DIGITAL VIDEO RECORDER

SHR-1040/SHR-1040K User’s Manual

English Français Spanish

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘`i

English

SHR-1040/1040K USER’S MANUAL

Please be sure to keep the following in mind for the right use of the product to

pre-vent proprietary risk or damage.

■Do not use multiple plugs at once.

●This may cause abnormal heat generation or fire

■Do not put a vase, flowerpot, cup, cosmetics, medicine, or vessel

with water around you.

●This may cause fire.

■Do not bend the power cord forcibly nor put a heavy material on it.

●This may cause fire.

■Do not touch the power plug with wet hands.

●This may cause electric shock.

■Insert the power plug firmly enough not to shake.

●This imperfect connection may cause fire.

■Keep the product off humidity, dust, or soot.

●This may cause fire or electric shock.

■Do not put metals(coin, hair pin, metal piece, etc.) or inflammable

materials(match, paper, etc.) in the ventilation hole.

●This may cause fire.

■Keep the surrounding temperature between 32˚F to 104˚F and keep

the product off humidity.

●This may cause breakdown.

■Secure sufficient ventilation.

●This may cause abnormal operation due to high temperature.

■Keep the product off direct ray of light or heat from the heating

device

●This may cause fire.

■Do not disassemble, repair, or remodel the product.

●This may cause fire, electric shock, or injury due to abnormal operation.

■Do not pull out the power cord.

●This may destroy the power cord, eventually, cause fire or

electric shock.

■Plug out in the event of thunder or lightning.

●This may cause fire.

■Keep your children off the battery after you take it out of the product.

They tend to swallow it unconsciously.

●If your children swallow it, please see the doctor immediately.

■Install the product at a safe place or attach the product to the wall or

ceiling with a stand firmly enough not to fall to the ground.

●This may injure people.

Safety Regulations

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘`ii

English

iii

WAR I G

[Battery]

As wrong exchange of the battery in SHR-1040 may cause explosion, you shall use

the certified battery for SHR-1040.

The battery specification is as follows.

-Normal Voltage : 3V

-Normal Capacity : 220mAh

-Continuous Standard Load : 0.2mA

-Operating Temperature : -22˚F ~ +140˚F

Before we start

Standards Approvals

ote :

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance whit the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense.

This User’s Manual describes the basic usage of SHR-1040.

This Manual contains all the matters necessary for using SHR-1040 such as brief

instruction, part name, function, connecting other equipment, and menu setup of

SHR-1040.

- SEC retains the copyright on this User’s Manual.

- This User’s Manual cannot be copied without SEC’s prior written approval.

- We are not liable for any or all losses to the product incurred by your use of

non-standard product or violation of User’s Manual.

- If you want to open the system case to touch the inside, please consult with an

expert who works for the shop where you bought the product.

- You may download open source codes from the following website.

(See CCTV Part of http://www.sec.co.kr)

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘`iii

English

Safety Regulations

Before we start

Standards Approvals

Chapter 1. Overview

1. Introduction

2. Features

3. Part Names and Functions

4. Remote Controller

Chapter 2. Installation

1. Installation Environment Setup

2. Checking Product & Accessory

3. HDD Addtion

Chapter 3. DIY Carmera

1. Standard Camera

2. Nightvision Camera

Chapter 4. Connecting with Other device

1. Connecting the Video, Audio, and Monitor

2. Connecting the Alarm Input/Output

Chapter 5. Basic Operation

1. System Operation

2. Live Screen Mode

3. Key Functions

3.1. Channel Key & Mode Key

3.2. Pip Key

3.3. Zoom Key

3.4. Freeze Key

3.5. Sequence Key

3.6. Alarm Key

Contents

iii

1-1

1-2

1-3

1-6

2-1

2-2

2-3

3-1

3-5

4-1

4-2

5-1

5-2

5-3

5-4

5-5

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘`iv

English

Chapter 6. Menu Setup

1. Main Setup Menu

2. Clock/Display Setup

3. Record Mode Setup

4. Title Setup

5. Dwell Time Setup

6. Alarm Setup

7. Event Record Mode Setup

8. Timer Record Setup

9. System Setup

10. System Information

Chapter 7. Recording

1. Basic Recording

2. Timer Recording

3. Motion Recording

4. Alarm Recording

5. Stop Recording

Chapter 8. Search & Playback

1. Search Menu

2. Date Time Search

3. Record Event Search

4. Alarm Event Search

5. Loss Event List

6. Power Event List

7. Basic Playback

Chapter 9. Appendix

1. Product Specification

2. Recommended HDD List

3 .Outline Drawing

6-1

6-2

6-3

6-4

6-5

6-6

6-7

6-9

6-10

6-14

7-1

7-2

7-3

8-1

8-2

8-3

8-4

9-1

9-4

9-5

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘`v

Chapter 1. Overview

English

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘`1

SHR-1040/1040K USER’S MANUAL

1-1

English

Introduction

The SHR-1040 digital video recorder is a digital video recorder that records and plays back

video and audio input from four cameras. It records and plays back each channel of video data

in MPEG4 format, and audio data in installed HDD format, by using the G-723 compression

standard.

●DVR is a digital device that stores video and audio data by using a hard disk drive, unlike a

video cassette recorder using video tapes. DVR enables users to easily play back and

search stored data, and edit and send data which are stored in digital signal format.

Users can compress, store and send moving images, and search listings on an hourly or

daily, camera unit and event basis by using this DVR with standard video and data com-

pression technology.

SHR-1040/1040K USER’S MANUAL

1-1

English

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘ ` 1-1

1-2

English

■Adjusts recorded data in three steps.

- HIGH, NORMAL, LOW

■Adjusts the number of record fields per second.

- NTSC : 1~ MAX 30 IPS

■Records before-event (Alarm or Motion) data based on pre-set hours. (Pre-Alarm)

- 0 ~ 5SEC

■Audio-records and plays back selected channels.

■Offers a timer used for time record.

■Records video and audio with alarm.

■Offers various playback speeds.

■Offers easy-to-use search functions.

- Date & Time Search, Event(Record, Alarm, Motion, Timer) Search

■Instantly pauses the current screen. (FREEZE)

■Offers 2X Zoom for video images monitored or played back by the user.

■Offers a variety of screen split modes.

- Full Screen Display, 4 Split Display, Sequence Display, PIP Display

■Allows the user to enjoy audio and video over a PC monitor through VGA Out.

Features

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘ ` 1-2

SHR-1040/1040K USER’S MANUAL

1-3

English

No. Name Function

SHR-1040/1040K USER’S MANUAL

Power LED

HDD LED Displays Normal Access to HDD. Upon Access to HDD, LED

repeats on and off.

Displays power On/Off condition.

Alarm LED lights on when an event occurs.

Rec LED Displays the record condition.

...

1 4

MODE

PIP

CH1, CH2,

CH3, CH4

The screen is switched to Single Mode when each channel

key is pressed during live programming, and the screen of

the channel is displayed in Full Screen.

During initial booting, the screen is displayed in four split.

When the Mode Key is pressed, the screen is switched to

single or split screen.

Enters the date/time of video and audio signals recorded in HDD,

select events from the RECORD and ALARM EVENT SEARCH,

and views the POWER EVENT LIST and LOSS EVENT LIST.

Displays the MAIN MENU, and exits the MENU Screen by

pressing the button again.

Enters the PIP Mode when the PIP Button is pressed in the

Single Screen. There must be two or more input channels.

(1) PIP is enabled when the sequence of the Single Screen

(Main Screen) is turned off.

(2) The Main Screen moves to Channel 1, 2, 3 and 4 in

sequence when the up/down or left/right button is pressed.

(3) Main-Sub switching: The screen is switched when the Enter

Button is pressed in the PIP Screen while the Sequence is

turned off.

Screen Split

Selection Button

PIP

[SHR-1040]

Part Names & Function

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘ ` 1-3

1-4

English

No. Name Function

RECORD

ALARM

ZOOM

SEQUENCE

FREEZE

You can view X2 screen by pressing the ZOOM Button in

the single screen.

When you press the up/down and the left/right key in the

Zoom screen, the selected Zoom Area moves. Press the

Enter button to view X2 Zoom Screen of the selected area.

Press the Freeze Button to freeze the current displayed

screen, and press the Freeze Button again to cancel the

Freeze.

The Freeze marker is displayed on top of the screen in

Freeze Mode.

In Normal Record Mode, video signals are recorded.

When pressing the Sequence Button in the Single Screen,

the screen is switched to each channel with video In.

When the Alarm Button is selected, the Alarm is canceled.

FREEZE

SEQUENCE

ALARM

ZOOM

➛



❿

❷

➛

Fast/Step

Reverse

STOP

PLAY/PAUSE

Fast/Step

Forward

Fast Reverse: Used for fast search in reverse direction

playback.

Step Reverse: Used for cut-by-cut search in reverse

direction during pause.

Ends search during playback and recording.

Operates in toggle for play/pause during playback.

Fast Forward: Used for fast search in forward direction

during playback.

Step Forward: Used for cut-by-cut search in forward

direction during pause.

Direction key used to set the details of the Menu.

Used to increase the value of setting, or direction key used

to set the details of the Menu.

Direction key used to set the details of the Menu.

Used to decrease the value of setting, or direction key used

to set the details of the Menu.

Plays the role of Enter Key when setting the Menu.

SHR-1040/SHR-1040K-ENG 2006.4.4 11:12 AM ˘ ` 1-4

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Samsung DVR

Samsung

Samsung HRD-1642 Guide d'installation

Samsung

Samsung iPOLIS SRN-470D Manuel utilisateur

Samsung

Samsung SRN-473S Manuel utilisateur

Samsung

Samsung SPR-7116 Instructions d'installation

Samsung

Samsung SRD-873D Manuel utilisateur

Samsung

Samsung SRN-3250 Manuel utilisateur

Samsung

Samsung DVD-R3000 Manuel utilisateur

Samsung

Samsung SHR-1041 Manuel utilisateur

Samsung

Samsung SRN-473S Guide d'installation

Samsung

Samsung SVR-1620 Manuel utilisateur

Samsung

Samsung SRD-470 Manuel utilisateur

Samsung

Samsung SRD-1650D Manuel utilisateur

Samsung

Samsung SRD-443 Manuel utilisateur

Samsung

Samsung SHR-2080 Manuel utilisateur

Samsung

Samsung SVR-470 Manuel utilisateur

Samsung

Samsung SVR-3200 Manuel

Samsung

Samsung SVR-1630 Manuel utilisateur

Samsung

Samsung DCB-P850Z(S) Manuel utilisateur

Samsung

Samsung SDH-P4080 Manuel utilisateur

Samsung

Samsung SHR5160500 - Electronics Gvi - Dvr 16ch Mpeg4 120ips Real... Manuel utilisateur

Samsung

Samsung SHR-2160 Manuel utilisateur

Samsung

Samsung SRD-480D Manuel utilisateur

Samsung

Samsung 4 channel DVR Manuel utilisateur

Samsung

Samsung SHR-3040 Manuel utilisateur

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

Speco

Speco D8HU Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur
