OBSERVER™ 4116 NVR

HARDWARE USER GUIDE

Important Notices

Title: Observer™4116 NVR Hardware User Guide

Document Version: 1.2

Safety Vision attempts to provide information contained

in this manual based on the latest product information

available at the time of publication. However, because of

Safety Vision’s policy of continual product improvement,

Safety Vision reserves the right to amend the information in

this document at any time without prior notice.

This material is condential and the property of Safety

Vision. It is shared with your company for the sole purpose

of helping you with the operation of the described

equipment.

Safety Vision makes no warranty of any kind with regard

to this material, including, but not limited to, the implied

warranties of merchantability and tness for a particular

purpose. Safety Vision shall not be liable for errors

contained herein or for incidental or consequential damages

in connection with the furnishing, performance, or use of

this material.

Safety Vision expressly disclaims all responsibility and

liability for the installation, use, performance, maintenance,

and support of third-party products. Customers are advised

to make their independent evaluation of such products.

No part of this document may be photocopied, reproduced,

or translated to another language without the prior written

consent of Safety Vision.

Safety Vision® is a registered trademark of Safety Vision, LLC. All

other products or name brands mentioned in this document are

trademarks of their respective owners. For more information

about Safety Vision and its products, go to www.

safetyvision.com or call 800-880-8855.

OBSERVER SERIES USER GUIDE

Table of Contents

Main Wiring Diagram 2

Installation 3

Hard Drive Removal 4

SD Card Insertion/Removal 5

Components 6

Appendix A: Specications 8

Appendix B: Dimensions 9

OBSERVER 4116 NVR HARDWARE GUIDE 1

Main Wiring Diagram

CAN BOX connections

TO COLOR

GND BLACK

485B-1 GREEN

485B-1 WHITE

+5V RED

OBSERVER 4116 NVR HARDWARE USER GUIDE

Installation

Flat Mount

Secure the NVR to the surface with self-tapping

screws or rivets.

Ensure that the front panel of the NVR

remains accessible and there is a minimum

2.5 inches of clearance for cables.. Do not

install the NVR in an area of the vehicle cabin

that could interfere with the safe operation

of the vehicle.

Security Cover

After connecting all needed cables to the

rear of the NVR as shown in the Main Wiring

Diagram, secure the Security Cover with the

included Phillips head screws as shown in the

diagram.

OBSERVER 4116 NVR HARDWARE GUIDE 3

OBSERVER 4116 NVR HARDWARE USER GUIDE

Hard Drive Removal

To remove the hard drive from the NVR:

1. Ensure the NVR is powered o.

2. Release the two faceplate security

tabs on the side of the enclosure.

3. Insert the key into the faceplate

lock and turn it clockwise.

4. Open the faceplate.

5. Pull the hard drive rmly and

straight out.

OBSERVER 4116 NVR HARDWARE USER GUIDE

SD Card Insertion/Removal

Do not force the SD card into the slot

upside down or backwards.

Ensure the SD card’s write protection

slider is in the “unlocked” position.

Do not remove the SD card until the

NVR is turned o.

1. Open the faceplate as described in

the previous procedure.

2. Open the SD card slot door from

the left edge.

3. Insert an SD card into the SD card

slot label-side up, with the notch to

the right, until it clicks in place.

To remove the SD card, press the SD

card as far as it will go in the slot, then

allow it to “spring” out.

OBSERVER 4116 NVR HARDWARE GUIDE 5

OBSERVER 4116 NVR HARDWARE USER GUIDE

STATUS LEDS

LAN Indicates network activity

Power NVR is receiving power

REC NVR is recording video

VLoss One or more cameras is detached or malfunctioning

ALM Event/alarm has occured

ERR Storage Error - corrupted driver or unformatted drive

Components

1 - Removable Hard Drive - The hard disk drive (HDD)

provides the main storage for recorded data.

2 - USB Port - Insert a USB ash drive to download events

quickly without having to remove the SD card or hard drive, or

upload rmware updates. A USB mouse may also be attached to

navigate menus in collaboration with an external monitor.

3 - eSATA Port -Connect optional external equipment.

4 - Status LEDs - The Status LEDs illuminate to display the

current status of the NVR. See chart at left.

5 - SD Card Slot - Insert an SD card into the slot until it clicks.

To remove the SD card, briey press it in until it ejects.

6 - SIM Card Slot - Insert a SIM card as required by a cellular

network provider.

6OBSERVER 4116 NVR HARDWARE USER GUIDE

1 - Power Port - Connection for the main power harness.

2 - Panel Port - Connection for optional CP4-series monitors.

3 - Serial Port - Connection for the sensor block wiring harness.

4 - WAN/LAN Ports (RJ45) - Connections for optional network accessories.

5 - GPS Antenna Port - Connection for the external antenna for the internal GPS module.

6 - WiFi Antenna Port - Connection to an external antenna for the internal WiFi module.

7 - IPC Ports - Connections for up to 16 network IP cameras.

8 - Fan Power - Connection for fan power when the NVR is installed in an optional lockbox equipped with a fan.

9 - USB Port - Connection for optional USB accessories.

10 - Debugging Port - Connection for debugging and development (Service Technician use only).

OBSERVER 4116 NVR HARDWARE GUIDE 7

Appendix A: Specications

SPECIFICATIONS

Part No. 4116-NVR

OS Support Linux 3.0.8

Access Control CP4, web interface (Wi-Fi or interface), mouse (wireless)

Cameras Supported Up to 16 IP cameras

Audio/Video Output Port 1 video output channel and 1 audio output channel (SV-VID-MON-OUT required)

Display 1/4/9 image display

On-Screen Display GPS information, trigged alarm, temperature, acceleration, voltage, device

information, software version, MCU version, network status

Image Quality 8 levels

Image Resolution NTSC: 1080p (1920×1080) at 30 fps, 720p (1280×720) at 30 fps

PAL: 1080p (1920×1080) at 30 fps, 720p (1280×720) at 30 fps

Storage

2 × SATA II SSD (2 TB max each, 4 TB total)

2 × SATA II HDD (2 TB max each, 4 TB total)

Recording Modes Power on / manual / timer / alarm event recording

Mirror Recording 1 × SD card (up to 256 GB)

Redundant Storage External fire proof box (optional)

Pre-Event Recording Configurable up to 60 minutes

Post-Event Recording Configurable up to 30 minutes

Ethernet 2 ×RJ45 (10/100 M and 1000M)

Wi-Fi (Antenna Required) Embedded module (802.11b/g/n)

GPS (built-in) Location tracking, speed detection, and sync time

Accelerometer 3-Axis

Interfaces Front: 1 × USB 3.0 (type A), 1 × eSATA

Rear: 1 × USB 2.0 (type B), 2 × RS232, 2 × RS485

Sensors 8 inputs, 2 outputs

Power Input 8 ~ 36V DC, ACC

Power Output 5V @ 500 mA, 12V @ 500 mA

Operating Temperature -14° F ~ 158° F (-10° C ~ 70° C)

-40° F ~ 158° F (-40° C ~ 70° C) (with heating module)

Dimensions (w × h × d) 9.4 in × 4.5 in × 12.8 in (238 mm × 115.5 mm × 324.6 mm)

Certications MIL-STD-810, IEC 60068, FCC, CE, EN50155 EMC, ISO7673

OBSERVER 4116 NVR HARDWARE USER GUIDE
