Samsung SCS-26UC2 Manuel utilisateur
UbiCell Plus User Guide _1
User Menual
(SCS-26UC2)
2_ © SAMSUNG Electronics Co., Ltd.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-nected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, (example - use only shielded interface cables when
connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this equipment.This device complies
with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation
UbiCell Plus User Guide _3
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the
radiator and your body.This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
4_ © SAMSUNG Electronics Co., Ltd.
SAFETY CONCERNS
The purpose of the Safety Concerns section is to ensure the safety of users and prevent property damage.
Please read this document carefully for proper use.
Conventions/Symbols
Warning
Provides information or instructions that
the reader should follow in order to
avoid personal injury or fatality.
Caution
Indication of a general caution.
Caution
Provides information or instructions that
the reader should follow in order to
avoid a service failure or damage to the
system.
Restriction
Indication for prohibiting an action for a
product.
Note
Indicates additional information as a
reference.
Instruction
Indication for commanding a
specifically required action.
UbiCell Plus User Guide _5
Warning
WARNING
Power
Insert power cord
tightly and fully into the
outlet.
Failure to do so may
cause fire.
Do not touch the
UbiCell Plus or power
plug with wet hands.
Failure to do so may
cause electric shock.
Do not connect many
devices to a single
outlet.
Failure to do so may
cause electric shock.
Pull out the power plug
when the UbiCell Plus is
not used for a long time
or bad weather
condition.
Failure to do so may
cause fire or electric
shock.
6_ © SAMSUNG Electronics Co., Ltd.
Installation/Maintenance
Do not use or
keep flammable
spray or materials
near the UbiCell
Plus.
Failure to do so
may cause fire or
explosion.
Do not install in
humid or dusty
area and near a
heating devices
(heater or light for
cigarette). Install in
the place well
ventilated.
Failure to do so
may cause fire or
electric shock.
Do not put
instruments that
contain water
such as vases,
cups, cosmetics,
and medicines, or
small metals near
the UbiCell Plus.
Moisture in the
UbiCell Plus can
cause a fire and
electric shocks.
Do not put heavy
materials on the
UbiCell Plus.
Failure to do so
may cause the
damage to the
parts of the
UbiCell Plus or
fire.
Turn off the power
and unplug the
power cable, and
then contact the
service center if
unusual sound,
smell, or smoke
comes out.
Failure to do so
may cause fire or
electric shock.
UbiCell Plus User Guide _7
Caution
CAUTION
Installation/Maintenance
Accurately install and
properly use the
product according to
the manual.
This is to prevent
malfunctions and
reductions in product
lifetime.
Do not spray water
directly or do not use
chemical solvents such
as wax, benzene,
alcohol, thinner,
mosquito spray,
aerosol, lubricant, and
detergent.
Failure to do so may
cause the damage to
the product.
Do not install the
UbiCell Plus on an
unstable surface or near
the direct rays of
sunlight.
It may cause severe
damage to the parts of
the UbiCell Plus, and
your UbiCell Plus may
not work properly.
Do not separate, repair
or remodel the UbiCell
Plus arbitrarily.
If a repair is needed,
please contact where
the UbiCell Plus was
purchased or call the
Service Center.
8_ © SAMSUNG Electronics Co., Ltd.
Installation/Maintenance
Do not place the
product on unstable
support and always be
in an upright position.
This is to protect the
product from falling and
damage from the rise of
inside temperature.
Do not give a shock to
the UbiCell Plus.
The UbiCell Plus can be
damaged.
Do not cover the
UbiCell Plus.
Doing so may cause
product malfunction
resulting from the rise of
inside temperature.
Do not install the
UbiCell Plus near the
products which release
electromagnetic waves
such as microwaves,
hair driers or vacuum
cleaners.
If they are too close,
GPS signalcan not be
normally received.
UbiCell Plus User Guide _9
Installation/Maintenance
Clean the UbiCell Plus
with a soft and dry cloth
when cleaning.
Failure to do so may
cause the damage to
the product.
Check the maximum
length of the cable
and install it near the
router.
Failure to do so may
cause malfunction of
this product.
The UbiCell Plus must
be placed more than
50cm apart from the
other LAN devices.
RF signal interference
may have a bad effect
on the other LAN
devices.
Please use a refined
accessory and a
charger provided or
activated by Samsung
Electronics.
The use of another
accessory and a
charger may cause the
critical damage to the
product.
10_ © SAMSUNG Electronics Co., Ltd.
Installation/Maintenance
Install the product in an area with
good ventilation. Install the
UbiCell Plus at a distance of
more than 30 cm from the walls
or other products.
Not doing so may cause product
malfunction resulting from the rise
of inside temperature.
Ethernet cable connector (RJ-45)
should be plugged before
plugging a DC power cable.
Not doing so may cause product
malfunction.
When detaching the GPS
antenna from the UbiCell Plus to
receive superior GPS signal,
connect extension cable to GPS
antenna after pulling out the
power plug.
Failure to do so may cause the
damage to the product.
