Ruida Technology RD-WIFI Manuel utilisateur
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
RD-WIFI
Wireless Network Instruction
Read this manual before operation
The content includes electric connections and operation steps
Read the manual to operate the systems
RuiDa Technology Co., Ltd
Addr: 2th floor,Technology Building,NO.,1057 Nanhai
Avenue,Nanshan District,Shenzhen city,Guangdong
Province,P.R.China
Tel: 0755--26066687
Fax: 0755--26982287
Web: www.rd-acs.com
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
COPYRIGHT
All rights reserved.You may not reproduce, transmit, store in a
retrieval system or adapt thispublication, in any form or by any
means, without the prior written permissionof RuiDa, except as
allowed under applicable copyright laws. We have identifiedwords
that we consider as trademarks. Neither the presence or absence
oftrademark identifications affects the legal status of any
trademarks.
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
CERTIFICATION DECLARATION
CE
The product has been certified by the CE (Commutate European) safety certification. It
has passed the corresponding conformity assessment procedure and the manufacturer's
declaration of conformity, in accordance with the relevant EU directive.
ROHS
This product has been certified by EU legislation (Restriction of Hazardous Substances)
Safety certification; comply with relevant EU environmental regulations.
FCC
This product has been certified by the Federal Communications Commission for safety,
Comply with us electronic safety regulations.
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
SAFETY INFORMATION
When using this system, please make sure the operation is correct and the usage is safe.
Some signs or text will be used to remind you to pay attention to the dangerous matters
and some important information.
Dangerous：
Indicates a serious danger. In the process of use, if the operation is
improper or the way of use is wrong, it may cause serious injury or even
death to the user. Please do not operate it easily until you have made sure
that the operation method is correct and the way of use is correct.
Warning：
Danger.n the process of use, if the operation is improper or the use is
wrong, which may lead to the injury of the personnel, please do not
operate the personnel and related personnel easily, until ensure the correct
operation method and use method is correct before use.
Cautious：
Represents the potential risk of the product. In the process of use, if the
use method is wrong or improper operation, it may cause damage to the
product or some parts. Please do not use it until you have made sure that
the operation method is correct and the usage is correct.
Important：
Represents important information to be paid attention to during the use of
the product.Please do not ignore this information, this information will
provide effective operational help.
This sign indicates laser radiation, which is usually posted on products
with laser output. Please be careful with laser and pay attention to safety
when using this kind of equipment.
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
Sign in、Devanning、Examine cargo
The product itself with plastic or metal shell, can protect the external electrical components
from damage. The products are packed in foam bags and anti-static bags. If there is any
external damage to the package, check the equipment and notify the carrier and carrier in
writing of the damage.
Inportant:
After receiving the product, please check whether the outer package is intact,
check whether the product is complete after unpacking and whether all parts
are intact. If any damage is found, please contact ruida immediately.
Remove all cargo from package and keep packing material and wiring parts. Please take care
of the safety of the goods when unpacking them.After taking out the goods, please check
whether the parts are complete and intact. If any missing parts or damaged parts are found,
please contact ruida technology immediately.Do not install or debug the equipment if any
obvious damage is found.
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
Contents
Section 1NETWORK CONNECTIONS VIAWIRELESS CARD OR WIFI ON LAPTOP .....................................1
1.1 One machine + One PC..................................................................................................................... 2
1.2 One machine + Multiple PC.............................................................................................................. 3
1.3 Multiple machines + One PC............................................................................................................ 3
1.4 Configuration:................................................................................................................................... 4
Section 2NETWORK CONNECTIONS VIA EXTERNAL WIRELESS ROUTER.................................................7
2.1 Multiple machines + One PC............................................................................................................ 8
2.2 Configured RD-WIFI terminal.......................................................................................................... 8
Section 3MAIN BOARD NETWORK SETTING ........................................................................................11
3.1 Networking without external wireless router...................................................................................11
3.2 Networking by external wireless router.......................................................................................... 15
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
1
Section 1 Network connections
via Wireless Network Card or WIFI
on laptop
CONTENTS:
One machine + One PC
One machine + Multiple PC
Multiple machines + One PC
Configuration
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
2
1.1 One machine + One PC
In this mode, one PC connects to one wireless terminal device via wireless terminal. As Figure-1 showed:
Figure-1 One desk-top computer wireless connection diagram
(Configured WIFI network card with USB interface)
Based on above structure, configured with RuiDa motion controller and RD-WIFI smart terminal devices, and the
desk-top computer with wireless card, the wireless control can be achieved between computer and machine.
Figure-2 One laptop wireless connection diagram
(Open WIFI)
Based on above structure, configured with RuiDa motion controller and RD-WIFI smart terminal devices, and the
laptop with wireless network card, the wireless control can be achieved between laptop and machine.
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
3
1.2 One machine + Multiple PC
For this mode, multiple PC can send process tasks to machine, see below figure-3.
Figure-3 Multiple PCs share one machine
Notes: This operating mode is different from sharing printer, due to the machine cannot do process task queue, so
when multiple PC shared the machine, the previous task must be finished, otherwise it will be failed.
1.3 Multiple machines + One PC
Each wireless terminal has an independent WIFI name in this mode. So user can chose any one of WIFI to control
the machine. All the machines WIFI name are listed in the wireless network. User can choose connecting the related WIFI
name to control the relative machine.
RD-WIFI Wireless Networking Instruction
SHENZHEN RUIDA TECHNOLOGY
4
1.4 Configuration
(1) Configured RD-WIFI
Adjust the router to AP gear first.
Set the local IP with router A or router B or router C in a network.
