Samsung DIGIMAX 230 Manuel utilisateur

CONTENTS

ⅠⅠ

.. SSPPEECCIIFFIICCAATTIIOONN

1. SPECIFICATION ……………………………………………………………………………………………… 2

2. SYSTEM REQUIRMENT ……………………………………………………………………………………… 2

3. TN LCD PANEL MARK…………………………………………………………………………………………3

4. TFT LCD PANEL MARK ………………………………………………………………………………………4

5. CONNECTION DIAGRAM ………………………………………………………………………………………5

6. PRODUCT EXTERIOR …………………………………………………………………………………………6

ⅡⅡ

.. EEXXPPLLOODDEEDD VVIIEEWW AANNDD PPAARRTTSS LLIISSTT

FRONT COVER ASSEMBLY

………………………………………………………………………………… 8

2. B

ODY ASSEMBLY

………………………………………………………………………………………… 10

3. BACK COVER ASSEMBLY ………………………………………………………………………………… 12

4. PACKING ITEM ………………………………………………………………………………………………14

ⅢⅢ.. AADDJJSSUUTTMMEENNTT

REPLACEMENT PARTS AND ADJUSTMENT ITEMS

…………………………………………………… 16

2. ADJUSTMENT TOOLS …………………………………………………………………………………………16

3. OPERATION INSPECTION ……………………………………………………………………………………16

2. ADJUSTMENT ITEMS

1) AE ADJUSTMENT …………………………………………………………………………………………17

2) AWB ADJUSTMENT ………………………………………………………………………………………18

3) AF ADJUSTMENT …………………………………………………………………………………………19

4) FLASH ADJUSTMENT ……………………………………………………………………………………20

ⅣⅣ.. PPRROODDUUCCTTSS CCOONNSSTTRRUUCCTTIIOONN

INTERCONNECTION DIAGRAM

…………………………………………………………………………… 21

2. PARTS ARRANGEMENT FOR EACH PCB ASS’Y

1) MAIN PCB ASSEMBLY ……………………………………………………………………………………22

2) POWER PCB ASSEMBLY …………………………………………………………………………………24

3) TOP PCB ASSEMBLY ……………………………………………………………………………………26

4) CCD F PCB ASSEMBLY …………………………………………………………………………………27

ⅤⅤ.. AADDJJUUSSTTMMEENNTT TTOOOOLL

………………………………………………………………………………… 28

11.. SSppeecciiffiiccaattiioonnss

※ Storage capacity figures are measured under Samsung's standard conditions and may vary

depending on shooting conditions and camera settings.

Image Sensor 1/2.7" CCD Seneor with 2.1Mega pixels(Effective no. of pixels:2.0M)

Lens f= 5.2~15.6mm(35mm film equivalent : 34 ~ 102mm)

F 2.4 ~ F4.0

Digital Zoom Record mode : 2X, Play mode : 2X

Viewfinder Real image optical viewfinder

LCD Monitor 1.6”color TFT LCD

Focusing TTL Auto focus (Central/Spot)

Focus distance Normal : 0.8m ~ Infinity, Macro : 0.2m ~ 0.8m

Shutter Mechanical and Electronic shutter

Shutter Speed 1 ~ 1/3,200sec.

Exposure Program AE(Full/Central/Spot)

Exposure compensation ±2EV (0.5EV steps)

ISO Equivalent Auto, 200, 400

Flash Auto & Red-eye reduction/Slow Sinc/Auto/Fill-in flash/Flash off

Flash Range Wide : 0.5m ~ 3.0m, Tele : 0.5m ~ 2.0m

Flash Charging time Approx 7sec.

Sharpness Soft/Normal/Hard

White Balance Auto/Daylight/Fluorescent/Tungsten

Voice memo Voice recording and play back for still image

Driver Mode Single / Continuous /

Movie clip Size : 320x240, recording time : 5~30sec.(5sec. steps)

Self-timer 10sec.

Storage CompactFlash Card

FIle Format Still image : JPEG(DCF compliant), DPOF compliant

Movie clip : AVI(MJPEG)

Image Size Large : 1600x1200 pixels, Medium : 800x600 pixels

Small : 640x480 pixels

Stroge Capacity Large : Super fine 6/12, FIne : 12/25, Normal : 25/51

(8MB/16MB) Medium : Super fine 19/38, FIne : 38/77, Normal : 77/155

Small : Super fine 38/77, FIne : 61/124, Normal : 90/182

Image Play Single image / Thumbnail / Slide show

Interface Digital output connector : USB

Video output : NTSC / PAL (user selectable)

DC power input connector : 6.0V

Power Source 4 X AA alkaline(high capacity recommended) / Ni-MH batteries.

AC adapter (optional)

Dimensions(WxHxD) 113x65x48mm

Weight 210g (without batteries and card)

Software Camera driver : Storage Driver(WIN 98/98SE/2000/ME/XP)

Application : MGI PhotoSuite, Digimax viewer

Ⅰ

. SPECIFICATIONS

22.. SSyysstteemm rreeqquuiirreemmeenntt

Specifications are subject to change without prior notice.

FFOORR WWIINNDDOOWWSS

Windows 98, 98SE, ME, 2000, XP

PC with processor better than MMX Pentium 233MHZ(XP:Pentium II 300MHz)

Min. 32MB of RAM(XP : 128MB)

110MB of available harddisk space

USB port

CD-ROM Driver

800X600 pixels, 16bits color display compatible monitor

(24bit color display adaptor, True color display recommended)

FFOORR MMAACCIINNTTOOSSHH

Power Mac G3 or later

OS 9.0 or later

Min 32MB RAM

110MB of available harddisk space

USB port

CD-ROM Driver

Quick Time 4.0 or later for Movie Clip.

33.. TTNN LLCCDD PPaanneell MMaarrkk

Image size

L : 1600X1200

M: 0800X0600

S: 640X0480

Shooting information

MACRO SHOT mode : Number of available shots remaining

STILL IMAGE mode : Number of available shots remaining

MOVIE CLIP mode : Available recording time

PLAY mode : Number of available shots remaining

SETUP mode : Number of available shots remaining

PC mode : USB

Battery condition indicator

:The batteries are fully charged

:Prepare new batteries

:There is no battery capacity

Replace new batteries

Flash

Auto flash and Red eye reduction :

Slow synchro : No indicator

Auto flash :

Fill in flash :

Flash off:

ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN

1 Battery condition

2 Flash

3 Self-timer

4 Landscapeshot

5 Macro shot

6 White balance

7 Metering methods

8 Exposure compensation

②

①

⒔

⒃

③

④

⑤

⑥

⑦

⑧

⑩

⑨

⑪

⑫

⑬

⑭

⑮

-2.0 ~ 0 ~ +2.0

9 ISO

10 Focusing Methods

11 Sharpness

12 Image quality

13 Image size

Number of available shots remaining

15 Zoom / Digital zoom

16 Movie clip shot

17 Shooting mode

■PLAY mode

AUTO 200 400

44.. TTFFTT LLCCDD PPaanneell MMaarrkk

■SHOT mode

ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN

13/13

15SEC

2002/ 01/ 01 00 : 00

REC

X 2.0

Movie clip shot

Movie clip running time

Image magnification

Date / Time

When an image that has sound

information is selected, this

indicator will be displayed.

This indicator will display when you

set DPOF.

DPOF

Battery condition The last stored image

number is displayed.

Number of stored images

Sound indicator

When you press the MIC ( )

button, this indicator will blink and

sound recording starts.

Sound recording

TV Monitor

AV Cable

AC Adaptor

USB Cable

Batteries

Alkarain x4

PCMCI Adaptorr

CF Card

Card Reader

IBM PC / MACINTOSH

6V/2.0A

Digimax 230 camera

55.. CCOONNNNEECCTTIIOONN DDIIAAGGRRAAMM

ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN

66..

PPrroodduucctt EExxtteerriioorr

Microphone

Shutter button

Mode dial

Strap eyelet

Lens

Self-timer lamp

Viewfinder

Flash fading

control sensor

LCD panel

Flash

Tripod socket

Cover lock

Battery

chamber cover

Mode dial lamp

ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN

LCD monitor

Autofocus

indicator (Green)

lamp

Viewfinder

Flash indicator

(Red) lamp

5-function button

Speaker

Zoom ( W ) / Thumbnail

button

Zoom (T) /Digital zoom

button

Power button

LCD button

MENU button

LANDSCAPE /

DELETE button

FLASH/LEFT button

PLAY&PAUSE/DOWN button

OK button)

SELF-TIMER / RIGHT button

MIC / UP button

▶

ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN

ⅡⅡ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT

1-22

1-1

1-9

1-11

1-18

1-10

1-14

1-13

1-8

1-16

1-2

1-20

1-3

1-7

1-6

1-5

1-4

1-18

1-21

1-12

1-19

1-15

1-17

11.. FFRROONNTT CCOOVVEERR

ⅡⅡ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT

▶▶PARTS LIST

1-1 9007-1818-01A FRONT COVER ASS'Y ( DIGIMAX 230) 1

9007-1828-01A FRONT COVER ASS'Y (KENOX DIGIMAX 230) 1

9007-1829-01A FRONT COVER ASS'Y (CYBERMAX 2000) 1

1-2 7217-2587-01A TOPLCD WINDOW 1

1-3 7217-2585-01A FRONT COVER ( DIGIMAX 230) 1

7217-2636-01A FRONT COVER (KENOX DIGIMAX 230) 1

7217-2637-01A FRONT COVER (CYBERMAX 2000) 1

1-4 7308-0135-01A GRIP RUBBER 1

1-5 7217258901A FINDER WINDOW A 1

1-6 7217-2638-01A FINDER WINDOW B 1

1-7 7217-2590-01A STROBE WINDOW 1

1-8 7411-0953-01A STRAP RING 1

1-9 7217-2588-01A CENTRAL DECORATION BAR 1

1-10 7217-2594-01A FD COVER 1

1-11 7217-2592-01A FD HOLDER 1

1-12 6107-0512-01A SB BUTTON SP 1

1-13 7217-2639-01A LED WINDOW 1

1-14 9007-1830-01A FD PLATE ASS'Y 1

1-15 6003-0350-01A SCREW 8

1-16 7017-0349-01A STRAP RING HOLDER 1

1-17 7217-2591-01A SB BUTTON 1

1-18 7409-1312-01A DOUBLE TAPE-GRIP 1

1-19 7409-1313-01A DOUBLE TAPE 2

1-20 7409-1257-01A FFC LABEL(MADE IN CHINA) 1

7409-1258-01A FCC LABEL(NO MARKING) 1

1-21 7409-1259-01A MIC LABEL 1

1-22 9002-1126-01A CENTRAL DECORATION BAR ASS'Y 1

Fig.No. Parts No. Parts Name Q'ty Remarks

2-3

2-18

2-19

2-21

2-8

2-9

2-10

2-39

2-11

2-12 2-34

2-17

2-40

2-20

2-15

2-14

2-15

2-16

2-2

2-43

2-44

2-25

2-27

2-26

2-28

2-29

2-4

2-41

2-42

2-5

2-6

2-7

2-33

2-35

2-32

2-31

2-36

2-13

2-24

2-36

2-23

2-1

2-22

2-38

2-36

2-37

2-30

2-36

22.. BBOODDYY

ⅡⅡ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT
