Professional

juice extractor

Instruction Booklet

Model: JE-1013

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed including the following:

1. Read all instructions.

2. Always use this appliance on a dry, level surface.

3. To protect against risk of electric shock, do not immerse cord, plugs,

or the appliance in water or other liquid.

4. Children should not be allowed to operate this appliances and close

supervision is necessary when this appliance is used around children.

5. This appliance is not intended for use by infirm persons,

without supervision.

6. Unplug from outlet when not in use before putting on or taking off parts

and before cleaning.

7. Do not operate any appliance with a damaged cord or plug or after

the appliance malfunctions, or is dropped or damaged in any manner.

Return appliance to Salton for examination, repair or electrical

or mechanical adjustment. See Warranty.

8. The use of accessories or attachments not recommended or sold

by Salton may cause fire, electric shock or injury.

9. Do not use outdoors.

10. Do not let cord hang over edge of table or counter, or touch hot surfaces.

11. Extreme caution must be used when moving an appliance containing

hot liquids.

12. This appliance is for Household Use Only. Do not use appliance for other

than intended use.

13. Do not leave unit unattended while in use.

14. Always turn the appliance off and unplug from the outlet when left

unattended or finished using.

15. Check to be sure that the switch is in the OFF position after each use.

Makesure the motor is stopped before disassembling.

16. Avoid contacting moving parts.

17. The cutting blades in the strainer basket are sharp. Handle with care.

18. Always make sure the juicer is fully assembled and the juicer cover

is locked securely in position before the motor is turned on.

Do not attempt to remove parts when the juicer is in operation.

19. Do not attempt to override the safety features.

20. Do not use this appliance if the strainer basket is damaged.

21. Do not put your fingers or other objects into the feed tube while it is

operating. Always use the food pusher provided. If food becomes lodged

in the feed tube use the food pusher or another piece of fruit or vegetable

with the food pusher to push it down. If this is not possible, turn

the motor off and unplug the unit from the wall outlet and disassemble

the unit to remove the stuck food.

22. Do not place on or near a hot gas or electric burner, or in a heated oven.

23. Always attach plug to appliance first, then plug cord into the wall outlet.

To disconnect, turn any control to ‘OFF’, then remove plug from wall outlet.

GROUNDED PLUG

To reduce the risk of electric shock this appliance has a grounded plug.

(2 blades and 1 pin) If the plug does not fit fully into the electrical outlet

contact a qualified electrician. Do not modify the plug in any way

or use an adaptor.

BEFORE FIRST USE

1. Read the instructions carefully and keep for future reference

2. Remove all packaging.

3. Disassemble the juicer (see the Care and Cleaning section).

Wash all removable parts to remove any residue left over from

the manufacturing process.

HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

DESCRIPTION OF PARTS

1. Motor Housing

2. Electronic Control

A-Hi speed

B-Off

C-Lo speed

3. Locking handle

4. 1.5 litre/quart pulp container

5. Pulp Container Safety Foot

(Not Shown)

6. Pulp Chute/Juicer Cover

7. Feed Tube

8. Food Pusher

9. Stainless Steel Juice Collector

10. Stainless Steel Strainer

Basket/Cutting Blades

11. Spout

12. Juice Jug

13. Froth Separator (inside jug)

14. Rubber feet

•

HOW TO ASSEMBLE THE JUICER

1. Place the Stainless Steel Juice collector on

the motor housing with the spout facing

the direction of the Locking Handle. Swivel until

it locks into place. (See Ill. 1)

2. Place the Stainless Steel Strainer Basket inside

the Juice Collector. Twist the Strainer Basket

and gently push down until it is seated

in the Juice Collector. (See Ill. 2)

NOTE: The top edge of the Strainer Basket

should not be higher than the edge of

the Juice Collector when properly installed.

3. Place the Pulp Chute/Juicer Cover on the top so

that the opening of the Pulp Chute is on the

side opposite the spout. (See Ill. 3)

4. Lock the Pulp Chute/Juicer Cover into position

by raising the Locking Bar until it clicks into

the grooves located on both side of the Pulp

Chute/Juicer Cover. (See Ill. 4)

NOTE:Push the Locking Bar until it is fully

upright otherwise the Juicer will not operate.

5. Align the groove in the Food Pusher with the

small protrusion on the inside of the Feed Tube.

6. Slide the Pulp Container into position under

the Pulp Chute. Ensure that the Safety Foot

on the Pulp Container is fully inserted in the slot

in the Motor Housing otherwise the Juicer

will not operate.

7. If the Froth Separator is not in the Juice Jug,

slide between the tabs inside the Juice Jug.

If you prefer to have juice with froth then

the Froth Separator is not required.

8. Place the Juice Jug or a glass under the spout.

•

Ill.1

Ill. 2

Ill. 3

Ill. 4

HOW TO PREPARE FRUIT AND VEGETABLES FOR JUICING

1. Wash fruits and vegetables.

2. Peel fruits that have inedible skins such as citrus fruits, pineapple,

melons, papaya, etc.

3. Pit all fruits with hard seeds or stones such as peaches, nectarines,

cherries, etc.

4. Most fruits and vegetables such as apples, carrots and cucumbers will

not need to be cut. If the pieces are too big for the Feed Tube, slice

the fruit or vegetables before starting to juice.

HOW TO JUICE

1. Assemble the Juicer. The Juice Jug or a glass can be placed below

the pout to collect juice.

2. Plug the power cord into a 120 V power outlet.

3. Choose either ‘Hi’ or ‘Lo’ speed on the Electronic Control depending

on the type of fruit or vegetable that is being juiced. Never put any fruit

or vegetables in the juicer until power is turned on. Soft fruit or

vegetables, such as berries, melons, cucumber, tomatoes, etc. should

be juiced on Lo speed. Harder fruit and vegetables such as apples, celery,

carrots, etc. should be juiced at ‘Hi’ speed.

4. With the motor running, place food into the Feed Tube. Using the Food

Pusher, gently guide food down the Feed Tube. To Extract the maximum

amount of juice, always push the Food Pusher down slowly.

IMPORTANT: DO NOT PLACE HANDS OR FOREIGN OBJECTS DOWN

THE FEED TUBE. ALWAYS USE THE FOOD PUSHER

5. If the Pulp Container is full it can be emptied during juicing. Turn

the Juicer Off and remove the Pulp Container by holding onto the Feed

Tub and tilting the juicer slightly to disengage the Safety Foot on the Pulp

Container. Empty the Pulp Container. Replace by sliding the Pulp

Container into position under the Pulp Chute. Ensure that the Safety Foot

on the Pulp Container is engaged in the slot in the Motor Housing.

6. The froth separator in the Juice Jug will eliminate froth being poured into

the glass. If you prefer to have juice with froth, simply remove the froth

separator attachment from the Juice Jug before juicing

IMPORTANT: When juicing on ‘Hi’ Speed do not run the Juicer

for longer than 5 minutes then allow to rest for 2 minutes

beforeyou resume juicing.

HELPFUL HINTS

• A small amount of lemon juice can be added to apple juice

to prevent browning.

• Do not use bananas or avocados as they do not contain juice and will

clog the juicer.

• Allow the juicer to run for one minute before turning ‘Off’ to allow

any excess juice to be extracted from the pulp.

•Aplastic bag can be put in the pulp container for easy clean-up.

• Disassemble the Juicer and rinse off the pulp immediately after juicing.

The Strainer Basket/Cutting Blades can be soaked in water to loosen

the pulp. Then wash in warm soapy water.

• Wash parts immediately after use to avoid discolouration of the plastic

parts which may occur with some fruits and vegetables.

• If juicing herbs or leafy green vegetables process in combination with

other fruits or vegetables to yield more juice.

CARE AND CLEANING

How to Disassemble the Juicer

IMPORTANT: Before disassembling the Juicer make

sure that the Electronic Control is in the Off position,

the plug has been removed from the wall outlet

and the motor has stopped completely.

1. Remove the Food Pusher from the Feed Tube.

2. Remove the Pulp Container by holding onto

the Feed Tube and tilting the juicer slightly to

disengage the Safety Foot on the Pulp Container.

3. Remove the Juice Jug.

4. Hold the Pulp Chute/Juicer Cover and disengage

the Locking Bar from the grooves on the side

of the Pulp Chute/Juicer Cover. (See Ill. 1)

5. Lift and remove the Pulp Chute/Juicer Cover.

(See Ill. 2)

6. Remove the Stainless Steel Juice Collector

and Strainer Basket by placing one hand under

the spout and the other under the black plastic

edge opposite the spout and lifting upwards.

The Stainless Steel Strainer Basket can be removed

from the Juice Collector by pushing it up through

the hole in the bottom of the Juice Collector.

NOTE: Be careful when handling the Strainer

Basket as the cutting blades are very sharp.

•

Ill.1

Ill. 2

How to Clean

1. Move the Control Switch to the Off position and wait for the motor

to stop completely.

2. Unplug from the wall outlet.

3. Disassemble the Juicer (see directions on page 8)

4. Clean the Pulp Container, Pulp Chute/Juicer Cover, Food Pusher, Stainless

Steel Juice Collector, Juice Jug and Froth Separator in warm, soapy water.

Amild detergent is recommended. Rinse well and dry thoroughly.

NOTE: Care must be taken when cleaning or storing the Pulp

Container with Safety Foot.

5. Hold the Stainless Steel Strainer Basket/Cutting Blades under clean

running water. Use the cleaning brush included with the Juicer to gently

clean away pulp from the filter and cutting blades. Rinse under running

water. Hold the Strainer Basket/Cutting Blades up to the light to ensure

that the fine mesh holes are not blocked. If the holes are blocked, soak

the Strainer Basket/Cutting Blades in hot water to loosen the pulp and

clean with the nylon brush again. Allow to dry on a cloth or paper towel

before reassembling the juicer.

CAUTION: THE CUTTING BLADES ARE VERY SHARP.

6. Wipe the Motor Housing with a soft cloth moistened in warm soapy

water. NEVER IMMERSE MOTOR HOUSING WATER OR ANY

OTHER LIQUID.

TROUBLESHOOTING

Problem Solution

Juicer will not operate

when switched on.

•The safety locking arm may not be

correctly engaged into the 2 grooves

on either side of the Pulp

Chute/Juicer Cover.

•The safety foot is not fully inserted

in the slot in the Motor Housing.

Motor stalls when juicing •Push the Food Pusher down slowly

so that wet pulp does not build up

under the Pulp Chute/Juicer Cover.

•Choose Hi speed instead of Lo speed.

Excess pulp building up in filter •Alternate soft and hard fruit

and vegetables

Pulp too wet •Use Lo speed.

•Check to be sure that the holes in

the mesh filter are not blocked. If

they are blocked follow #5 in the

How to Clean section.

Juice leaks between the rim of the

Juicer and Pulp Chute/Juicer Cover

•Use Lo speed. Fruits and vegetables

with a high water content should be

juiced on Lo speed.

Table des matières

Autres manuels Salton Appareils de cuisine

Salton

Salton FR1416A Manuel utilisateur

Salton

Salton SWOK30 Guide d'installation

Salton

Salton BM1735 Manuel utilisateur

Salton

Salton DM-2 Manuel utilisateur

Salton

Salton TO2122SS Manuel utilisateur

Salton

Salton SFP85 Guide d'installation

Salton

Salton VitaPro DH1273A Manuel utilisateur

Salton

Salton SSM01 Guide d'installation

Salton

Salton SM-2 Manuel utilisateur

Salton

Salton SP2042 Manuel utilisateur

Salton

Salton MP2013 Manuel utilisateur

Salton

Salton CP1283 Manuel utilisateur

Salton

Salton DH-1043 Manuel utilisateur

Salton

Salton DH1273 Manuel utilisateur

Salton

Salton SSU8 Mode d’emploi

Salton

Salton JEB-10 Manuel utilisateur

Salton

Salton Cordless HOTRAY TWT40 Manuel utilisateur

Salton

Salton DH-1171 Manuel utilisateur

Salton

Salton CM1337 Manuel utilisateur

Salton

Salton GM1707 Manuel utilisateur

Salton

Salton SP1499 Manuel utilisateur

Salton

Salton JE-1187 Manuel utilisateur

Salton

Salton Melted Bliss SGCM1 Manuel utilisateur

Salton

Salton ELITE SDM051E Guide d'installation

Manuels Appareils de cuisine populaires d'autres marques

Tayama

Tayama TYG-35AF Manuel utilisateur

AEG

AEG 43172V-MN Manuel utilisateur

REBER

REBER Professional 40 Guide de l'utilisateur

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuel utilisateur

Presto

Presto fountain popper Manuel utilisateur

Westmark

Westmark 1035 2260 Manuel utilisateur

Zanussi

Zanussi ZCG64396XA Manuel utilisateur

HOFFEN

HOFFEN SM-9302M Manuel utilisateur

Philips

Philips HD3133 Manuel utilisateur

Ronco

Ronco Beef Jerky Manuel utilisateur

Hendi

Hendi 470411 Manuel utilisateur

Livoo

Livoo MEN386 Manuel utilisateur

Vogue

Vogue D446 Manuel utilisateur

croydon

croydon WR-10313-700 Manuel utilisateur

ADE

ADE AUTOMATIC-L Manuel utilisateur

Chefman

Chefman RJ43-SQ Series Manuel utilisateur

Vacmaster

Vacmaster VP680 Manuel utilisateur

Jetmaster

Jetmaster 900HG Manuel utilisateur
