Royal Enfield SCRAM 411 2021 Manuel utilisateur

ROYAL

ENFIELD

OWNER’S

MANUAL

BS VI-2022

Royal Eneld Support

1800 - 210 - 0007

1. Roadside Assistance

2. Product Update

3. Feedback

4. Dealer Locator

RoyaleneldSupport support@royaleneld.com www.royaleneld.com

Download the ROYAL ENFIELD APP and explore more

To access dealer details scan the QR code

READY. SET. SCRAM.

Conceived on our LS410 platform, SCRAM is a scrambler with an o-road pedigree. Bold & Playful - Lively & Engaging, it is nimble to

ride, from trails to alleyways. Always ready for what comes next; without a second thought. Living life on an instinct, spontaneous &

restless SCRAM 411 is all-ready to take it on.

While the Scram is all-ready, this Owner’s Manual prepares you to be ready before you set out to Scram. It thoroughly covers

features, capability, operation of the controls and quick xes. For the best health and performance of your motorcycle, we highly

recommend that you maintain it as per the schedule and procedures described in this manual. It should be considered a permanent

part of your motorcycle and should always be stored in it, even if it is subsequently sold.

For support and information, please call 1800 210 0007 anytime between 9 AM - 9 PM, any day of the week.

—Team Royal Eneld

FOREWORD

Royal Eneld Scram 411

All information in this manual is based on the latest product

information available at the time of publication. Due to

continuous improvements there may be discrepancies

between the information in this manual and your motorcycle.

Royal Enfield reserves the right to make production changes

at any time without prior notice and without incurring any

obligation to make the same or similar changes to motorcycles

previously built or sold. All images shown are for reference to

explain and need not to be exactly the same on the model you

own. Technical specifications are subject to change without

be copied,distributed or otherwise dealt without the express

permission in writing of Royal Eneld"

Part No. RAM00385/A / Qty. 1000 / Oct. 2021 /

NOTE

Disclaimer

This motorcycle meets the BS VI emission norms.

NOTICE

1. Do not polish matt nished paint surface in your motorcycle as

it will increase the gloss level.

2. Wash the painted parts only with plain water and do not use any

strong solvents cleaning agents or detergents.

3. Scratches, if happens on the matt finish parts cannot be

touched up and corrected / removed.

4. Warranty is not applicable for any matt nished painted parts of

the motorcycle.

5. The heat resistance coated components such as silencer pipe,

exhaust etc.., shall not be wiped clean with oiled cloth as it can

generate smokewhen the vehicle is driven and also leave patch

marks.

Royal Eneld Scram 411 3

Personal and motorcycle information ........................................... 4

Technical specications.................................................................. 5

Recommended lubricants ............................................................. 11

Safety denitions........................................................................... 12

Motorcycle identication numbers .............................................. 13

Location of key parts .................................................................... 15

Operation of controls ....................................................................18

Pre-Operational checks ............................................................... 40

Safe & Happy riding ..................................................................... 41

Cargo & Accessories .................................................................... 44

Rules of the road ......................................................................... 46

Running in period......................................................................... 48

Warning indications & Safety systems......................................... 49

Starting......................................................................................... 53

Gear shifting, Riding & Stopping .................................................. 54

Parking ......................................................................................... 55

Environment care ............................................................................... 56

Periodical maintenance chart ............................................................. 59

Tools kit .............................................................................................. 66

First aid kit .......................................................................................... 67

Minor maintenance tips ..................................................................... 68

Long trip precautions ......................................................................... 87

Shock absorber ...................................................................................88

O roading ......................................................................................... 89

Washing procedure ............................................................................ 90

Storage precautions ........................................................................... 92

Trouble shooting ................................................................................ 93

Warranty terms & Conditions ............................................................ 97

Emission warranty ............................................................................ 100

Service / Maintenance record ........................................................... 105

Note .................................................................................................. 106

CONTENTS

Royal Eneld Scram 411

Name

Door No. / Street

Locality / Town

City Country

Contact Res : O :

Mobile : Email :

Licence No. Valid till :

Model Color :

Engine No.

VIN. No.

Tyre Make Front : Rear:

Tyre Nos. Front : Rear:

Battery make Battery No :

Sold by

Date of Sale

PERSONAL & MOTOR CYCLE INFORMATION

Royal Eneld Scram 411 5

Ignition system .......... Digital electronic ignition

Spark plug .................. Bosch - UR5CC

Start spark plug gap ... 0.7 to 0.8 mm

Engine type ............. Single cylinder, 4 Stroke, SOHC,

Air cooled, Fuel injection

Bore ......................... 78 mm

Stroke ...................... 86 mm

Displacement........... 411 cc

Compression ratio.... 9.5:1

Max power ............... 24.3bhp (17.88 kW) @ 6500 rpm

Max torque .............. 32 Nm @ 4250 ±250 rpm

ECU / Variable

Idle rpm.................... 1300 ±100 rpm

Starting system ....... Electric Start

Air lter element ........ Paper element

Lubrication ................. Wetsump

Engine oil capacity...... 2.3 l ( Initial ll only),

1.61.8 l (Subsequent rells)

TECHNICAL SPECIFICATIONS

IGNITION SYSTEM

ENGINE

Royal Eneld Scram 411

Clutch....................... Wet multi plates

Primary drive............ Gear

Primary ratio ............ 2.312:1

Gear box................... 5 Speed. Constant mesh

Gear Ratio

1st Gear ............... 1st 2.916:1

2nd Gear............... 2nd 1.833:1

3rd Gear............... 3rd 1.428:1

4th Gear............... 4th 1.173:1

5th Gear............... 5th 1.000:1

Secondary drive ....... 5/8” Chain & sprocket

Secondary ratio....... 2.533:1

Drive chain links....... 110 links

TECHNICAL SPECIFICATIONS

TRANSMISSION

Royal Eneld Scram 411 7

Frame ........................ Half duplex split cradle frame

Steering lock ............ In built

Suspension

Front................. Telescopic, 41 mm forks 190 mm travel

Rear................... Mono shock with linkage, 180 mm Rear

wheel travel

Brakes

Brake system..... Dual channel ABS

Front disc.......... 300 mm Dia disc.

Rear disc ........... 240 mm Dia disc.

Tyre size

Front ................. 100/90 - 19"

Rear ................... 120/90 - 17"

Tyre pressures

Solo

Front .................. 25 psi / 1.75 kg/cm2

Rear .................... 32 psi/ 2.25 kg/cm2

With pillion

Front .................. 27 psi/ 1.89 kg/cm2

Rear .................... 34 psi/ 2.39 kg/cm2

TECHNICAL SPECIFICATIONS

CHASSIS

Royal Eneld Scram 411

Fuel type.................. Unleaded gasoline

Ethanol content....... E10 or less

Minimum octane..... 91 RON (Research octane rating number)

or Higher

Fuel tank capacity*... 15 ± 0.5 l (approx*)

Low fuel warning* .... Fuel segment 1ST bar blinking.

4 ±0.5 l (approx*)

Dead stock ............... 0.5 l (approx*) (unusable fuel)

TECHNICAL SPECIFICATIONS

1. The use of petrol containing more than the specied ethanol

will cause the fuel tank corrosion & paint damage and will also

damage the rubber tubes in the fuel line as well.

2. It is recommended to use only unleaded petrol, as leaded petrol

will cause damage to the catalytic converter.

Fly wheel magneto ....... 221 W @ 1500 rpm

Generation ................... Alternator, lll Phase

System ......................... 12 V - DC

Battery ......................... 12 volt, 8 Ah VRLA

Head lamp ................... 12 V, H460/55 W - BULB

Tail lamp/ Brake lamp.. 12 V - 4/1 W LED

CAUTION

ELECTRICALS

* The above values are approximate and the actual capacity

will vary with each fuel tank.
