B2 Series

HIGH VOLTAGE BATTERY

USER MANUAL

B2-5.0-25.0-HV1

B2 Series Battery

{=2*{page}-1}

Preface

Thank you for choosing SAJ battery. We are pleased to provide you first-class products and exceptional

service.

This manual includes information for installation, operation, maintenance, trouble shooting and safety.

Please follow the instructions of this manual so that we can ensure delivery of our professional guidance

and wholehearted service.

Customer-orientation is our forever commitment. We hope this document proves to be of great

assistance in your journey for a cleaner, greener world.

Please check for the latest version at www.saj-electric.com

Guangzhou Sanjing Electric Co., Ltd.


                                                                                                                                                                                         B2 Series Battery
{=2*{page}-1}









SAFETY PRECAUTIONS ..........................................................................................................................1
1 Scope of Application ........................................................................................................................................................2
2 Safety Instructions ............................................................................................................................................................2
3 Target Group........................................................................................................................................................................2

PREPARATION..........................................................................................................................................3
1 Safety Instructions ............................................................................................................................................................4
2 Explanations Of Symbols................................................................................................................................................ 5
3 Battery Handling................................................................................................................................................................6
4 Emergency Situation........................................................................................................................................................ 6

PRODUCT INFORMATION.......................................................................................................................9
1 Application Scope of Products...................................................................................................................................10
2 Specification for Product Model ................................................................................................................................10
3 Overview of Productsl....................................................................................................................................................11
4 Battery Terminals Description.....................................................................................................................................11
5 Datasheet ...........................................................................................................................................................................13

INSTRUCTIONS FOR INSTALLATION ..................................................................................................15
1 Unpacking and Inspection...........................................................................................................................................16
1.1 Checking the Package....................................................................................................................... 16
1.2 Scope of Delivery................................................................................................................................ 16
2 Installation and Position............................................................................................................................................... 17
2.1 Installation Position and Clearance.............................................................................................. 17
2.2 Mounting Method............................................................................................................................... 19
3 Mounting Procedure...................................................................................................................................................... 20
3.1 Installation Tools.................................................................................................................................. 20
3.2 Mounting Procedure.......................................................................................................................... 21
ELECTRICAL CONNECTION..................................................................................................................29
1 Additional Grounding Cable ....................................................................................................................................... 30
2 Connecting Battery COMM Cable............................................................................................................................ 32
3 Connecting Battery Power Cable ............................................................................................................................. 33
4 Connecting Battery to Inverter ................................................................................................................................. 34
5 Communication Inteface.............................................................................................................................................. 35
6 Installation of Side Covers........................................................................................................................................... 36

COMMISSIONING...................................................................................................................................37
1 Start Up and Shut Down the Battery...................................................................................................................... 38
1.1 Start Up .................................................................................................................................................. 38
1.2 Shut Down ............................................................................................................................................. 38
2 Introduction of Human-computer Interface ........................................................................................................ 39
3 Commissioning................................................................................................................................................................. 40

Battery Maintanence.............................................................................................................................41
1 Transportation.................................................................................................................................................................. 42
2 Storage................................................................................................................................................................................ 42

Troubleshooting and Warranty............................................................................................................43
TABLE OF
CONTENTS

B2 Series Battery

SAFETY

PRECAUTIONS

1.1 Scope of Application

This User Manual describes instructions and detailed procedures for installing, operating, maintaining, and

troubleshooting of the following SAJ products:

B2-5.0-HV1; B2-10.0-HV1; B2-15.0-HV1; B2-20.0-HV1; B2-25.0-HV1;

1.2 Safety Instructions

DANGER

·DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

·WARNING indicates a hazardous situation which, if not avoided, can result in death or serious injury or moderate injury.

CAUTION

·CAUTION indicates a hazardous condition which, if not avoided, can result in minor or moderate injury.

NOTICE

·NOTICE indicates a situation that can result in potential damage, if not avoided.

1.3 Target Group

Only qualified electricians who have read and fully understood all safety regulations contained in this manual

can install, maintain and repair the battery. Operators must be aware of the high-voltage device.

B2 Series Battery

PREPARATION

2.1 Safety Instructions

For safety, be sure to read all the safety instructions carefully prior to any works, and please observe the

appropriate rules and regulations of the country or region where you installed B2 battery.

DANGER

·Please keep the power off prior to any operations

·Do not use the battery or the battery control unit if it is defective, broken or damaged.

·Do not expose the battery to temperatures in excess of 50°C.

·Do not subject the battery to any strong force.

·Do not place the battery near a heat source, such as direct sunlight, a fireplace.

·Keep inflammable and explosive dangerous items or flames away from the battery.

·Do not soak the battery in water or expose it to moisture or liquids.

·Do not use the battery in vehicles.

·Do not use the battery in areas where the ammonia content of the air exceeds 20ppm.

WARNING

·Only qualified personnel who has full knowledge of local safety regulations and local standards on battery can install,

maintain, retrieve and process this product.

·SAJ electric shall not be liable for any loss or warranty claims arising from any unauthorized change of product which may

cause fatal injury to the operator, third party or equipment performance.

·For personal and property safety, do not short-circuit the positive (+) and negative (-) electrode terminals.

CAUTION

·Do not modify or change any components in the battery.

·Risk of damage due to improper modification

·Use professional tools when operating the products.

NOTICE

·During installation of the battery B2 high voltage battery, circuit breaker must be disconnected from the battery pack wiring.

·The battery B2 can only be used as a set with SAJ's H2 high voltage series storage inverter, otherwise it cannot be used

normally.

B2 Series Battery

2.2 Explanations of Symbols

Symbol

Description

Dangerous electrical voltage

This device is directly connected to public grid, thus all work to the battery shall only be carried out

by qualified personnel.

No open flames

Do not place or install near flammable or explosive materials.

Danger of hot surface

The components inside the battery will release a lot of heat during operation. Do not touch metal

plate housing during operating.

Attention

Install the product out of reach of children

An error has occurred

Please go to Chapter 7 “Troubleshooting”to remedy the error.

This device shall NOT be disposed of in residential waste

This battery module shall NOT be disposed of in residential waste

CE Mark

Equipment with the CE mark fulfills the basic requirements of the Guideline Governing Low-

Voltage and Electro-magnetic Compatibility.

Recyclable

2.3 Battery Handling

Operate and use the battery properly according to user manual, any attempt to modify battery without the permission from SAJ will void the limit

warranty for the battery.

•The battery must be installed at a suitable location with sufficient ventilation

•Do not use the battery if it is defective, damaged or broken.

•Only use the battery with compatible inverter.

•Do not use the battery with other type of battery.

•Make sure the battery is grounded prior to use.

•Do not pull out any cables or open the battery enclosure when the battery is powered on.

•Only use the battery as intended and designed.

2.4 Emergency Situation

Despite of its careful and professional protection design against any hazards, damage of the battery may still possible. If a small amount of battery

electrolyte is released due to a serious damage of the outer casing; or if the battery explodes due to not being treated timely after a fire breaks

out nearby, and leaks out poisonous gases such as carbon monoxide, carbon dioxide and etc., the following actions are recommended:

1）Eye contact: Rinse eyes with a large amount of running water and seek medical advice

2）Contact with skin: Wash the contacted area with soap thoroughly and seek medical advice

3）Inhalation: If you feel discomfort, dizziness or vomiting, seek medical advice immediately.

4）Use a FM-200 or Carbon Dioxide (CO2) fire extinguishers to extinguish the fire if there is a fire in the area where the battery pack is

installed. Wear a gas mask and avoid inhaling toxic gases and harmful substances produced by the fire.

5）Use an ABC fire extinguisher, if the fire is not caused by battery and not spread to it yet.

WARNING

B2 Series Battery

·If a fire has just occurred, try to disconnect the battery circuit breaker and cut off the power supply first, but only if you

can do so without endangering yourself.

·If the battery is on fire, do not attempt to extinguish the fire but evacuate the crowd immediately.

Potential danger of damaged battery:

Chemical Hazard: Despite of its careful and professional protection design against any hazard results, rupture of battery may still occur due

to mechanical damage, internal pressure etc., and may result in a leakage of battery electrolyte. The electrolyte is corrosive and flammable. When

there is fire, the toxic gases produced will cause skin and eyes irritation, and discomfort after inhalation. Therefore:

1) Do not open damaged batteries;

2) Do not damage the battery again (shock, fall, trample, etc.);

3) Keep damaged batteries away from water (except to prevent an energy storage system from catching fire);

4) Do not expose the damaged battery to the sun to prevent internal heating of the battery.

Electrical hazard: The reason of fire and explosion accidents in lithium batteries is battery explosion. Here are the main factors of battery

explosion:

1) Short circuit of battery. Short circuit will generate high heat inside battery, resulting in partial electrolyte gasification, which will stretch

the battery shell. The temperature reaching ignition point of internal material will lead to explosive combustion.

2) Overcharge of battery. Overcharge of battery may precipitate lithium metal. If the shell is broken, it will come into direct contact with the

air, resulting in combustion. The electrolyte will be ignited at the same time, resulting in strong flame, rapid expansion of gas and explosion.

B2 Series Battery

PRODUCT

INFORMATION

3.1 Application Scope of Products

The battery B2 is applied to residential photovoltaic storage system. The battery is built internally with a battery management system (BMS),

which is used to ensure efficiency of the battery and protect the battery from operating outside its specified limitations. B2 battery is a high

voltage battery system. The battery employs modular design for easy installation and wiring.

Figure 3.1

B2 battery application

3.2 Specification for Product Model

B2 –X.X –HV1

①②③

②B2 represents for product name.

②X.X represents rated energy XkWh of battery, for example, 5.0 means 5.0kWh.

③HV means high voltage.

B2 Series Battery

3.3 Overview of Products

626

200

365

261

365

626

Figure 3.2

Dimensions of battery control unit and battery module

3.4 Battery Terminals Description

Figure 3.3 Battery control unit interface (left view and right view)

Position

Name

BAT +/BAT- port (to inverter)

Communication port (to inverter)

B+/B- port (to battery module)

Circuit breaker

Display

BAT+- port (for parallel connection)

Main switch

Communication port (to battery module)

Ground

Communication port (for parallel connection)

Table 3.1 Battery control unit interface

Figure 3.4 Battery module interface (left view & right view)

Code

Name

Link Port 0

Link port 1

Ground

B - port

B +port

Table 3.2 Battery module interface

789

B2 Series Battery

3.5 Datasheet

Model

B2-5.0-HV1

B2-10.0-HV1

B2-15.0-HV1

B2-20.0-HV1

B2-25.0-HV1

Battery Module

BU2-5.0-HV1 (1P32S 102.4V50Ah)

No. of Modules

Rated Energy [kWh]

5.0

10.0

15.0

20.0

25.0

Usable Energy [kWh]

4.5

9.0

13.5

18.0

22.5

Dimension (H*W*D)[mm]

261*626*365

522*626*365

783*626*365

1044*626*365

1305*626*365

Weight [kg]

50.5

101

151.5

202

252.5

Nominal Voltage [V]

102.4

204.8

307.2

409.6

512

Operating Voltage [V]

89.6～115.2

179.2～230.4

268.8～345.6

358.4～460.8

448～576.0

Max. Charge Current [A]

Max. Discharge Current [A]

Short Time Withstand Current/

Conditional Short-circuit Current [A]

<10000

Control Module

BC2-HV1

Dimension (H*W*D)[mm]

200*626*365

Weight [kg]

General Data

Ingress Protection

IP65

Mounting

Wall-Mounted / Ground-Mounted

Operating Temperature Range

Charging: 0～50℃; Discharging: -10～50℃

Ambient Humidity

0～95% non-condensing

Cooling Method

Natural convection

Communication

CAN

Warranty [Year]

5/10

Applicable Standard

IEC62619(Cell&Pack)/EN62477-1/EN61000-6-1/2/3/4/UN38.3

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SAJ Accessoires pour appareils photo

SAJ

SAJ AS1-3KS-5.1 Manuel utilisateur

Manuels Accessoires pour appareils photo populaires d'autres marques

Viltrox

Viltrox EF-NEX Instructions d'installation

Calumet

Calumet 7100 Series CK7114 Manuel utilisateur

Ropox

Ropox 4Single Series Manuel utilisateur

Cambo

Cambo Wide DS Digital Series Mode d'emploi

Samsung

Samsung SHG-120 Manuel utilisateur

Ryobi

Ryobi BPL-1820 Manuel d'utilisation

Aegis

Aegis ABL-36020P Manuel utilisateur

Pentax

Pentax Data Back Fc Manuel utilisateur

Fantasea

Fantasea EyeGrabber F Series Manuel utilisateur

Honeywell

Honeywell HDZ20HD Manuel utilisateur

EGO

EGO BA1400T Manuel utilisateur

Sima

Sima SRW-62 Manuel utilisateur

Shape

Shape A7SSMKIT Manuel utilisateur

Slide Kamera

Slide Kamera HST-2 Manuel utilisateur

Power works

Power works 2902613 Manuel utilisateur

SES

SES SE-2047-2 Manuel utilisateur

Olympus

Olympus PT-EP05L Manuel utilisateur

Starlite

Starlite OctoDome nxt Manuel utilisateur
