Samsung LA52A610A3R Manuel utilisateur
LCD TV
quick start guide
imagine the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service, please
register your product at
www.samsung.com/global/register
English - 1
Connections
1.
Connect an HDMI Cable (Not supplied) between the HDMI IN (1, 2, 3 or 4) jack on the TV and the HDMI jack on
the Cable Box/Satellite receiver (Set-Top Box).
No additional Audio connection is needed for an HDMI to HDMI connection.
N
CABLE BOX/SATELLITE
RECEIVER (SET-TOP BOX)
REAR PANEL
TV REAR PANEL
1
CONNECTINg A CABLE BOX/SATELLITE RECEIVER (SET-TOP BOX)
VIA HDMI
Caution
● When connecting an external device, match the colour of the connection terminal to the cable.
● The product colour and shape may vary depending on the model.
● Each Cable Box/Satellite receiver (Set-Top Box) has a different back panel conguration.
● Whenever you connect an external device to your TV, make sure that power on the unit is turned off.
English - 2
CONNECTINg A CABLE BOX/SATELLITE RECEIVER (SET-TOP BOX)
VIA DVI
CONNECTINg A CABLE BOX/SATELLITE RECEIVER (SET-TOP BOX)
VIA COMPONENT CABLES
CABLE BOX/SATELLITE
RECEIVER (SET-TOP BOX)
REAR PANEL
TV REAR PANEL
1
2
TV REAR PANEL
CABLE BOX/SATELLITE
RECEIVER (SET-TOP BOX)
REAR PANEL
12
1.
Connect an HDMI Cable (Not supplied) between the HDMI IN 2 jack on the TV and the HDMI jack on the Cable
Box/Satellite receiver (Set-Top Box).
2.
Connect Audio Cables (Not supplied) between the DVI IN [R-AUDIO-L] jack on the TV and the Cable Box/Satellite
receiver (Set-Top Box).
When using an HDMI/DVI cable(Not supplied) connection, you must use the HDMI IN2 jack.
N
1.
Connect a Component Cable (Not supplied) between the COMPONENT IN (1 or 2) [Y, PB, PR ]jacks on the TV
and the COMPONENT jacks on the Cable Box/Satellite receiver (Set-Top Box).
2.
Connect Audio Cables (Not supplied) between the COMPONENT IN [R-AUDIO-L] jacks on the TV and the AUDIO
OUT jacks on the Cable Box/Satellite receiver (Set-Top Box).
English - 3
Storing Channels Automatically
You can scan for the frequency ranges available to you (and availability
depends on your country). Automatically allocated programme numbers may
not correspond to actual or desired programme numbers. However, you can
sort numbers manually and clear any channels you do not wish to watch.
1.
Press the MENU button to display the menu.
Press the ▲ or ▼ button to select "Channel", then press the ENTER
button.
2.
Press the ENTER button to select "Area".
3.
Select the appropriate country by pressing the ▲ or ▼ button.
Press the ENTER button to conrm your choice.
4.
Press the ▲ or ▼ button to select "Auto Store", then press the ENTER button.
5.
Press the ENTER button.
The TV will begin memorizing all of the available channels.
Press the ENTER button at any time to interrupt the memorization process and return to the "Channel" menu.
6.
After all the available channels are stored, the "Sort" menu appears.
N
N
Troubleshooting
My TV is out of order. Why? Try this.
TV HD is displayed, but
the visual quality is not
good.
• The visual quality may be degraded
when the broadcasting stations convert
the analog signal to digital. (Although
you are watching digital broadcasting,
the video source is analog.)
• Check the transmitting signal of the
corresponding cable TV network or
broadcasting station.
The picture on the
TV screen is broken
intermittently (a mosaic or
distorted).
• This may occur when the broadcast
signal received by the TV is too weak
or unstable.
• Check the transmitting signal of the
corresponding cable TV network or
broadcasting station.
• If you are using a publically shared
antenna, check the signal by asking
your apartment manager.
I cannot control the TV
using the remote control.
• When the battery is at.
• When it is not in TV mode.
• When the remote control malfunctions
temporarily.
• Replace the battery and then retry.
• Press the TV button on the remote
control to select TV mode.
A strange sound is
generated by the TV.
• Sound may be generated by the
temporary swelling and shrinking of the
plastics in the TV due to temperature
and humidity changes.
• Temporary electronic oscillation
sounds may be generated due to the
characteristics of the TV
• Some noise can be heard due to the
characteristics of the product.
Channel
Area :
Asia/W.Europe
Auto Store
Manual Store
Channel Manager
Sort
Name
Fine Tune
Move Enter Return
TV
COUNTRY Customer Care Center
Web Site
AUSTRIA 0800-SAMSUNg (726-7864) www.samsung.com/at
BELgIUM 0032 (0)2 201 24 18 www.samsung.com/be
CZECH REPUBLIC
844 000 844 www.samsung.com/cz
Distributor pro Českou republiku:
Samsung Zrt., česka organizační složka Vyskočilova 4, 14000 Praha 4
DENMARK 70 70 19 70 www.samsung.com/dk
EIRE 0818 717 100 www.samsung.com/ie
FINLAND 030-6227 515 www.samsung.com/
FRANCE 3260 SAMSUNG (€ 0,15/Min)
08 25 08 65 65 (€ 0,15/Min) www.samsung.com
gERMANY 01805 - SAMSUNg (726-7864)
(€ 0,14/Min) www.samsung.com
HUNgARY 06-80-SAMSUNg (726-7864) www.samsung.com
ITALIA 800-SAMSUNg (726-7864) www.samsung.com
LUXEMBURg 0035 (0)2 261 03 710 www.samsung.com/be
NETHERLANDS 0900-SAMSUNG (726-7864) (€ 0,10/Min) www.samsung.com/nl
NORWAY 815-56 480 www.samsung.com/no
POLAND 0 801 801 881
022-607-93-33 www.samsung.com/pl
PORTUgAL 80820-SAMSUNg (726-7864) www.samsung.com/pt
SLOVAKIA 0800-SAMSUNg (726-7864) www.samsung.com/sk
SPAIN 902 10 11 30 www.samsung.com
SWEDEN 0771-400 200 www.samsung.com/se
SWITZERLAND 0800-SAMSUNg (726-7864) www.samsung.com/ch
U.K 0845 SAMSUNg (7267864) www.samsung.com
TURKEY 444 77 11 www.samsung.com
ESTONIA 800-7267 www.samsung.ee
LATVIA 800-7267 www.samsung.com/lv
LITHUANIA 8-800-77777 www.samsung.lt
KAZAHSTAN 8-10-800-500-55-500 www.samsung.kz
KYRgYZSTAN 00-800-500-55-500 -
RUSSIA 8-800-555-55-55 www.samsung.ru
TADJIKISTAN 8-10-800-500-55-500 -
UKRAINE 8-800-502-0000 www.samsung.com
UZBEKISTAN 8-10-800-500-55-500 www.samsung.uz
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care centre.
