Samsung AVMDH Manuel utilisateur

ENGLISH

ESPAÑOLFRANÇAIS

USER’S MANUAL

Duct Type Series

Silhouette duct : AVMDH



High static pressure duct : AVMHH



System Air Conditioner

DB98-05587A(3)SE F

AVXDD_E_05587A-3.indd 17 2007-04-02 ¿ÀÀü 9:01:34

E-2

Contents

 PREPARING YOUR AIR CONDITIONER

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

View of the Indoor Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

 RECOMMENDATIONS FOR USE

Operating Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Temperature and Humidity Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Cleaning Your Air Conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

AVXDD_E_05587A-2.indd 2 2006-09-18 ｿﾀﾈﾄ 1:19:35

E-3

ENGLISH

 Risk of electric shock can cause injury or death.

• Disconnect all remote electric power supplies before servicing, installing or

cleaning.

• Installation must be done by the manufacturer or service agent or a similar

qualified person in order to avoid a hazard.

WARNING

Safety Precautions

You should take the following safety precautions when using your air conditioner.



Do not pull the electric wire or

touch the power plug with the

wet hands.



Install the switch and circuit

breaker only for

air conditioner.



Use the rated current fuse.

REGARDING POWER SOURCE



Do not bend the electric wire

by force or weigh down the air

conditioner not to be out of

order.



Use the power source with

separate wiring only for air

conditioner.



If the power plug is

damaged, replace it by the

manufacturer or qualified

personal to avoid the risk.



Do not install the air

conditioner where there is

combustible gas.



Do not install the outdoor

unit where there is the risk

of dropping such as on high

outer wall or outside of the

terrace.



Earth the ground conductor

and do not connect it to the

gas pipe, water pipe or

telephone wire.

WHEN INSTALLING



Contact the service center if the air conditioner

is under water.

AVXDD_E_05587A-2.indd 3 2006-09-18 ｿﾀﾈﾄ 1:19:37

E-4



Do not place any materials so

that children cannot step on it.



Do not connect the electric

heater to the air conditioner

or repair it with your

discretion.

WARNING

DURING OPERATION



Do not place any obstacles in

front of the unit.

Make sure that the unit is

correctly ventilated at all times:

Do not place clothing or other

materials over it.



Do not insert anything

between the air outlet blades

because the inner fan may

be damaged and could cause

injury. Keep children away

from the unit.



If the wireless remote

controller is not used for

a long time, remove the

batteries. (If applicable)



Never spill any kind of liquid

into the unit. Should this

happen, unplug or main

switch off the unit and

contact an authorized

service center.



When using a wireless remote

controller, the distance should

not be more than

7 meters from the air

conditioner. (If applicable)



Users of this product are

cautioned not to attempt

repair of this product at their

own discretion. Instead, they

are requested to directly

contact a designated service

center or the outlet at which

the product was purchased.

AVXDD_E_05587A-2.indd 4 2006-09-18 ｿﾀﾈﾄ 1:19:41

E-5

ENGLISH

WARNING



Before throwing out the

device, it is necessary to pull

back the battery cells and get

rid of them safely for recycling

reasons.



Please recycle or dispose

of the packaging material

for this product in an

environmentally responsible

manner.

DISPOSING THE UNIT



When you need to dispose of

the unit, consult your dealer.

If pipes are removed

incorrectly, refrigerant may

blow out and come into

contact with your skin, causing

injury. Releasing refrigerant

into the atmosphere also

damages the environments.



Install the air conditioner

avoiding direct sunlight or

heater, especially water.



Install the outdoor unit so as

to let the discharged air out

properly. Avoid a place that

may disturb your neighbor by

noise.



Install the drain hose to let

the water run safely and

correctly.

WHEN INSTALLING

CAUTION

AVXDD_E_05587A-2.indd 5 2006-09-18 ｿﾀﾈﾄ 1:19:43

E-6



Disconnect the circuit breaker

when you don’t use the air

conditioner for a long time to

save energy.



Contact the service center or

manufacturer if you want to

repair the air conditioner.



Contact the service center

after turning off the air

conditioner if strange noise

is heard, burning smell or

smoke blow.

REGARDING POWER SOURCE



Avoid cold and hot air

reaching to person, pet or a

plant directly for a long time.



Avoid the water from

getting into the

air conditioner.

DURING OPERATION



Do not use the air conditioner

for a long time in a closed

room or in a place where

there is a baby or an old person.



Do not step on the air

conditioner or put heavy

objects on it.



Do not drink the water from

the air conditioner.

CAUTION

AVXDD_E_05587A-2.indd 6 2006-09-18 ｿﾀﾈﾄ 1:19:44

E-7

ENGLISH



Do not touch the pipes

connected to the air

conditioner.



Do not use the air conditioner

to maintain the machine, food,

pet, plant or cosmetics.



Do not give excessive shock

to the air conditioner.

DURING OPERATION



The appliance is not intended

for use by young children or

infirm persons without

supervision: Young children

should be supervised to

ensure that they do not play

with the appliance.



Max current is measured

according to IEC standard for

safety and current is

measured according to ISO

standard for energy efficiency.

OTHERS



Be sure that the air filter is

not to be exposed to direct

sunlight.



Do not clean the air conditioner

by spraying water directly or

with benzene, thinner or alcohol.



The surface of the heat

exchanger is sharp, so be

careful of it when cleaning.



Turn off the air conditioner

and if the fan stops operating,

clean the air conditioner.



Be sure to insert the air filter.

CAUTION

AVXDD_E_05587A-2.indd 7 2006-09-18 ｿﾀﾈﾄ 1:19:48

E-8

The figures shown in this instruction may differ from yours depending on the model.

Indoor Unit

AVMDH

Air

outlet

Air

inlet

Air filter

View of the Indoor Unit

AVXDD_E_05587A-2.indd 8 2006-09-18 ｿﾀﾈﾄ 1:19:50

E-9

ENGLISH

Indoor Unit

AVMHH

Air

outlet

Air

inlet

View of the Indoor Unit

AVXDD_E_05587A-2.indd 9 2006-09-18 ｿﾀﾈﾄ 1:19:50

E-10

Operating Recommendations

Here are a few recommendations that you should follow when operating your

air conditioner.

Topic Recommendation

Heating

performances

The heat pump function of the air conditioner absorbs heat from

outside air and brings it indoors. As the temperature of the outside

air drops, the heating performance of air conditioner will decrease.

If you find that the room is not warm enough, using an additional

heating appliance is recommended.

Frost & Defrost When outside temperature is low but humidity is high, frost may

form on the outdoor unit at HEAT mode.

If this happens:

The heating operation stops.

The defrost mode will be triggered automatically for about

10 minutes.

The steam produced on the outdoor unit in the defrost mode is

safe.

No intervention is required ; after about 10 minutes,

the air conditioner operates again normally.

High indoor

and outdoor

temperatures

If both indoor and outdoor temperatures are high and

the air conditioner is running at HEAT mode, the outdoor unit’s

fan and compressor may stop at times. This is normal ;

simply wait until the air conditioner switches on again.

Power failure

If a power failure occurs while the air conditioner is operating,

the unit will be switched off. When the power returns,

the air conditioner starts up again automatically.
