Samsung NX300 Manuel utilisateur

DIGITAL CAMERA CONTENTS

SERVICE

Manual

1. Repair information

2. Product specifications

3. Disassembly and reassembly

4. Troubleshooting

5. PCB diagram

6. Block diagram

7. Firmware update

8. Adjustment

9. Exploded view and parts list

NX300

DIGITAL CAMERA

Contents

1. Repair information

1-1 Customer satisfaction statement..........................................1-1

1-2 Warranty and repair service information............................... 1-1

1-3 Precaution for disassembly and reassembly......................... 1-4

2. Product specifications

2-1 Specifications ..................................................................... 2-1

2-2 Product comparison ............................................................2-2

2-3 Accessories information ...................................................... 2-3

2-4 About the memory card .......................................................2-5

2-5 About the battery ................................................................2-6

3. Disassembly and reassembly

3-1 Disassembly ....................................................................... 3-1

3-2 Reassembly...................................................................... 3-20

4. Troubleshooting

4-1 Regarding to memory card recognition ................................ 4-1

4-2 Regarding to MAIN PCB connection ................................... 4-2

4-3 Regarding to TOP ..............................................................4-3

4-4 Regarding to image display .................................................4-4

4-5 Regarding to voice playback and recording .......................... 4-4

5. PCB diagram

5-1 MAIN PCB ..........................................................................5-1

5-2 CIS PCB............................................................................. 5-1

5-3 BACK PCB .........................................................................5-2

5-4 TOP PCB............................................................................5-2

5-5 HOT SHOE PCB .................................................................5-3

5-6 TILT PCB............................................................................ 5-3

6. Block diagram

6-1 Block diagram.....................................................................6-1

Contents

7. Firmware update

7-1 Factory data reset...............................................................7-1

7-2 Firmware update by using user menu .................................. 7-4

7-3 Firmware update by using CS menu .................................... 7-6

7-4 How to recover the MAIN PCB.............................................7-9

8. Adjustment

8-1 Adjustment items ................................................................8-1

8-2 Test Mode...........................................................................8-2

8-3 CIS TILT Adjustment ...........................................................8-3

8-4 CIS DOT Data Input & SHUTTER Adjustment....................... 8-4

8-5 ISO Adjustment................................................................... 8-9

8-6 AWB Adjustment .................................................................8-9

8-7 VFPN & CMOS Defact Adjustment ..................................... 8-10

8-8 Color Shading Adjustment ................................................. 8-11

8-9 Country setting (Wi-Fi) ...................................................... 8-12

8-10 S/N, Mac address Input ................................................... 8-12

8-11 PAF (Phase AF) Adjustment............................................. 8-13

8-12 NFC Tag Information Record ........................................... 8-15

8-13 Adjustment data Image Storage ....................................... 8-18

9. Exploded view and parts list

9-1 ASSY BODY .......................................................................9-1

9-2 ASSY MAIN ........................................................................9-3

9-3 ASSY CHAMBER ................................................................9-5

9-4 ASSY COVER TOP ............................................................. 9-6

9-5 ASSY FPCB_HOTSHOE...................................................... 9-7

9-6 ASSY SPEAKER .................................................................9-8

9-7 ASSY COVER BACK ........................................................... 9-9

9-8 ASSY BACK...................................................................... 9-10

9-9 ASSY TILT LCD ................................................................ 9-12

9-10 ASSY CMOS................................................................... 9-13

9-11 ASSY LCD SUB............................................................... 9-14

Precautions

ⓒ

1-1

1. Repair information

1-1 Customer satisfaction statement

1-2 Warranty and repair service information

■

Combining perfect technical solutions with a customer-oriented approach is our top priority.

■

We treat our customers we serve with kindness, loyalty, respect and dignity.

■

We are committed to earn customers’ trust continuously through excellence in repair solutions.

■

We keep our promises and commitments to our customers.

■

Committed to quick and easy resolution of all support issues, we deliver industry-leading

response times.

[Guide]

We listen carefully to our customers' requirements and always nd an optimum solution for their needs.

We are committed to your satisfaction and have procedures in place to provide you with a fair, timely and effective means to resolve problems. It

combines industry leading preventive assistance with responsive support that helps us address problems quickly and effectively.

We will continuously maintain and improve our services to satisfy the needs of our customers.

We hold ourselves to the highest standards of customer satisfaction and service.

(1) General terms and conditions

It is guaranteed to be free of charge from defects in material and workmanship under normal use for a period

of one year from date of purchase.

Digital Camera and lens come with a one year limited warranty from the date of purchase.

* The duration of the warranty depends on the laws in the country in which it was purchased.

The following information will be required to process warranty requests:

a. We imply warranties to one year from the original date of purchase. In the event that the purchaser is

unable to provide a warranty card or proof of purchase, the warranty period will be determined by the

date of manufacture. The warranty period shall be decreased to three months from the original product

manufactured date.

b. The coverage under this warranty begins on the date of your purchase of the product. In the event

that a warranty card or proof of purchase is not available, a purchase receipt, preferably the purchase

invoice, to conrm the date of purchase is required for warranty service.

c. In the event that a valid date of purchase is not available, the warranty period will be determined by

the date of manufacture. The warranty period shall be decreased to three months from the original

product manufactured date.

Precautions

1-2

ⓒ

(2) Limited Warranty

It reserves the right to retain any parts or components replaced at its discretion in the event of a defect no-

ticed in the product. The period with respect to retaining components may vary respectively depending on its

components. We are not liable to repair or replace its faulty product after the Warranty Period has expired.

* We warrant its retaining camera and lenses for ve years and three years for the accessories.

a. If a warranty claim is led after the product has been discontinued, we reserves the right to honor the

components warranty. Warranty period may vary depending on the type of components.

b. In the event that no identical warranty information is available for service repair, company has the right to provide warranty.

The warranty does not affect the consumers' rights against the company related to its information.

For the length of the period indicated on the chart below, it starts with the date of original purchase.

Part Name Warranty Period

Battery Charger

Six months

AC Adaptor

Battery

Remote Control

CD Software Three months

Earphone

Pouch for camera Not applicable

Cable

(3) Warranty Period for components

Our liability under this warranty shall be limited to the following:

a. In the event of a same malfunction problem within two months after repair service by Samsung authorized technician,

we will repair or replace free of charge the component of the product which is found to be defective.

b. In the event of the component that you have paid the replacement cost is returned under normal use within one year at our premises,

such components will be replaced free of charge component of the product which is found to be defective.

Precautions

ⓒ

1-3

Types of consumer damages Compensation

Failing to perform or

failing to function properly

under normal use

Required for essential repair within 10 days

after the purchase

Replace the prod-

uct or refund -

Required for essential repair within one

month after the purchase

Replace the

product or repair

at free of charge

Repair charges

Applicable

to repair

Problem occurred twice

due to same malfunction Free of charge

Problem occurred three

times due to same

malfunction

Replace the prod-

uct or refund

Repair charges

Problem occurred four

times due to some other

malfunction

Not applicable

to repair

Within the period with

respect to retaining

components

Replace the product at the cost of the

depreciated value or refund its price

added 10% of depreciation

Failing to perform or

failing to function properly

as a result of willful intent

and negligence of

customer

Applicable repair Repair charges

Not applicable to repair

(Except for defects or malfunction as a result

of re or ood or other natural disasters

Replacement

charge

Repair charge and replace the prod-

uct at the cost of the depreciated value

(4) Repair Claims

1) Repair free of charge

Essentially, the following causes of damage are covered:

a. Failing to function properly under normal use during the limited warranty period.

b. Repair Services free of charge is granted for the performance of a specic contract.

2) Repair charges

This warranty does not cover damage caused by:

a. Defect occurring after the expiration of the Warranty Period.

b. Damage due to negligence, immersion in water, impact, loss and tampering.

c. Repair or alteration performed by any party other than Samsung authorized technicians.

d. Misuse or other improper use of the power button.

e. Exhausted parts such as batteries, lamps and lters, etc.

f. Defect that occurs due to sand, dirt liquid, etc. entering the inside of the product casing.

g. Consumable parts which have ceased working through normal use such as as earphone, battery discharger and various accessories.

h. Products purchased second hand or any damage that occurs due to a second hand or repair performed

by anyone other than Samsung or a Samsung authorized service station.

i. Fire, earthquake, ood or other natural disasters.

The warranty cover period for components is listed below as per table 1-2.

Precautions

1-4

ⓒ

1-3 Precaution for disassembly and reassembly

Component Precautions

FPCB FPCB is brittle material. It can be easily damaged thus it should be handled with care.

It is recommended to use wooden or plastic tweezers for manual placement.

CCD (CMOS)

IR CUT Filter

LCD, LENS

Be careful not to stained your nger. It is recommended to use wooden or plastic tweezers

for manual placement. Stain is often caused by the Alcohol used in these components.

Find a clean, well-ventilated place to do your work.

PCB Use an anti-static mat as well as an anti-static wrist strap to avoid ESD damage to PCB.

CONNECTOR The use wooden or plastic tweezers is recommended for manual placement.

Metal tip tweezer might make marks or damage.

BARREL Always follow proper direction while assembling the components of the barrel.

1. Use the anti-static handing procedures included with the anti-static mat to ensure that there is no electrostatic

discharge and component damage.

2. Static electricity is the biggest danger to the PCB parts you are about to disassemble or assemble. It’s important

to use your anti-static wrist strap to prevent damage to these components.

3. Dismantling a discrete electronic component such as main capacitor is dangerous.

The capacitor contains high voltage, which can cause a severe electric shock if you touch it. This holds a

charge even when the unit is not plugged in and is capable of delivering a fatal shock.

4. Using excessive force during disassembly and assembly can damage locking parts. Use care when handling

“Locking parts” to avoid damage to FPCB or wire. Apply pressure only at the points designated in the maintenance

instructions.

5. Due to increasing environmental concerns, a number of restrictions have been placed on the material content

of electronic components and electronic assemblies. It requires utilizing Lead-Free (Pb-free) Soldering.

6. The following precautions must be observed when handling such components below.

CAUTION

Precautions

ⓒ

1-5

Product specications

ⓒ

2-1

2. Product specifications

2-1 Specifications

Image Sensor

Type(size) CMOS(23.5 X 15.7mm)

Effective/ Total pixels Approx. 20.3 mega-pixels/ Approx. 21.6 mega-pixels

Lens Mount

Type/ Available lens Samsung NX Mount/ Samsung lenses

Image Stabilization

Type/ Mode Lens shift (depends on lens)/ Off/Mode 1/Mode 2

i-Function

ⓘdepth, ⓘzoom (X1.2, 1.4, 1.7, 2.0)

Dust Reduction

Type Super sonic drive

Display

Type/ Size AMOLED with Touch Panel (C-type Touch Control Enabled) 3.31” (Approx. 84.0 mm)

Resolution WVGA (800X480) 768 k dots (PenTile)

Shutter

Type Electronically controlled vertical-run focal plane shutter

Speed

• Auto: 1/6,000–30 sec.

• Manual: 1/6,000–30 sec. (1/3 EV Step)

• Bulb (time limit: 4 min)

Flash

Type External Flash (Bundle with SEF8A)

Angle of view 28mm (35mm lm equivalent)

White Balance

Mode Auto WB, Daylight, Cloudy, Fluorescent White, Fluorescent NW, Fluorescent Daylight, Tungsten,

Flash WB, Custom Set, Color Temperature(Manual)

Micro adjustment Amber/Blue/Green/Magenta 7 steps respectively

Storage

External memory (optional): SD card, SDHC card, SDXC card, UHS-1 card (Class 6 and above recommended)

GPS

Type Geo-tagging with an optional GPS Module

(WGS 84)

Feature Location name (English and Korean only)

Wireless network

Function MobileLink, Remote Viewnder, Auto Backup, Email, SNS & Cloud, AllShare Play, AutoShare, Wi-Fi Direct

Interface

Digital output USB 2.0 (micro USB jack)

Video output NTSC, PAL (selectable)

HDMI 1.4a

Power Source

Type Rechargeable battery: BP1130 (1130 mAh)

Dimensions (W X H X D)

122 X 63.7 X 40.7 mm (without protrusions)

Weight

284 g (without battery and memory card)

Product specications

2-2

ⓒ

2-2 Product comparison

NX300 NX200


Image Sensor 23.5 X 15.7 mm CMOS 23.5 X 15.7 mm CMOS

Effective Pixels Approx. 20.3 mega-pixels Approx. 20.3 mega-pixels

Total Pixels Approx. 21.6 mega-pixels Approx. 21.6 mega-pixels

Weight 284 g (without battery and memory card) 220.4g (without battery and memory card)

Dimensions

(W X H X D) 122 X 63.7 X 40.7 mm (without protrusions) 116.5 X 62.5 X 36.6 mm (without protrusions)

Display

AMOLED with Touch Panel (C-type Touch Control Enabled)

3.31” (Approx. 84.0 mm)

AMOLED

3.0” (

Approx.

7.6 cm)

Focusing Phase Detection & Contrast AF Contrast AF

Angle of View 28 mm (35 mm lm equivalent) 28 mm (35 mm lm equivalent))

Shutter Speed

- Auto: 1/6,000–30 sec.

- Manual: 1/6,000–30 sec. (1/3 EV Step)

- Bulb (time limit: 4 min)

- Auto: 1/4000-30 sec.

- Manual: 1/4000-30 sec. (1/3 EV Step)

- Bulb (time limit: 4 min)

ISO

1 Step: Auto, ISO 100, ISO 200, ISO 400, ISO 800,

ISO 1600, ISO 3200, ISO 6400, ISO 12800, ISO 25600

1/3 Step: Auto, ISO 100, ISO 125, ISO 160,

ISO 200, ISO 250, ISO 320, ISO 400, ISO 500,

ISO 640, ISO 800, ISO 1000, ISO 1250, ISO 1600,

ISO 2000, ISO 2500, ISO 3200, ISO 4000, ISO 5000,

ISO 6400, ISO 8000, ISO 10000, ISO 12800, ISO 25600

-1 Step: Auto, ISO 100, ISO 200, ISO 400, ISO 800,

ISO 1600, ISO 3200, ISO 6400, ISO 12800

-1/3 Step: Auto, ISO 100, ISO 125, ISO 160, ISO 200,

ISO 250, ISO 320, ISO 400, ISO 500, ISO 640,

ISO 800, ISO 1000, ISO 1250, ISO 1600,

ISO 2000, ISO 2500, ISO 3200, ISO 4000, ISO 5000,

ISO 6400, ISO 8000, ISO 10000, 12800

Storage

External memory (optional):

SD card, SDHC card, SDXC card, UHS-1 card

(Class 6 and above recommended)

External memory (optional):

SD card , SDHC card, SDXC card

Image Stabilization Lens shift (depends on lens) Lens shift (depends on lens)

Power Source Rechargeable battery: BP1130 (1130 mAh) Rechargeable battery: BP1030 (1030 mAh)

Wireless Network

MobileLink, Remote Viewnder, Auto Backup,

Email, SNS & Cloud, AllShare Play, AutoShare,

Wi-Fi Direct

Model

Spec

* This specifications can change without notice to upgrade a performance.

Autres manuels pour NX300

Table des matières

Autres manuels Samsung Appareil photo numérique

Samsung

Samsung digimax U-CA 501 Manuel utilisateur

Samsung

Samsung SMART CAMERA DV305 Manuel utilisateur

Samsung

Samsung ES15 Manuel d'instructions

Samsung

Samsung EC-HZ10WBBP Manuel utilisateur

Samsung

Samsung SL40 Manuel utilisateur

Samsung

Samsung SAMSUNG ST93 Manuel utilisateur

Samsung

Samsung WB650 Manuel d'instructions

Samsung

Samsung SL201 - Digital Camera - Compact Manuel d'instructions

Samsung

Samsung SCC-C4205P Manuel utilisateur

Samsung

Samsung EK-GN120ZKAXAR Manuel utilisateur

Samsung

Samsung I80 Manuel utilisateur

Samsung

Samsung NX10 Manuel utilisateur

Samsung

Samsung Digimax S800 - Digital Camera - 8.1... Manuel utilisateur

Samsung

Samsung NX500 Manuel utilisateur

Samsung

Samsung SAMSUNG ST66 Manuel utilisateur

Samsung

Samsung WB510 Manuel d'instructions

Samsung

Samsung Galaxy Camera EK-GC100 Manuel utilisateur

Samsung

Samsung TL90 - 12.2-megapixel Digital Camera Manuel d'instructions

Samsung

Samsung ST45 Manuel utilisateur

Samsung

Samsung DIGIMAX L70 Manuel utilisateur

Samsung

Samsung Vluu ST600 Manuel d'instructions

Samsung

Samsung NV30 - Digital Camera - Compact Manuel utilisateur

Samsung

Samsung SAMSUNG PL57 Manuel d'instructions

Samsung

Samsung L210 - Digital Camera - Compact Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
