Samsung SGH-E690 Manuel utilisateur

World Wide Web

http://www.samsungmobile.com

* Depending on the software installed or your service provider or country,

some of the description in this guide may not match your phone.

* Depending on your country, your phone and accessories may appear

different from the illustrations in this guide.

Printed in Korea

Code No.: GH68-xxxxxA

English(SEA). 07/2006. Draft

SGH-E690

User’s Guide

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or illegal.

Drive safely at all times

Do not use a hand-held phone while driving. Park

the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them

in an aircraft is both illegal and dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Important safety precautions

Be aware of special regulations

Meet any special regulations in force in any area and

always switch off your phone whenever it is forbidden

to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid

unnecessary contact with the antenna when the phone

is switched on.

Emergency call

Key in the emergency number for your present

location, then press

Keep your phone away from small children

Keep the phone and all its parts, including accessories,

out of the reach of small children.

Accessories and batteries

Use only Samsung-approved batteries and

accessories, such as headsets and PC data cables.

Useof any unauthorised accessories could damage you

or your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health and

safety information" on page 24.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

At very high volumes, prolonged listening to a

headset can damage your hearing.

Contents

Unpack 4

Make sure you have each item

Get started 5

First steps to operating your phone

Install and charge the phone ..................................... 5

Power on or off........................................................ 6

Keys and display ..................................................... 6

Menu functions 9

All menu options listed

Solve problems 17

Help and personal needs

Health and safety information 19

1 Call log

1 Recent contacts

2 Missed calls

3 Dialled calls

4 Received calls

5 Delete all

6 Call time

7 Call costs

2 Phonebook

1 Contact list

2 FDN contacts

3 Create contact

4 Group

5 Speed dial

6 My namecard

7 Own number

8 Management

9 Service number

3 Applications

1 Music Player

2 Voice recorder

3 Image editor

4 Decision maker

5 Bluetooth

6 Java world

7 FM radio

8 SIM-AT

4 Browser

1 Home

2 Bookmarks

3 Enter URL

4 Clear cache

5 Profile settings

6 Current profile

5 Messages

1 Create new message

2 My messages

3 Templates

5 Messages

(continued)

4 Delete all

5 Settings

6 SOS message

7 Broadcast messages

8 Memory status

6 My files

1 Images

2 Videos

3 Music

4 Sounds

5 Other files

6 Memory status

7 Planner

1 Alarm

2 Calendar

3 Memo

4 World time

5 Calculator

6 Convertor

7 Timer

8 Stopwatch

8 Camera

1 Take photo

2 Record video

3 Go to My photos

4 Go to My video clips

9 Settings

1 Time and date

2 Phone settings

3 Display settings

4 Sound settings

5 Light settings

6 Network services

7 Security

8 Memory status

9 Reset settings

* Shows only if supported by your

SIM card.

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

Unpack

Your package contains the following items.

•Handset

• Battery

•TravelAdapter

•User’sGuide

In addition, you can obtain various accessories from your local Samsung dealer.

•StandardBattery

• Extended Battery

• Battery Charger

•Headset

• PC Data Link Kit

• Car Charger/Adaptor

The items supplied with your phone and the

accessories at your Samsung dealer may vary,

depending on your country or service provider.

phone

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive

a plug-in SIM (Subscriber Identity Module) card

loaded with your subscription details, such as your

PIN, and available optional services.

Install and charge the phone

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Remove the battery.

If the phone is already on, first turn it off by

holding [ ].

Insert the SIM card.

Make sure that the gold-coloured contacts on the card

face down into the phone.

Install the battery.

Plug the travel adapter into the phone.

Plug the adapter into a standard AC wall outlet.

When the phone is completely charged (the

battery icon becomes still), unplug the adapter

from the power outlet.

Remove the adapter from the phone.

Get started

Power on or off Keys and display

Switch on

Do not turn on the

phone when

mobile phone use

is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

the phone.

3. If necessary, enter the PIN and

press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Key(s) Description

Soft keys

Perform the function indicated on the

bottom line of the display.

Navigation

keys

In Idle mode, access your favourite

menus, directly.

In Menu mode, scroll through the menu

options.

Cingular keyIn Idle mode, launch the web browser.

In Menu mode, select the highlighted

menu option.

Cancel key Delete characters from the display.

In Menu mode, return to the previous

menu level.

Get started

SEND key Send or answer a call.

In Idle mode, retrieve the recent

numbers dialled, missed, or received.

END key End a call.

Press and hold to switch the phone on

and off.

In Menu mode, cancel input and return

the phone to Idle mode.

Numeric

keys

Enter numbers, letters, and some special

characters.

In Idle mode, press and hold

[1]

access your voicemail server. Press and

hold [

] to enter the international call

prefix.

key In Idle mode, press and hold [ ] to enter

a pause between numbers.

key Press and hold [ ] to activate or

deactivate Quiet mode.

Volume

keys

Adjust the phone volume.

In Idle mode, with the phone open,

adjust the keypad tone volume. With the

phone closed, press and hold to activate

the external display.
