Rule 174D Manuel utilisateur
Standard Bilge Pump
INSTRUCTION MANUAL
This pump is designed for use with fresh wa-
ter and salt water ONLY. Use with any other
hazardous, caustic, or corrosive material
could result in damage to the pump and the
surrounding environment, possible exposure
to hazardous substances and injury.
WARNING
2
STOP
C
4
CE Logo
When this product carries a CE mark, it conforms to
one or more of the following standards:
EN 61000-6-1:2001 EN 61000-6-3:2007
Following the Provisions of the Electromagnetic
Compatibility Directive 2004/108/EC
ISO 8846 / Electrical Devices Protection Against
Ignition of Surrounding Flammable Gases
ISO 8849:2003 / Electrically Operated Bilge Pumps
ISO 10133 / Electrical Systems - Extra Low
Voltage D.C. Installations Following the Provisions
of the Recreation Craft Directive 94/25/EEC
5
Disconnect power from the system before
working on the unit to avoid personal injury,
damage to the surrounding environment and/
or damage to the unit.
6
11
2
11
2
7
8
9
Rated Open Flow Open Flow Open Flow
Flow Output @ 0ft/0m Output @ 3.35ft/1m Output @ 6.7ft/2m
(0 kPa) GPH (LPH) (10 kPa) GPH (LPH) (20 kPa) GPH (LPH)
360 360 (1362) 265 (1003) 190 (719)
500 500 (1892) 360 (1362) 260 (984)
700 700 (2649) 562 (2127) 330 (1249)
800 800 (3028) 615 (2328) 425 (1608)
1000 1000 (3785) 725 (2744) 450 (1703)
1100 1100 (4164) 860 (3255) 550 (2081)
1500 1500 (5678) 1200 (4542) 680 (2574)
2000 2000 (7570) 1620 (6132) 1300 (4921)
3700 3700 (14006) 2900 (10977) 2450 (9274)
4000 4000 (15142) 3527 (13351) 2952 (11174)
8000 8000 (30283) 7050 (26687) 5984 (22651)
Note: Output is based on 10 hour break-in period and at 13.6V (12V
models) or 27.2V (24V models)
10
3800 GPH (14384 LPH)
(14006 LPH)
(15141 LPH)
(30283 LPH)
Pump Performance - Large RULE Pumps
(15141) (22712) (30283)
3785
Pump Performance - Small RULE Pumps
360
1000 GPH (3785 LPH)
Pump Performance - Small RULE Pumps
Pump Performance - Large RULE Pumps
11
