Samsung DeX Pad Manuel utilisateur

www.samsung.com

User Manual

02/2018. Rev.1.0

DeX Pad

EE-M5100

Table of Contents

English (UK)

Français

Deutsch

Italiano

Español

Magyar

Polski

Română

Български

Hrvatski

Srpski

Português

Latviešu

Lietuvių kalba

Eesti

Nederlands

Svenska

Norsk

Suomi

Dansk

Ελληνικά

Slovenščina

Slovenčina

Čeština

Türkçe





Русский

Українська

Қазақ тілі

English (USA)

Español (Castellano)

简体中文

繁體中文(台灣)

Français (Canada)

Português (Brasil)

한국어

Getting started

Introduction

With the multimedia dock, you can use your mobile device’s features on a wider screen by

connecting a TV or monitor. You can also connect with nearby devices, such as a keyboard or

mouse.

English (UK)

Getting started

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Images may differ in appearance from the actual product. Content is subject to change

without prior notice.

•

You can use the multimedia dock only on supported mobile devices running Android

8.0 or higher. You can view the compatible devices in the introduction section for the

multimedia dock on the Samsung website.

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

English (UK)

Getting started

Package contents

Check the product box for the following items:

•

Multimedia dock

•

HDMI cable

•

USB cable

•

USB power adaptor

•

Quick start guide

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible

with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

English (UK)

Getting started

Device layout

USB port

Charger port

(USB Type-C)

Fan vent

Surface

HDMI port

Fan vent

Mobile device

connector

(USB Type-C)

When you connect the charger to the multimedia dock’s charger port (USB Type-C),

be sure to use a USB Type-C cable. If you connect a Micro USB cable, the multimedia

dock may malfunction or be damaged.

English (UK)

Using the multimedia dock

Connecting the multimedia dock and a mobile

device

1 Connect the charger to the multimedia dock’s charger port (USB Type-C).

Use only Samsung-approved chargers that support the fast charging feature

(9 V/1.67 A, 9 V/2 A, 12 V/2.1 A).

•

To save energy, unplug the charger when not in use. The charger does not have a

power switch, so you must unplug the charger from the electric socket when not in

use to avoid wasting power. The charger should remain close to the electric socket

and easily accessible while charging.

•

Remove your mobile device from the multimedia dock when it is not in use.

Otherwise, your mobile device’s battery will drain.

•

The socket-outlet shall be installed near the equipment and shall be easily

accessible.

English (UK)

Using the multimedia dock

2 Connect one end of an HDMI cable to the multimedia dock’s HDMI port, and plug the

other end of the cable into a TV or monitor’s HDMI port.

Use only the HDMI cable supplied with the multimedia dock. Otherwise, the

multimedia dock may not work properly.

English (UK)

Using the multimedia dock

3 Connect the mobile device’s multipurpose jack to the mobile device connector (USB

Type-C) on the multimedia dock.

Mobile device

connector

(USB Type-C)

•

Ensure that the mobile device is horizontal to the connector. Otherwise, the

multimedia dock and the mobile device may be damaged.

•

If you connect your mobile device with a case attached, it may not correctly

connect to the multimedia dock or run SAMSUNG DeX properly depending on

your mobile device’s case. Remove the case before use.

For some mobile devices, only the normal charging mode is available when your

mobile device is turned off. If you want to activate the fast charging feature, activate

it when the mobile device is on or connect your mobile device directly to the

Samsung-approved fast charger, not the multimedia dock. When charging, use only

the Samsung-approved charger that is provided on purchase.

English (UK)

Using the multimedia dock

4 Select the screen mode you want to use. You can select Samsung DeX mode or Screen

mirroring mode.

•

START SAMSUNG DeX

: The mobile device’s screen will turn off and appear on the

connected TV or monitor in desktop mode.

•

SWITCH TO SCREEN MIRRORING

: The same screen as the mobile device will appear

on the connected TV or monitor.

Samsung DeX mode Screen mirroring mode

•

The screen mode you first select will be applied for subsequent connections. Refer

to Changing screen mode for more information.

•

If you want to use a keyboard or a mouse, connect them using the multimedia

dock’s USB ports or via Bluetooth. Refer to Controlling with an external keyboard

and mouse for more information.

•

The available features may vary depending on the mobile device. You can view

more information in the introduction section for the multimedia dock on the

Samsung website.

English (UK)
