Samsung AR TVHA Series Manuel utilisateur

Air conditioner

Quick Guide

AR**TVHA*** /AR**TSHC***

•Thank you for purchasing this Samsung air conditioner.

•Before operating this unit, please read this manual carefully and retain it for future reference.

2English

Detailed User Manual

Checking on the website

STEP1 Check the model name.

STEP 2 Go to the Samsung website (http://www.

samsung.com) or Read the QR code.

STEP 3 Search and check User manual. SUPPORT

> Manuals & Downloads > Search model

Checking in Service Centre

STEP1 Check the model name.

STEP 2 Contact Service Centre.

STEP 3 Ask for the user manual of your product

model.

English

01 Air intake

02 Air filter

03 Wind-Free panel

04 Airflow blade (up and down)

05 Airflow blade (left and right)

06 Power button/Remote control receiver

07 Room temperature sensor

08 Display

Display

02 03

01 Temperature indicator (numeric)

Filter reset indicator ( )

Auto clean indicator ( )

Defrost indicator( ) (For AR**TSHC*** models)

02 Timer indicator

good’sleep indicator

03 Eco indicator

The appearance of the actual product may differ slightly from the image below.

Indoor Unit Overview

4English

Operating the Air Conditioner

Functions and Buttons

Function Button and Selection Display

Power On/Off

Wind-Free

Cooling In Cool/Dry/Fan mode ▶

Auto ▶ ▶ Select Auto.

Cool ▶ ▶ Select Cool.

Dry ▶ ▶ Select Dry.

Fan ▶ ▶ Select Fan.

Heat ▶ ▶ Select Heat.

Fast In Cool or Heat mode ▶

Quiet In Cool or Heat mode ▶ ▶

▶ Select Quiet. ▶

Beep ▶ ▶ Select Beep. ▶

Display lighting ▶ ▶ Select Display. ▶

01 Display

02 Button

NOTE

•Although Heat (AR**TVHA***),

Purify, Usage, Direct and Indirect

is displayed on the remote control

display, it is not available on this

model.

•Features may differ depending on

models.

English

Function Button and Selection Display

Eco In Cool or Heat mode ▶ ▶

▶ Select Eco. ▶

Timed on/off

▶ Select On or Off ▶

(Set the duration.) ▶

good'sleep

In Cool or Heat mode

▶

(Select .) ▶

(Set the duration.) ▶

6English

Cleaning

Auto clean function

Use the Auto clean function if the indoor unit produces odors.

Activating Auto clean

To activate Auto clean, press the (Options) button for at least 3 seconds.

The indoor unit display shows:

Canceling Auto clean

To cancel Auto clean while it is running, follow the procedure below:

▶Press and hold for 3 or more seconds.

Deactivating Auto clean

To deactivate Auto clean, follow the procedure below while the air conditioner is in operation or turned off:

▶ ▶ Select Clean. ▶

Cleaning the filter

Clean the air filter every two weeks or when the (filter-cleaning reminder) appears on the indoor unit

display. The time between cleanings may vary, depending on the usage and environmental conditions.

Vacuum cleaner

Soft brush 30 minutes

Mild detergent

English

1 Slide the filter off of the unit.

2 Use a soft brush or vacuum cleaner to remove any dust or debris on the filter.

3 Soak the filter in a solution of water and mild detergent for 30 minutes.

4 Rinse the filter and let it air dry in a well-ventilated area that is out of direct sunlight.

5 Reinstall the filter.

6 Reset the filter-cleaning reminder:

In operation ▶▶ ▶ Select Filter Reset. ▶

QUESTIONS OR COMMENTS?

COUNTRY CALL OR VISIT US ONLINE AT

SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/za/support

NAMIBIA 08 197 267 864 www.samsung.com/africa_en/support

ZAMBIA 0211 350 370 www.samsung.com/africa_en/support

MAURITIUS 800 2550 www.samsung.com/africa_en/support

REUNION 0262 50 88 80 www.samsung.com/africa_fr/support

MOZAMBIQUE 84 726 7864 www.samsung.com/africa_pt/support

NIGERIA 0800 726 7864 www.samsung.com/africa_en/support

Ghana 0800 100 077 www.samsung.com/africa_en/support

Cote D’Ivoire 8000 0077 www.samsung.com/africa_fr/support

SENEGAL 800 00 0077 www.samsung.com/africa_fr/support

CAMEROON 67095 0077 www.samsung.com/africa_fr/support

KENYA 0800 545 545 www.samsung.com/africa_en/support

UGANDA 0800 300 300 www.samsung.com/africa_en/support

TANZANIA 0800 780 089 www.samsung.com/africa_en/support

RWANDA 9999 www.samsung.com/africa_fr/support

DRC 499 999 www.samsung.com/africa_fr/support

SUDAN 1969 www.samsung.com/eg/support

DB68-08675A-00
