications

General 136

Preset Timing Modes 138

Appendix

Responsibility for the Pay Service (Cost to

Customers) 143

Not a product defect 143



fault 143

Others 143

Prevention of Afterimage Burn-in 144

 

Recommended prevention practices 144

Licence 145

Terminology 146

Before Using the Product





Samsung Electronics owns the copyright for this manual.





VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.



 

– (a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

– 

(i.e. where you have failed to read this user manual).

 

out.

Chapter 01

Safety Precautions

Warning



Caution







Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

The following images are for reference only. Real-life situations may differ from what is

shown in the images.

Power off the product and computer.

Disconnect the power cord from the product.



wet hands. Otherwise, an electric shock may result.



Do not use detergents that contain alcohol, solvent

or surface-active agents.

Do not spray water or detergent directly on the

product.



the exterior of the product.

Connect the power cord to the product when cleaning is

finished.

Power on the product and computer.

Storage



white-coloured stains on the product.

Contact Customer Service Centre if the inside of the product needs cleaning (service fee will



Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is

shown in the images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

An electric shock or fire may result.

Do not use multiple products with a single power socket.

Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric

shock may result.

Insert the power plug all the way in so it is not loose.

An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated

devices only).

 





Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket

with a dry cloth.

A fire may result.

Caution



 



not use the power cord with other products.

A fire or electric shock may result.





 

product when an issue occurs.

 



Hold the plug when disconnecting the power cord from the power

socket.

An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON

TOP OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT

SOURCES.

A fire may result.

Have a technician install the wall-mount hanger.

 

 

Do not install the product in poorly ventilated spaces such as a



An increased internal temperature may cause a fire.



ventilation.

An increased internal temperature may cause a fire.



Children may suffocate.





(insecure shelf, sloped surface, etc.)

 



 

the product or cause a fire.

Do not install the product in a vehicle or a place exposed to dust,

moisture (water drips, etc.), oil, or smoke.

A fire or electric shock may result.



such as a stove.

 

Do not install the product within the reach of young children.

 

 

surface.



not install the product in a kitchen or near a kitchen counter.

Caution

Do not drop the product while moving.

 

Do not set down the product on its front.

 





 



 

Set down the product gently.

 

SAMSUNG

Installing the product in an unusual place (a place exposed to a lot of



presence of moisture, or a place where the product will operate

continuously for an extended period of time) may seriously affect its

performance.

Be sure to consult Samsung Customer Service Centre if you want

to install the product at such a place.
