Samsung SSA-R1001 Manuel utilisateur

Quick Guide

Contents

SSA-R1001

SSA-R1101

Product Introduction

Installation and External Connection

ENG FRE GER SPA ITA

Installation and External Connection2

Product Introduction

WHAT’S INCLUDED

Check if the following items are included in the product package.

What’s in cluded in SSA-R1001

xGn

SSA-R1001

Bezel READER Module

3.5x40mm screws (x2)

3.5x25mm screws (x2)

6x30mm Plastic Anchor (x2)

Quick Guide CD Manual Ferrite Core

QUICK GUIDE

English_3

ENG

QUICK GUIDE

English_3

ENG

What’s included in SSA-R1101

xGn

SSA-R1101

Bezel READER Module

3.5x40mm screws (x2)

3.5x25mm screws (x2)

6x30mm Plastic Anchor (x2)

Quick Guide CD Manual Ferrite Core

Installation and External Connection4

Product Introduction

AT A GLANCE

Front/Rear

QUICK GUIDE

English_5

ENG

QUICK GUIDE

English_5

ENG

LED Displays the system operation status using red and green indicators.

Buzzer Piezo buzzer.

Connection Cable Used to connect to the power or I/O cable.

Fixing Hole Fixing hole for wall-mounting.

Installation and External Connection6

Product Introduction

CABLE COLOR SCHEME

Item Cable Color Signal Line Description

Power Red DC +12V DC +12V supplied

Black GND Earth-grounding for power

Input Blue Buzzer Control BUZZER Control Input Port

Yellow LED Control LED Control Input Port

Output Green Out Wiegand 0 Wiegand Data 0 Output Port

White Out Wiegand 1 Wiegand Data 1 Output Port

Communication Purple RS-232(TX) RS-232 Transmission Output Port

Not used

Gray

NC Not ConnectedBrown

Orange

QUICK GUIDE

English_7

ENG

Installation and External Connection

- Inserted in the doorframe / attached to the wall

Two 6-32 or M3 holes are 3.3” (8.38 cm) away from

each other vertically; between the two exists one 1/2”

hole through which the reader cables are arranged.

The midway hole is located 1.7” (4.31cm) down from

the upper hole.

(If the product is already installed, you can skip the

follow step)

Insert the reader cables to the midway hole and ﬁx the

reader module with two 6-32 or M3 screws.

Insert the reader module into the bezel and push it up

until you hear a click.

INSTALLATION

Wall Mount

Mullion Mount

Electric Gang

Box Mount

Upper

6-32 hole

3.3”

(8.38cm) 1/2”hole

1.7”

(4.31cm)

6-32 hole

6-32 or M3 Screws

Reader

Module

Bezel

6-32 or M3 Screws

Gang Box

Reader

Module

Bezel

Lower

Installation and External Connection

PRECAUTIONS ON INSTALLATION

If installing on a metal wall

If you install the reader on a metal wall, the read range may

be reduced.

To avoid this problem, it is recommended to insert the

spacer between the metal wall and the reader as shown

below.

Metal

Wall

Spacer

Reader

QUICK GUIDE

English_9

ENG

If installing more than one reader side by side or front and back

If you install more than one reader side by side or

front and back, the read range may be reduced. In

this case, if you present a card to one reader, the

other reader may recognize the same card, meaning

both readers read the same card simultaneously.

To avoid this problem, keep at least 20 cm of space

between the two readers.

BACK TO BACK

INSTALLATION

#Reader 2

#Reader 1

Minimum

20cm

#Reader 1

#Reader 2

Minimum

20cm

Installation and External Connection

EXTERNAL CONNECTION

Wiring Diagram

Blue

Yellow

RS-232(GND)

RS-232(TX)

Red Black

Buzzer Control In

LED Control In

DC +12V GND

SSA-R1001/SSA-R1101

Wiegand Data 0 Out

Wiegand Data 1 Out

Green

White

Purple

Black

PCCONTROLLER

POWER
