1
BALL HEAD
User Manual
1
Thank you for purchasing a Really
Right Stuff ball head. Many years
ago, we set out to create ball heads
that would exemplify the best in
craftsmanship and quality. We are
proud to present the results of that
pursuit.
Thanks again, and enjoy.
Joe Johnson Sr.
Protected by US Patents
®™© 1990-2021 Really Right Stuff, LLC. All rights reserved.
Really Right Stuff, LLC Trademarks:
Really Right Stuff®, RRS®, Ground Pod®, Rock Claw®, Anvil™, Ascend™, Versa™, SureGrip™
WELCOME
Really Right Stuff
720 S 850 E, Lehi, UT 84043
Email: info@ReallyRightStuff.com
Web: www.ReallyRightStuff.com
Phone: 1-385-248-0777 or
toll-free US/CA 1-888-777-5557
Product Guarantee: All Really Right Stuff brand products are guaranteed to
the original purchaser to be free of defects in materials or workmanship for
five (5) years from the date of purchase.
1
03 |Maintenance
04 |General Use
07 |BH-55
08 |BH-40
09 |BH-30
CONTENTS
2
3
CARE / MAINTENANCE
GENERAL CARE
RRS ball heads are finished with a protective anodize plating that
protects the aluminum from corrosion and mild abrasion. It will not
protect it from scraping against or dropping on rocks/concrete/etc.
CLEANING
If your ball head is fouled, dry dust and dirt can be blown off and/
or wiped off with a soft cloth. Mud or salt water should be lightly
rinsed off with fresh water and then thoroughly dried. DO NOT
submerge your ball head when washing and do not direct a high-
pressure stream of water at the ball head.
DO NOT attempt to remove the knobs. If fine sand/grit fouls the
knob, simply run a gentle stream of water around the knob while
rotating it one-half turn back and forth.
LUBRICATION
RRS ball heads are lubricated at the factory and parts that require
lubrication are sealed. NO LUBRICATION IS REQUIRED BY THE
USER. DO NOT LUBRICATE THE BALL as this will decrease the lock-
up capacity. Keep ball free from contamination to maintain smooth
action.
4
GENERAL BALL HEAD USE
| Attach Ball Head to Tripod
| Reposition Main Lock T-Lever*
1Tighten the pan lock knob to lock the
panning base.
2Screw ball head onto the 3/8”-16
threaded stud on top of the tripod.
Tighten ball head onto tripod snugly,
but do not over-torque or it will be
difficult to remove.
1Pull the T-Lever out.
2Rotate T-Lever to new position.
3Re-seat the T-Lever back in.
1
2
1
2
3
*Non-applicable to BH-55
5
| Adjust the Drag Set*
| Using the Panning Base
1Remove your camera or hold it in place.
2Loosen the Main Lock Knob or T-Lever by rotating in the
opposite direction of the arrow (counter-clockwise).
3Tighten the Main Lock Knob or T-Lever to your preferred
amount of resistance by turning in the same direction of the
Arrow and Lock symbol (clockwise).
4Turn the Drag Set Knob in the direction of the arrow until it
stops, then loosen the Main Lock Knob or T-Lever.
DO NOT use the drag-set knob for locking/unlocking the ball;
doing so will damage the ball head.
1Loosen the Pan Lock Knob.
2Rotate the ball head body around the base into desired position.
3Lock the Pan Lock Knob.
*Non-applicable to BH-30
6
7
BH-55
Pan Lock Knob
Drag Set Knob
RRS 1.5" Dovetail Clamp
Main Lock Knob
Panning Base
8
BH-40
Panning Base
Pan Lock Knob
Drag Set Knob
RRS 1.5" Dovetail Clamp
Main T-Lock Lever
