Rosslare AY-D09M Instructions de montage

AY-Dx9M Family

Indoor Multi-Format Readers

Installation and Programming Manual

Models:

AY-D09M

AY-D19M

This manual and the information contained herein are proprietary to ROSSLARE

ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’

(hereafter: "ROSSLARE"). Only ROSSLARE and its customers have the right to

use the information.

No part of this manual may be re-produced or transmitted in any form or by any

means, electronic or mechanical, for any purpose, without the express written

permission of ROSSLARE.

ROSSLARE owns patents and patent applications, trademarks, copyrights, or

other intellectual property rights covering the subject matter in this manual.

TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN

THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS

AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND

TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION

MAY RESULT IN LEGAL PROCEEDINGS.

The furnishing of this manual to any party does not give that party or any third

party any license to these patents, trademarks, copyrights or other intellectual

property rights, except as expressly provided in any written agreement of

ROSSLARE.

ROSSLARE reserves the right to revise and change this document at any time,

without being obliged to announce such revisions or changes beforehand or

after the fact.

Table of Contents

AY-Dx9M Family Installation and Programming Manual iii

Table of Contents

1. Introduction ................................................................7

1.1 Reader/Controller Types........................................................... 7

1.2 Key Features ........................................................................... 7

1.3 Box Content ........................................................................... 8

1.4 Ancillary Equipment ................................................................ 8

2. Technical Specifications..............................................9

3. Installation ................................................................11

3.1 Mounting and Wiring the AY-Dx9M....................................... 11

4. Transmit Mode ..........................................................13

5. Programming the AY-Dx9M......................................14

5.1Entering Programming Mode................................................. 15

5.2 Exiting Programming Mode ................................................... 15

5.3 Selecting Keypad Transmission Format ................................... 16

5.3.1 Keypad Transmission Format Option Number ...............................17

5.4 Selecting Proximity Card Transmission Format (AY-D19M model

only)..................................................................................... 22

5.4.1 Wiegand Card + PIN Transmission Format ....................................22

5.5 Changing the Programming Code.......................................... 24

5.6 Changing the Facility Code.................................................... 24

5.7 Return to Factory Default Settings.......................................... 25

5.8 Replacing a lost Programming Code....................................... 26

A. Limited Warranty ......................................................27

List of Figures

iv AY-Dx9M Family Installation and Programming Manual

List of Figures

Figure 1: AY-Dx9M Layout ..............................................................................11

Figure 2: AY-Dx9M Wiring ..............................................................................12

List of Tables

AY-Dx9M Family Installation and Programming Manual v

List of Tables

Table 1: Programming Menus..........................................................................14

Table 2: Keypad Transmission Format..............................................................17

Notice and Disclaimer

vi AY-Dx9M Family Installation and Programming Manual

Notice and Disclaimer

This manual’s sole purpose is to assist installers and/or users in the safe and

efficient installation and usage of the system and/or product, and/or software

described herein.

BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE

USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY

REQUIREMENTS AND OPERATING PROCEDURES.

The system must not be used for purposes other than those for which it

was designed.

The use of the software associated with the system and/or product, if

applicable, is subject to the terms of the license provided as part of the

purchase documents.

ROSSLARE exclusive warranty and liability is limited to the warranty and

liability statement provided in an appendix at the end of this document.

This manual describes the maximum configuration of the system with the

maximum number of functions, including future options. Therefore, not all

functions described in this manual may be available in the specific system

and/or product configuration you purchased.

Incorrect operation or installation, or failure of the user to effectively

maintain the system, relieves the manufacturer (and seller) from all or any

responsibility for consequent noncompliance, damage, or injury.

The text, images and graphics contained in the manual are for the purpose

of illustration and reference only.

All data contained herein subject to change without prior notice.

In no event shall manufacturer be liable for any special, direct, indirect,

incidental, consequential, exemplary or punitive damages (including,

without limitation, any and all damages from business interruption, loss of

profits or revenue, cost of capital or loss of use of any property or capital or

injury).

All graphics in this manual are for reference only, some deviation between

the image(s) and the actual product may occur.

All wiring diagrams are intended for reference only, the photograph or

graphic of the PCB(s) are intended for clearer illustration and

understanding of the product and may differ from the actual PCB(s).

Introduction

AY-Dx9M Family Installation and Programming Manual 7

1. Introduction

The AY-Dx9M series are programmable indoor readers that allow

entry via a personal identification number (PIN) and/or by presenting a

proximity card. The keypad can be programmed to output eight

different data formats. The AY-D19M supports multiple proximity

card formats to provide a high level of compatibility and connectivity

with host controllers.

1.1 Reader/Controller Types

The two types of units described in this manual are:

Keypad Type PIN Proximity

AY-D09M Standard 

AY-D19M Standard 

1.2 Key Features

Built-in proximity card reader (125 kHz ASK modulation) (AY-

D19M model only)

Programmable Proximity Card Transmission Format (AY-D19M

model only)

Clock & Data

Wiegand 26-Bit

Wiegand Card + PIN

Built-in keypad for PIN code entry

Programmable keypad transmission format

Built-in case and back tamper

Programmable Facility code

Two tri-colored LEDs

Internal buzzer provides audible interface feedback

Introduction

8 AY-Dx9M Family Installation and Programming Manual

Comes with mounting template for easier installation

Comes with installation kit that includes a security screw and a

security screw tool

1.3 Box Content

Before beginning, verify that all of the following is in the box. If

anything is missing, please report the discrepancy to your nearest

Rosslare office.

AY-Dx9M access control unit

Installation kit

Installation and operating instructions

1.4 Ancillary Equipment

Additional non-supplied equipment required:

Compatible host controller

Power supply – 5 to 16 VDC (from a regulated power supply)

Other Rosslare accessories can be found at Rosslare's website:

http://www.rosslaresecurity.com

Technical Specifications

AY-Dx9M Family Installation and Programming Manual 9

2. Technical Specifications

Electrical

Characteristics

AY-D09M AY-D19M

Power Supply Type Linear type (recommended)

Operating Voltage Range 5–16 VDC

Maximum Input Current

(not including attached

devices)

Standby: 55 mA

Max: 100 mA

Card Read Distance* N/A 80 mm (3.0 in.)

Proximity Card Modulation N/A •Wiegand 26-Bit, ASK

at 125 kHz

•Clock & Data, ASK at

125 kHz

Proximity Card Compatibility N/A All 26-Bit EM cards

Keypad Transmit Format •Single Key, Wiegand 6-Bit (Rosslare

Format)

•Single Key, Wiegand 6-Bit with Nibble

and Parity Bits

•Single Key, Wiegand 8-Bit, Nibbles

Complemented

•4 Keys Binary + Facility Code, Wiegand

26-Bit

•1 to 5 Keys + Facility Code, Wiegand

26-Bit

•6 Keys BCD and Parity Bits, Wiegand

26-Bit

•Single Key, 3x4 Matrix Keypad

•1 to 8 Keys BCD, Clock & Data

Tamper Only with Rosslare controllers AC-015, AC-

020, and AC-115

* Measured using a Rosslare proximity card or equivalent. Range also

depends on electrical environment and proximity to metal.

Technical Specifications

10 AY-Dx9M Family Installation and Programming Manual

Environmental Characteristics

Operating Temp. Range -31°C to 63°C (-24°F to 145°F)

Operating Humidity Range 0 to 95% (non-condensing)

Dimensions AY-D09M AY-D19M

Length x Width x Depth 122 x 75 x 24 mm (4.8 x 3.0 x 0.9 in.)

Weight 110 g (3.9 oz) 117 g (4.1 oz)
