Samson Studio GT Manuel utilisateur

v1.1

Samson Technologies Corp.

45 Gilpin Avenue

Hauppauge, New York 11788-8816

Phone: 1-800-3-SAMSON (1-800-372-6766)

Fax: 631-784-2201

www.samsontech.com

Important Safety Information

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This lightning ash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of non-insulated“dangerous volt-

age”within the product’s enclosure that may be of sucient magnitude to

constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance instructions

in the literature accompanying the appliance.

AVIS

RISQUE DE CHOC ÉLECTRONIQUE -

NE PAS OUVRIR

If you want to dispose this product, do not mix it with general household waste. There is a

separate collection system for used electronic products in accordance with legislation that

requires proper treatment, recovery and recycling.

Private household in the 25 member states of the EU, in Switzerland and Norway may return their used

electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar

new one).

For Countries not mentioned above, please contact your local authorities for a correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and

recycling and thus prevent potential negative effects on the environment and human health.

Important Safety Information

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. This apparatus shall not be exposed

to dripping or splashing liquid and

no object lled with liquid, such as

a vase, should be placed on the ap-

paratus.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation

openings. Install in accordance with

the manufacturer's instructions.

8. Do not install near any heat sources

such as radiators, heat registers,

stoves, or other apparatus (including

ampliers) that produce heat.

9. Only use attachments/accessories

specied by the manufacturer.

10. Unplug this apparatus during light-

ning storms or when not in use for

long periods of time.

11. Do not override the intended pur-

pose of the polarized or grounding-

type plug. A polarized plug has two

blades, with one wider than the

other. A grounding-type plug has

two blades and a third grounding

prong. The wide blade or third prong

is provided for your safety. If the pro-

vided plug does not t your outlet,

consult an electrician to replace the

obsolete outlet.

12. Protect the power cord from being

walked on or pinched, particularly at

the prongs, convenience receptacles,

and the point where they exit from

the apparatus.

13. Use only with the cart

stand, tripod bracket,

or table specied by

the manufacture, or

sold with the apparatus.

When a cart is used, utilize caution

when moving the cart/apparatus

combination to avoid injury from

tip-over.

14. Refer all servicing to qualied service

personnel. Servicing is required if the

apparatus has been damaged in any

way, such as power-supply cord or

plug breakage, damage due to liquid

or objects falling onto the appara-

tus, exposure to rain or moisture, or

if the apparatus does not operate

normally, or has been dropped.

15. POWER ON/OFF SWITCH: For prod-

ucts with a power switch, the power

switch DOES NOT break the connec-

tion from the mains.

16. MAINS DISCONNECT: The plug

should remain readily operable.

For rack-mount or installation

where plug is not accessible, an

all-pole mains switch with a contact

separation of at least 3mm in each

pole shall be incorporated into the

electrical installation of the rack or

building.

17. FOR UNITS EQUIPPED WITH EXTER-

NALLY ACCESSIBLE FUSE RECEP-

TACLE: Replace fuse with same type

and rating only.

18. MULTIPLE-INPUT VOLTAGE: This

equipment may require the use of a

dierent line cord, attachment plug,

or both, depending on the available

power source at installation. Connect

this equipment only to the power

source indicated on the equipment

rear panel. To reduce the risk of re

or electric shock, refer servicing

to qualied service personnel or

equivalent.

Studio GT

Owner's Manual 5

Table of Contents

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Studio GT Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Studio GT Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Studio GT Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Studio GT Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Studio GT Hook-Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Recording with a microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Recording a guitar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Recording a keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Direct monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Setting Up the Studio GT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Direct Monitoring and Latency. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Installing the Studio GT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Studio GT Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Studio GT Dimensional Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANO

Studio GT

Introduction

Thank you for purchasing the Samson Studio GT studio monitors with integrated USB

audio interface. The Samson Studio GT provides accurate monitoring thanks to its

4.25-inch copolymer woofer and its 1-inch silk dome high frequency driver powered

by 2 x 20 watts of internal power. Beyond the boundaries of the typical studio monitor,

the Samson Studio GT includes two professional-quality microphone and instrument/

line inputs, two headphone outputs with independent level controls, as well as high-

quality analog-to-digital and digital-to-analog converters, that make it an ideal solu-

tion for your digital audio workstation. The Studio GT also features an input/computer

MIX control and 2-position switch for no-latency direct monitoring.

Designed to make home recording easy and professional, Studio GT includes

Cakewalk® Sonar LE music production software for enhanced control over the devel-

opment of your creations. Thanks to the versatile recording and monitoring solutions

provided by the Studio GT, it has never been easier to create professional, studio-quali-

ty tracks on any Mac or PC.

In these pages, you’ll find a detailed description of the features of the Studio GT

monitors, as well as a guided tour through its control panel, step-by-step inst-

ructions for its setup and use, and full specifications. You’ll also find a warranty card

enclosed, please don’t forget to fill it out and mail it in so that you can receive online

technical support and so that we can send you updated information about these

and other Samson products in the future. Also, be sure to check out our website

(www.samsontech.com) for complete information about our full product line.

With proper care and adequate air circulation, your Studio GT will operate trouble-free

for many years. We recommend you record your serial number in the space provided

below for future reference.

Serial number: ____________________________________________

Date of purchase: __________________________________________

Should your unit ever require servicing, a Return Authorization number (RA) must be

obtained before shipping your unit to Samson. Without this number, the unit will not

be accepted. Please call Samson at 1-800-3SAMSON (1-800-372-6766) for a Return

Authorization number prior to shipping your unit. Please retain the original packing

materials and if possible, return the unit in the original carton and packing materials.

If you purchased your Samson product outside the United States, please contact your

local distributor for warranty information and service.

Studio GT

Owner's Manual 7

Studio GT Features

Here is a look at some of the unique features of the Studio GT studio monitor system with

USB audio interface:

• Two-way, active studio reference monitor with ported tuned enclosure providing

extremely accurate monitoring for recording studio, post-production, video

gaming and multi-media applications.

• Integrated two-channel USB audio interface provides the ability to connect a

microphone, line, or instrument signal to record directly onto your digital audio

workstation.

• Onboard high quality 16-bit 44.1kHz/48kHz D-to-A (digital-to-analog) and A-to-D

(analog-to-digital) converters.

• Two combination XLR/¼”mic and instrument/line inputs.

• 2-position switch for no-latency direct stereo and mono monitoring.

• To listen to your mix on headphones, there are two 1/8-inch stereo headphone

outputs with individual level controls. The internal speakers automatically turn off

when you plug into the right Headphone output.

• For tight and controlled low frequency response, the Studio GT employs a

4.25-inch custom designed, inverted cone, copolymer woofer with santoprene

surround.

• The Studio GT’s 1-inch silk dome high frequency driver is set in a custom designed

wave guide, producing a high frequency response that’s accurate and natural.

• You can connect a second stereo input from an MP3 player, keyboard, sound card

or any other stereo line level signal to the Studio GT rear panel’s stereo RCA or 3.5

mm stereo Aux Input jack.

• Stereo Class D internal power amplifier.

• Passive crossovers utilizing a multi-pole design for linear response from bottom

to top.

• Solid MDF (Medium Density Fiberboard) construction provides maximum SPL.

• Precision-tuned rear vented enclosure, attractively finished in black satin vinyl

covering.

• 2 meter, 20-gauge speaker cable and USB cable included.

• Includes Cakewalk® Sonar LE music production software.

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANO

Studio GT

Studio GT Front Panel Layout

7 128 119 10

1. Silk Dome Tweeter - Smooth high frequency response produced from a 1-inch

silk dome tweeter.

2. Low Frequency Driver - 4.25” extended range low frequency transducer.

3. POWER LED (active) - Green LED illuminates indicating the unit is powered on,

ready for operation.

4. Clip LED - The Clip LED will illuminate red when the input signal reaches clipping

point. If the red Clip LED lights often or stays lit for any period of time, lower the

input gain level on that channel.

5. Input Gain Level Knob (GAIN) - Controls the input level of the associated Mic/

Inst input (6).

6. Microphone/Instrument Inputs (Channel 1 & Channel 2) - Each XLR / ¼”combo

connector will accept a standard mic, line or instrument level signal. Phantom

power is provided on the XLR microphone input.

7. Phones Level - Controls the overall output level to the left Headphone output (8).

8. Headphone - 3.5mm stereo output jack for connecting headphones.

9. STEREO/MONO Button - This button allows you to select the direct input

monitoring between stereo and mono operation. In Mono mode, the input

signals will be heard equally in the left and right side of the Studio GT. In Stereo

mode, Channel 1 will be heard in the left and Channel 2 will be heard in the right.

Studio GT

Owner's Manual 9

Studio GT Front Panel Layout

10. MIX Control - The MIX control is used to balance the audio mix of the input

signals and the audio coming from the computer. When turned fully counter-

clockwise, only the signals connected to the Studio GT inputs are heard. When

turned fully clockwise, only the output signal from your computer is heard at the

speaker and headphone outputs. Any adjustment between the two endpoints

will result in a proportional mix of both the Studio GT inputs and computer audio.

11. Headphone - 3.5mm stereo output jack for connecting headphones. The

monitors automatically mute when the right headphone is connected.

12. Level Control - Controls the overall output level for both speakers and the right

HEADPHONE output (11).

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANO

Studio GT

Studio GT Rear Panel Layout

1. 1/8” AUX INPUT – 3.5mm stereo input jack for connecting a second line level

signal source, like an MP3 player. This input is not sent through the USB output.

2. RCA INPUT – Used to connect signals from unbalanced, –10dBV devices, like a

mixer. The Red connector is for the Right input and the White is for the Left input.

3. USB Connector – Connect the supplied USB cable to this rear panel USB“B”

connector.

4. LEFT SPEAKER OUTPUT – Push Terminals for connecting the Left-side Extension

Speaker.

5. POWER SWITCH – Main power switch. When set to the ON position, the front

panel green LED illuminates indicating the Studio GT is powered up and ready for

operation.

6. AC INLET - Connect the supplied IEC power cable here.

7. TERMINAL CUP – Push Terminals for connecting the Left-side Extension Speaker

to the Active (Right-side) speaker.

8. TUNED PORT - Quiet port design offering linear extended low frequency

response.

Table des matières

Langues :

Autres manuels Samson Intervenants

Samson

Samson MediaOne 3a Manuel utilisateur

Samson

Samson Expedition Express Manuel utilisateur

Samson

Samson RS112A Manuel utilisateur

Samson

Samson Resolv 50a Manuel utilisateur

Samson

Samson Expedition EX30 Manuel utilisateur

Samson

Samson XP308i Manuel utilisateur

Samson

Samson EXPEDITION XP150 Manuel utilisateur

Samson

Samson MediaOne M30 Manuel utilisateur

Samson

Samson EXPEDITION XP40i Manuel utilisateur

Samson

Samson PORTABLE PA SYSTEM EXL250 Manuel utilisateur

Samson

Samson Resound RS10 Manuel utilisateur

Samson

Samson Resound RS12M Manuel utilisateur

Samson

Samson EXPEDITION XP312w Manuel utilisateur

Samson

Samson Resolv RXA5 Manuel utilisateur

Samson

Samson RSX M10a Manuel utilisateur

Samson

Samson AURO D415 Manuel utilisateur

Samson

Samson RESOLV 80a Manuel utilisateur

Samson

Samson Expedition XP300 Manuel utilisateur

Samson

Samson Expeditionn XP150 Manuel utilisateur

Samson

Samson MEDIAONE BT Manuel utilisateur

Samson

Samson Resolv RXA5 Manuel utilisateur

Samson

Samson expedition xp1000 Manuel utilisateur

Samson

Samson dB500a Manuel utilisateur

Samson

Samson Resolv A5 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
