Samsung LN40A650A1F Mode d’emploi

Network Connection - Wireless

You can connect to the Samsung’s Infolink network wirelessly through a wireless IP sharer.

HDMI IN4

DMI IN

TV Side Panel

Wireless LAN Adapter

for InfoLink

LAN Cable

Wireless IP sharer

The LAN Port on

the Wall

1. Connect the Samsung

Infolink Wireless adapter

into the Wiselink terminal

of the TV.

You must use the Samsung Wireless LAN Adapter for InfoLink(WIS-08BG) to use a wireless network.

The Samsung Wireless LAN Adapter for InfoLink is sold separately. Contact a Samsung Electronics agent or service

center for purchasing.

To use a wireless network, your TV must be connected to a wireless IP sharer.

If the wireless IP sharer supports DHCP, you TV can use a DHCP or static IP address to connect to the wireless

network.

You must use a wireless IP sharer that supports IEEE 802.11 B or IEEE 802.11G.

If the wireless IP sharer allows you to turn on/off the Ping connection function, turn it on.

Set the wireless IP sharer to Infrastructure mode. Ad-hoc mode is not supported.

Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer

is currently being used by another device nearby, this will result in interference and communications may fail.

When applying the security key for the AP (wireless IP sharer), only the following is supported.

1) Authentication Mode : WEP, WPAPSK, WPA2PSK

2) Encryption Type : WEP, TKIP, AES

If you apply a security system other than the systems listed above, it will not work with the TV.

Network selection

Select Cable or Wireless as the method to connect to the Samsung’s Infolink

network.

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select “Setup”, then press the ENTER button.

2. Press the ▲ or ▼ button to select “Network selection”, then press the

ENTER button.

3. Press the ▲ or ▼ button to select “Cable” or “Wireless”, then press the

ENTER button.

Cable: Connect to Samsung’s Infolink network using a cable.

Wireless: Connect to Samsung’s Infolink network wirelessly.

•

The menu is activated only if the Samsung Wireless LAN Adapter for

InfoLink is connected. (See page 107)

➣

•

➣

Setup

Language : English

Time

Networkselection :Cable ►

Cable Network Setup

Wireless Network Setup

V-Chip

Caption

External Settings

Entertainment : Off

Energy Saving : Off

Setup

Language : English

Time

Networkselection :Cable ►

Cable Network Setup

Wireless Network Setup

V-Chip

Caption

External Settings

Entertainment : Off

Energy Saving : Off

Cable

Wireless

Manual Setup

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select “Setup”, then press the ENTER button.

2. Press the ▲ or ▼ button to select “Wireless Network Setup”, then press the

ENTER button.

3. Press the ENTER button to select “Internet Protocol Setup”.

4. Press the ▲ or ▼ button to select “Manual Setup”, then press the ENTER

button.

5. Press the ▲, ▼, ◄ or ► button to move to an item, and press the numeric

button to congure the selected item. Press the ENTER button.

If you want to use a static IP address, refer to the user manual of your

wireless IP sharer.

Select “Access Point Select” to check the network connectivity. (Refer to

page 111)

Press the EXIT button to exit.

➣

Setup

Network selection : Wireless

Cable Network Setup

WirelessNetworkSetup ►

V-Chip

Caption

External Settings

Entertainment : Off

Energy Saving : Off

PIP

SW Upgade

Wireless Network Setup

Internet Protocol Setup : Auto Setup

Network Test

Access Point Select : AP1

IP Address : 0000

Subnet Mask : 0000

Gateway : 0000

DNS Server : 0000

EnterMove Return

Auto Setup

Manual Setup

Cable Network Setup

Internet Protocol Setup : Manual Setup

Network Test

Access Point Select : AP1

IP Address : 0000

Subnet Mask : 0000

Gateway : 0000

DNS Server : 0000

EnterMove Return

Wireless Network Setup

The menu is activated only if the Samsung Infolink Wireless adapter is connected. (See page 107)

Auto Setup

If you connect the LAN cable and it supports DHCP, the Internet Protocol (IP)

Settings are automatically congured.

The wireless IP sharer to be connected to this product must support DHCP.

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select “Setup”, then press the ENTER button.

2. Press the ▲ or ▼ button to select “Wireless Network Setup”, then press the

ENTER button.

3. Press the ENTER button to select “Internet Protocol Setup”.

4. Press the ▲ or ▼ button to select “Auto Setup”, then press the ENTER

button.

The Internet Protocol is set automatically.

Select “Access Point Select” to check the network connectivity.

(Refer to page 111)

Press the EXIT button to exit.

➣

Setup

Network selection : Wireless

Cable Network Setup

WirelessNetworkSetup ►

V-Chip

Caption

External Settings

Entertainment : Off

Energy Saving : Off

PIP

SW Upgade

Wireless Network Setup

Internet Protocol Setup : Auto Setup

Network Test

Access Point Select : AP1

IP Address : 0000

Subnet Mask : 0000

Gateway : 0000

DNS Server : 0000

EnterMove Return

Auto Setup

Manual Setup

Access Point Select

You can select the IP sharer to use when using a wireless network.

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select “Setup”, then press the ENTER button.

2. Press the ▲ or ▼ button to select “Wireless Network Setup”, then press the

ENTER button.

3. Press the ▲ or ▼ button to select “Access Point Select”, then press the

ENTER button.

The wireless Access Points that exist in you area are searched and

displayed in the Access Point List.

4. Press the ▲ or ▼ button to select the Access Point to use. Then press the

ENTER button.

If a wireless Access Point is not in the Access Point list, press the Red

button.

When the connection is made, you will be returned to the screen

automatically.

If you selected an Access Point that requires security authentication,

enter the security key.

You can enter up to 26 characters for a security key.

If you have selected an Access Point with a security authentication:

- The Security Key input screen appears.

- Enter the security key and press the ENTER button.

- Using the Remote Control Buttons on the Security Key Input Screen

Button Operations

Wheel

(▲/▼/◄/►) Moves the selection up/down/left/right.

ENTER Enters (Inputs) the selected character.

RED Switch between Upper- and Lower-Case

Letters

GREEN You can delete an already entered

character.

BLUE Press this button to nish entering the

security key.

➣

Setup

Network selection : Wireless

Cable Network Setup

WirelessNetworkSetup ►

V-Chip

Caption

External Settings

Entertainment : Off

Energy Saving : Off

PIP

SW Upgade

Wireless Network Setup

Internet Protocol Setup : Auto Setup

Network Test

Access Point Select : AP 1

IP Address : 0000

Subnet Mask : 0000

Gateway : 0000

DNS Server : 0000

EnterMove Return

Securty Key _

Number

Lowercase

Delete

Done

0~9

A B C D E F G

I J K L M NH

P Q R S T UO

W X Y ZV

Select ReturnMove

Wireless Network Setup

1~ 9Number

Wireless Network Setup

Access Point Select 1/5

Select Return



AP 1

AP 2 WEP

AP 3

AP 4

Move

Wireless Network Setup

Access Point Select 1/5

Select Return



0016018F0176

ALKO_AP WEP

NESPOT

AP4

Move

Connected

Network Test

You can test or conrm the network connection status after setting up the network.

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select “Setup”, then press the ENTER button.

2. Press the ▲ or ▼ button to select “Wireless Network Setup”, then press the

ENTER button.

3. Press the ▲ or ▼ button to select “Network Test”, then press the ENTER

button.

The current network settings will appear.

If no “Access Point Select” is set up, the test cannot be completed. (See

page 111)

Press the EXIT button to exit.

When unable to connect to a wireless network

1. Your TV may fail to locate an AP that is congured as a private SSID type.

In this case, please change the AP settings and try again.

2. If your Internet service provider has registered the MAC address of the

device used to connect to the Internet for the rst time and authenticates

the MAC address each time you connect to the Internet, your TV may not

be able to connect to the Internet as the MAC address differs from that of

the device (PC) used to connect to the Internet the rst time. In this case,

ask your Internet service provider about the procedures to connect devices

other than your PC (such as your TV) to the Internet.

If you cannot connect to the Internet even if you have followed the procedures

of your Internet service provider, please contact a Samsung Electronics

Service Center.

➣

Network Test

MAC Address

IP Address, Subnet, Gateway, DNS Server

Gateway Ping

Domain Ping

Network Test Completed.

Return

Setup

Network selection : Wireless

Cable Network Setup

WirelessNetworkSetup ►

V-Chip

Caption

External Settings

Entertainment : Off

Energy Saving : Off

PIP

SW Upgade

Wireless Network Setup

Internet Protocol Setup : Auto Setup

Network Test

Access Point Select : AP1

IP Address : 0000

Subnet Mask : 0000

Gateway : 0000

DNS Server : 0000

EnterMove Return
