Sage The Big Squeeze BJS700 Manuel utilisateur

the Big Squeeze™

BJS700/SJS700

EN QUICK GUIDE DE KURZANLEITUNG

FR GUIDE RAPIDE NL SNELSTARTGIDS

ES GUÍA RÁPIDA

IT GUIDA RAPIDA

PT MANUAL RÁPIDO

SAGE®

RECOMMENDS

SAFETY FIRST

At Sage®we are very safety

conscious.We design and

manufacture consumer

products with the safety of

you, our valued customer,

foremost in mind. In

addition we ask that you

exercise a degree of care

when using any electrical

appliance and adhere to the

following precautions.

IMPORTANT

SAFEGUARDS

READ ALL INSTRUCTIONS

BEFORE USE AND SAVE

FOR FUTURE REFERENCE

• A downloadable version of this

document is also available at

sageappliances.com

• Before using for the rst time

ensure your electricity supply

is the same as shown on

the label on the underside

of the appliance.

• Remove and safely discard

any packaging materials before

rst use.

• To eliminate a choking hazard

for young children, safely

discard the protective cover

tted to the power plug.

• This appliance is for household

use only. Do not use the

appliance for anything other

than its intended use. Do not

use in moving vehicles or boats.

Do not use outdoors.Misuse

may cause injury.

• Fully unwind the power cord

before operating.

• Position the appliance on

a stable, heat resistant, level,

dry surface away from the edge

and do not operate on or near

a heat source such as a hot

plate, oven or gas hob.

• Vibration during operation may

cause the appliance to move.

Contents

2Important Safeguards

5Components

6Assembly

9Operation

10 Care & Cleaning

12 Troubleshooting

15 Guarantee

• Do not let the power cord hang

over the edge of a bench or

table, touch hot surfaces or

become knotted.

• Always ensure the appliance

is turned OFF, unplugged at

the power outlet and has been

allowed to cool before cleaning,

attempting to move or storing.

• Always turn the appliance to

the OFF position, switch o at

the power outlet and unplug

at the power outlet when the

appliance is not in use.

• Do not use the appliance if the

power cord, plug, or appliance

becomes damaged in any way.

If damaged or maintenance

other than cleaning is

required, please contact Sage

Customer Service or go to

sageappliances.com

• Any maintenance other than

cleaning should be performed

by an authorised Sage®

service centre.

• Children should not play with

the appliance.

• Cleaning of the appliance

should not be carried out by

children unless they are 8 years

or older and supervised.

• The appliance and its cord

should be kept out of reach

of children aged 8 years

and younger.

• The installation of a residual

current safety switch is

recommended to provide

additional safety when using

all electrical appliances.

Safety switches with a rated

operating current not more

than 30mA are recommended.

Consult an electrician for

professional advice.

• Always ensure the appliance is

properly assembled before use.

The appliance will not operate

unless properly assembled.

• Do not use the appliance

on a sink drain board.

• Keep hands, ngers, hair,

clothing as well as spatulas

and other utensils away from

moving or rotating parts during

operation.

• Do not use the appliance

for anything other than food

and/or beverage preparation.

• In order to avoid the possible

hazard of the appliance starting

by itself due to inadvertent

resetting of the overload

protection, do not attach an

external switching device

(such as a timer) or connect the

appliance to a circuit that can

regularly switch the appliance

on and o.

• Carefully read all instructions

before operation and save for

future reference.

• The appliance can be used by

persons with reduced physical

or mental capabilities or a lack

of experience and knowledge,

only if they have been given

supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

• This appliance shall not be

used by children.

• Do not leave the appliance

unattended when in use.

• Do not push food into the feed

chute with your ngers or other

utensils. Always use the food

pusher provided. Do not place

hand or ngers into the food

chute when it is attached to

the appliance.

• Do not juice stone fruit unless

seeds and/or stones have

been removed.

• Do not operate the juice

extractor without the pulp

and juice container in place.

• Do not use the juice extractor

if the juicing screw is damaged.

• Do not operate the machine

longer than 20 seconds before

inserting ingredients.

The symbol shown

indicates that this appliance

should not be disposed of

in normal household waste.

It should be taken to a local

authority waste collection centre

designated for this purpose or to

a dealer providing this service.

For more information, please

contact your local council oce.

To protect against electric

shock, do not immerse the

power plug, cord or appliance

in water or any liquid.

SAVE THESE INSTRUCTIONS

Components

Feeding

Basket

Feeding

Tube

Detachable

A. Feeding Tube & Basket

For dierent sizes of produce.

B. Juicing Bowl

C. Pulp Cup

D. Drum Lid

E. Detachable Smart Cap

F. Juice Jug

G. Motor Body

H. Rotation Wiper

I. Strainer

J. Juicing Screw

K. Pusher

L. Cleaning Brush

Rating Information

220–240V~ 50/60Hz 240W

H I J K L

TOP SET ASSEMBLY

Align the dots on each part and assemble

in the order shown. Once assembled, turn the

drum lid clockwise to close.

Assembly

BEFORE FIRST USE

Before using your Juicer for the rst time, remove

any packaging material and promotional labels.

Ensure the power is in the OFF position, the juicer

is switched o at the power outlet and the power

cord is unplugged.

Wash bowl and juicing tools in warm soapy water

with a soft cloth. Rinse and dry thoroughly.

When rst using your appliance, you may notice

an odour coming from the motor. This is normal

and will dissipate with use.

TOP-SET AND BODY ASSEMBLY

Place the drum lid on the juicing bowl. Align the

red dot on the drum lid with the ALIGN mark

on the body and turn to the LOCK position.

ASSEMBLY

1. Firmly insert the compression silicone into

the slot below the pulp spout.The Juicer

may leak if not assembled properly.

2. Assemble the strainer into the rotation

wiper then place this assembly in to the

juicing bowl ensuring the red dot on the

strainer is aligned with the red dot on the

juicing bowl.

3. Place the juicing screw into the strainer. Turn

and press down on it until it clicks into place.

The juicing screw needs to be locked in place

in order to close the drum lid.

4. Place the drum lid on to the juicing bowl

aligning the dot on the drum lid with the

red dot on the juicing bowl.

TIP

For easy assembly hold the drum lid by grabbing

the feeding tube and turn clockwise as shown

in the illustration.

5. Align the red dot on the drum lid with the

ALIGN mark on the body and turn to the

CLOSE position.

6. Align arrows on drum lid and motor body.

NOTE

The juicer will not operate if the down arrow

on the drum lid is not completely aligned with

the CLOSE mark on the body.

7. Place the pulp cup under the pulp spout and

place the juice cup under the juice spout

as shown in the illustration.

Detachable

Operation

USING YOUR JUICER

1. After preparing the ingredients, plug the

power cord into a wall outlet. Do not touch

the power cord with wet hands. It may cause

electrical shock, short-circuit, or re.

2. Press the FORWARD button to operate.



Forward: Pulls down and slowly masticates

the ingredients.

Reverse: Pushes the ingredients back up

to dislodge them.The REVERSE button

only works while holding down the switch.

3. Insert the prepared ingredients into the

feeding tube, one piece at a time. If large

quantity of ingredients are put into the

feeding tube, it can cause the juicer to stop

Remove hard seeds or pits in fruits.

When juicing frozen fruits, completely

thaw before juicing.

HARD VEGETABLES & HIGH FIBRE

FOODS (E.G. CARROTS, BEETROOT,

& SPINACH)

Insert into the feeding tube.

Tough and brous ingredients: Cut to 2cm

wide and 5cm long.

Fibrous leafy vegetables: (celery, kale, collard

greens, etc.): Cut the stems into 5cm long and

bundle up the leafy part as you insert them into

the juicer.

SOFT FRUITS & VEGETABLES

(E.G. APPLES, ORANGES & TOMATOES)

Insert into the feeding basket.

Soft ingredients: Cut ingredients into 1–4

pieces. Insert the prepared ingredients into the

feeding basket and push down the ingredient

with the basket lid to extract.

Care & Cleaning

4. Remove the juicing screw, strainer and

rotation wiper unit from the juicing bowl.

Clean with provided brush.

NOTE

Immediately clean the juicer after each use.

If remaining residue in the juicer dries up,

it can make disassembling and clean-up dicult.

The excess build up can cause poor performance

in future uses. For easier disassembly, place the

top-set in the sink and run the water through from

the top of the top-set.

We do not recommend to wash any parts of the

juicer in the dishwasher.Washing parts in the

dishwasher can cause damage to them due

to prolonged exposure to harsh detergents,

hot water and pressure.

5. Place the juicing bowl under running water

and unplug the compression silicone to clean

the pulp spout.

Extract all the remaining pulp in the juicing bowl

before stopping the juicer.

For easier clean up, operate the juicer for

an additional 30 seconds after the juice is

extracted. Then ll the juicing bowl with water

and run the juicer before opening the drum lid.

When the drum lid is stuck, press the

REVERSE – OFF – FORWARD button in this

order, switching back and forth 2 to 3 times to

dislodge.Then place both hands on the drum

lid and rmly press down while simultaneously

turning the drum lid to open.

CLEANING THE JUICER

1. Switch OFF and unplug the power cord

from the wall outlet.

2. Turn the drum lid counter clockwise to open.

WARNING

When moving the appliance, do not lift by

grabbing the feeding tube. Always lift the

appliance by grabbing the body or handle.

3. Turn the top-set counter clockwise and lift

o the body.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Sage presse-agrumes

Sage

Sage Nutri Juicer Classic SJE95 Manuel utilisateur

Sage

Sage Nutri Juicer Cold Plus Manuel utilisateur

Sage

Sage Nutri Juicer Cold BJE430 Manuel utilisateur

Sage

Sage Citrus Press BCP600 Manuel utilisateur

Sage

Sage the Nutri Juicer Cold XL BJE830 Manuel utilisateur

Sage

Sage Big Squeeze SJS700 Manuel utilisateur

Sage

Sage Nutri Juicer Pro Manuel utilisateur

Sage

Sage the 3X Bluicer Pro BJB815 Manuel utilisateur

Sage

Sage Citrus Press BCP600 Manuel utilisateur

Sage

Sage Nutri Juicer Cold SJE430 Manuel utilisateur

Sage

Sage Nutri Juicer Cold XL SJE830 Manuel utilisateur

Sage

Sage Nutri Juicer BJE410 Manuel utilisateur

Sage

Sage Nutri Juicer SJE410 Manuel utilisateur

Sage

Sage Citrus Press Pro 800CP Manuel utilisateur

Sage

Sage the Nutri Juicer Plus SJE520 Manuel utilisateur

Sage

Sage Nutri Juicer SJE410 Manuel utilisateur

Sage

Sage the Nutri Juicer Plus BJE520UK Manuel utilisateur

Sage

Sage Fresh & Furious SBL620 Manuel utilisateur

Sage

Sage Nutri Juicer Cold BJE430 Manuel utilisateur

Sage

Sage Nutri Juicer Cold BJE430 Manuel utilisateur

Sage

Sage Nutri Juicer Plus BJE520 Manuel utilisateur

Sage

Sage the Nutri Juicer Plus SJE520 Manuel utilisateur

Sage

Sage SJE830 Manuel utilisateur

Sage

Sage Citrus Press 800CP Manuel utilisateur

Manuels presse-agrumes populaires d'autres marques

GE 169201 Manuel utilisateur

Exquisit

Exquisit ZP 3001 WET Manuel utilisateur

Philips

Philips HR1851 Manuel utilisateur

Sam Cook

Sam Cook MASTERCHEF EXECUTIVE PSC-50 Manuel utilisateur

Termozeta

Termozeta spremiagrumi Manuel utilisateur

ElectrIQ

ElectrIQ WF1000 Manuel utilisateur

Bella

Bella WHOLE FRUIT JUICER Manuel utilisateur

HAEGER

HAEGER Little Juice CJ-025 006A Manuel utilisateur

Havells

Havells Fusion Manuel utilisateur

Siemens

Siemens MK554 SERIES Manuel utilisateur

Beper

Beper 90.302B Guide rapide

NATURSAFT

NATURSAFT 015.401.3 Manuel utilisateur

Moulinex

Moulinex BKB 2 Manuel utilisateur

Royal Catering

Royal Catering RCJU-01 Manuel utilisateur

camry

camry CR 4002 Manuel utilisateur

AIGOSTAR

AIGOSTAR 30HIM Manuel utilisateur

ZUMEX

ZUMEX MINEX Manuel utilisateur

Skymsen

Skymsen EX Manuel utilisateur

Sage the Big Squeeze BJS700 Manuel utilisateur

Manuels presse-agrumes populaires d'autres marques
