eSATA-150 RAID External 2Ports

Low Profile PCI Adapter

RC-221

User Manual

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

Important Message to RAID User:

1. Before the installation of controller card, please to study the PDF file of

SATA Raid manual at enclosed CD folder \ SATA Raid_2Port \ SiI3x12 \

Win98_me_2000_xp_nt4.0 \ Gui first. This Raid manual has more information

on Raid architecture, Raid features, Raid installation, Raid setting

and Management software for Raid GUI (Graphical User Interface).

2. After driver installation, if you like, you can install SATARaid GUI for Raid

management. Before SATARaid GUI installation, you must remove all the

existing SATARaid GUI (or Java SATARaid GUI) to ensure your new SATARaid

GUI can work properly.

i.e. : (\ Start \ Control Panel \ Add or Remove Programs \ Select all

SATARaid \ Remove)

3. For the creating and management of Raid sets, you can either use BIOS

utility setting before Windows operation or use GUI setting under Windows.

1. Introduction

The SATA RAID 2 Port PCI Host Adapter is a PCI to dual Serial ATA host

controller board. It provides a 32bit, 33/66 MHz PCI interface on the host side and

dual, fully compliant Serial ATA ports on the device side to access SATA storage

devices.

The board can be used to upgrade your desktop computer to have dual Serial

ATA Channels and support RAID 0 and RAID 1 features.

The board supports Serial ATA Generation 1 transfer rate of 1.5 Gb/s (150 MB/s). It

comes completely with drivers for Windows Vista, 2003, NT 4.0, 2000 and XP.

RAID, Redundant Array of Independent Disks, greatly enhances two main areas

of data storage: performance and data integrity. By using RAID 0, also known as

Striping, performance of sustained data transfer rates is greatly enhanced by

simultaneously writing data to 2 drives. The second benefit of RAID is data

redundancy. RAID 1, Mirroring, writes identical data on two drives or sets of drives,

thus protecting the data from a disk failure. If, for any reason, one drive were to fail,

your data is secure and available from the mirrored second drive.

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

1.1. Features

1.1.1. PCI Interface

Compliant with PCI Specification, revision 2.2

Integrated PCI DMA engines.

32 bit, 33/66MHz fully compliant PCI host interface.

1.1.2. High Speed Serial ATA Interface

Dual high speed Serial ATA ports, each supporting 1st generation Serial

ATA data rates (1.5Gb/s).

Provides RAID 0 (Stripping) to greatly increase the performance of data

transfer by simultaneously writing data to 2 drives.

Provides RAID 1 (Mirroring) to protect the data from a disk failure by writing

identical data on 2 drives.

Fully compliant with Serial ATA 1.0 specifications

Supports Spread Spectrum in receiver.

Independent 256-byte FIFOs (32 bit * 64 deep) per Serial ATA channel for

host reads and writes.

1.2. Package Contents

SATA RAID 2 Port PCI Host Adapter

Users Manual

Driver CD

2. What Is RAID

RAID - Redundant Array of Independent Disks

RAID technology manages multiple disk drives to enhance I/O performance and

provide redundancy in order to withstand the failure of any individual member,

without loss of data. This card provides two RAID Set types, Striped (RAID 0) and

Mirrored (RAID 1).

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

Disk Striping (RAID 0)

Striping is a performance-oriented, non-redundant data mapping technique. While

Striping is discussed as a RAID Set type, it is actually does not provide fault

tolerance. With modern SATA bus mastering technology, multiple I/O operations

can be done in parallel, enhancing performance. Striping arrays use multiple disks

to form a larger virtual disk.

Disk Mirroring (RAID 1)

Disk mirroring creates an identical twin for a selected disk by having the data

simultaneously written to two disks. This redundancy provides instantaneous

protection from a single disk failure. If a read failure occurs on one drive, the system

reads the data from the other drive.

3. BIOS Installation (RAID Setting)

Creating and deleting RAID sets is a function found in the BIOS. During boot up, the

RAID setting message will appear and pause for a few moments to allow the user to

choose what to do. This board will act as normal NON-RAID card when BIOS not

configured for RAID. Just proceed to Software Installation section directly. If you

use traditional parallel ATA HDD, make sure your hard drives be set up as master

mode before the RAID setting.

3.1. Creating Striped Sets (RAID 0)

1. As the BIOS boots, Press CTRL+S or F4 to enter the raid bios utility.

2. Select Create RAID set. Press Enter.

3. Select Stripe then press Enter.

4. Select Auto configuration. Press Enter.

5. Press Yto save your settings.

6. Press CTRL+E and then press Yto exit the setup.

7. Continue with conventional Fdisk and Format steps as if you are installing a

conventional hard drive.

8. Your RAID configuration is complete. Please proceed to software installation

section.

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

3.2. Creating Mirrored Sets (RAID 1)

1. As the BIOS boots, Press CTRL+S or F4 to enter the raid bios utility.

2. Select Create RAID set. Press Enter.

3. Select Mirrored then press Enter.

4. Select Auto configuration. Press Enter.

5. Press Yto save your settings.

6. Press CTRL+E and then press Yto exit the setup.

7. Continue with conventional Fdisk and Format steps as if you are installing a

conventional hard drive.

8.Your RAID configuration is complete. Please proceed to software installation section.

3.3. Deleting RAID Sets

1. As the BIOS boots, Press CTRL+S or F4 to enter the raid bios utility.

2. Select Delete RAID set. Press Enter.

3. Answer Y to remove the RAID set. If the RAID set being deleted is a Striped set,

then all of the data will be lost. If the set being deleted is a Mirrored set, then the data

will remain intact and accessible on both drives.

3.4. Rebuilding Mirrored Sets

1. After replacing the failed hard drives boot the BIOS, Press CTRL+S or F4 to enter

the raid bios utility.

2. Select rebuilding Mirrored set. Press Enter.

3. Select Online rebuild or Offline rebuild.

4. Answer Y to rebuild the Mirrored set of hard drive.

3.5. Resolving Conflict

When a RAID set is created, the metadata written to the disk includes drive

connection information (Primary and Secondary). If, after a disk failure, the

replacement disk was previously part of a RAID set (or used in another system), it may

have conflicting metadata, specifically in reference to the drive connection

information. If so, this will prohibit the RAID set from being either created or

rebuilt, In order for the RAID set to function properly, this old metadata must be

first overwritten with the new metadata. To resolve this, select Resolve Conflicts,

and the correct metadata, including the correct drive connection information, will be

written to the replacement disk.

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

4. Software Installation

4.1. Windows 98/98SE Driver Installation

For New Windows 98/98 SE Systems (Fresh Installation)

1. After the SATA RAID PCI Host Adapter and attached drives are configured,

follow Microsoft procedures to install Windows accordingly.

2. Once Windows has been installed, double click My Computer/Control

Panel/System, then click Device Manager.

3. Double click Other Devices then PCI RAID Controller.

4. Click Driver tab, then Update Driver.

5. Insert the Driver diskette and click Next.

6. Select Search for a better driver than the one ...option and click Next.

7. Check Specify a location, uncheck the other boxes, type in E:\ (If your

CD-ROM/DVD is E:\) and click Browse.

8. Points specify a location, example E:\SATA Raid_2Port\ Sil3x12\ Win98_me

_2000_xp_nt4.0 \ Driver, click OK and then Next.

9. Click Next and then Finish.

10. Remove the Driver CD and click Yes to restart Windows to complete driver

installation.

For Existing Windows 98/98 SE Systems

1. After the SATA RAID PCI Host Adapter and attached drives are configured, boot

up Windows.

2. At the Add New Hardware Wizard, click Next.

3. Select Search for the best driver for your device option and then click Next.

4. Insert the Driver CD, check Specify a location, uncheck the other boxes, and

click Browse.

5.Points specify a location, example E:\SATA Raid_2Port\ Sil3x12\ Win98_me

_2000_xp_nt4.0 \ Driver, click OK and then Next.(If your CD-ROM/DVD is E:\)

6. Click Next and then Finish respectively.

4.2. Windows ME Driver Installation

For New Windows ME Systems (Fresh Installation)

1. After the SATA RAID PCI Host Adapter and attached drives are configured,

follow Microsoft procedures to install Windows accordingly.

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

2. Once Windows has been installed, click My Computer, then click Properties. Click

Device Manager tab.

3. Double click Other Devices then PCI RAID Controller.

4. Click Driver tab, then Update Driver.

5. Insert the Driver CD, check Specify the location of the driver (Advanced)

and click Next.

6. Select Search for the better driver option, check Specify a location,

uncheck Removable Media, type in E:\ (If your CD-ROM/DVD is E:\), and click

Browse.

7. Points specify a location, example E:\SATA Raid_2Port\ Sil3x12\ Win98_me

_2000_xp_nt4.0 \ Driver, click OK and then Next.

8. Click Next and then Finish.

9. Remove the Driver diskette and click Yes to restart Windows to complete driver

installation.

For Existing Windows ME Systems

1. After the SATA RAID PCI Host Adapter and attached drives are configured, boot

up Windows.

2. At the Add New Hardware Wizard, check Specify the location of the driver

(advanced), and click Next.

3. Insert the Driver CD, check Specify a location, uncheck the other boxes, and

click Browse.

4.Points specify a location, example E:\SATA Raid_2Port\ Sil3x12\ Win98_me

_2000_xp_nt4.0 \ Driver, click OK and then Next.(If your CD-ROM/DVD is E:\)

5. Click Next and then Finish.

Verification of the Proper Installation for Windows 98/98SE/ME

1. Double click My Computer/Control Panel/System. Click Device Manager tab.

2. Double click SCSI Controllers, Silicon Image Sil-3x12 SATA Raid

Controller should be listed.

3. Highlight Silicon Image Sil-3x12 SATA Raid Controller and click

Properties. A message This device is working properly is displayed in the

dialog box, the driver has been correctly installed. If any error message is displayed,

remove Silicon Image Sil-3x12 SATA Raid Controller and restart your

system.

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

4.3. Windows NT 4.0 Driver Installation

For New Windows NT 4.0 System (Fresh Installation)

1. Before installation, copy all the files under directory E:\SATA Raid_2Port\ Sil3x12\

Win98_me _2000_xp_nt4.0\ driver\ *.* to a blank floppy disk

2. After the SATA RAID PCI Host Adapter and attached drives are configured, follow

Microsoft procedures to install Windows accordingly.

3. At the Windows Set-up screen, press F6 to specify and add the driver.

4. Press S, select Other, then press Enter.

5. Insert the Driver diskette and press Enter.

6. Select Silicon Image Sil-3x12 SATA Raid Controller Driver and press Enter.

7. Press Enter to continue and follow on-screen instructions to complete

Windows NT 4.0 installation.

Add Windows NT 4.0 Driver on Original Booting Device

1. After the SATA RAID PCI Host Adapter and attached drives are configured, boot

up Windows. Double click My Computer/Control Panel/SCSI Adapters, then click

the Drivers tab.

2. Click Add… then Have Disk....

3. Insert the Driver CD in your CD-ROM/DVD drive and type in E:\ (If your

CD-ROM/DVD is E:\), then click Browse.

4.Points specify a location, example E:\SATA Raid_2Port\ Sil3x12\ Win98_me

_2000_xp_nt4.0 \ Driver, click Open then OK.

5. Highlight Silicon Image Sil-3x12 SATA Raid Controller and click OK.

Verification of the Proper Installation for Windows NT 4.0

1. Double click My Computer/Control Panel/SCSI Adapters.

2. Highlight Silicon Image Sil-3x12 SATA Raid Controller and click

Properties. This device is working properly is displayed in the dialog box, the

driver has been correctly installed.

4.4. Windows 2000 Driver Installation

For New Windows 2000 Systems (Fresh Installation)

1. Before installation, copy all the files under directory E:\SATA Raid_2Port\ Sil3x12\

Win98_me _2000_xp_nt4.0\driver\ *.* to a blank floppy disk.

2. After the SATA RAID PCI Host Adapter and attached drives are configured,

follow Microsoft procedures to install Windows accordingly.

3. At the Windows Set-up screen, press F6 to specify and add the driver.

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

4. Insert the Driver diskette. Press S, then press Enter.

5. Select Silicon Image Sil-3x12 SATA Raid Controller Driver and press Enter.

6. Press Enter to continue and follow on-screen instructions to complete

installation.

Add Windows 2000 Driver on Original Booting Device

1. After the SATA RAID PCI Host Adapter and attached drives are configured, boot

up Windows.

2. At the Found New Hardware Wizard, click Next.

3. Select Search for a suitable driver for my device (recommended) and click

Next.

4. Insert the Driver CD in your CD-ROM/DVD drive, check Specify a location,

uncheck the other boxes, click Next, type in E:\ (If your CD-ROM/DVD is E:\). Click

Browse.

5. Points specify a location, example E:\SATA Raid_2Port\ Sil3x12\ Win98_me

_2000_xp_nt4.0 \ Driver, click Open then OK.

6. If the Digital Signature Not Found message appears, click Yes. (Note If

prompted for Windows 2000 CD-ROM, insert the CD and click OK. Type in

E:\I386, click OK and Finish. (assuming E: is your CD-ROM drive))

7. Click Finish.

4.5. Windows Vista/XP Driver Installation

For New Windows Vista/XP Systems (Fresh Installation)

1. Before installation, copy all the files under directory E:\SATA Raid_2Port\ Sil3x12\

Win98_me _2000_xp_nt4.0\driver\ *.* to a blank floppy disk

2. After the SATA RAID PCI Host Adapter and attached drives are configured,

follow Microsoft procedures to install Windows accordingly.

3. At the Windows Set-up screen, press F6 in order to specify and add the driver.

4. Insert the Driver diskette. Press S, then press Enter.

5. Select Silicon Image Sil-3x12 SATA Raid Controller Driver and press Enter.

6. Press Enter to continue and follow on-screen instructions to complete

Windows XP installation. Note: When the Software Installation warning pops

up, click Yes. And when the Hardware Installation warning pops up, click Yes

again.

Add Windows Vista/XP Driver on Original Booting Device

1. After the SATA RAID PCI Host Adapter and attached drives are configured, boot

up Windows.

eSATA-150 RAID External 2Ports Low Profile PCI Adapter RC-221 User Manual

2. At the Found New Hardware Wizard, check Install from a list or

specific location (advanced), then click Next.

3. Insert the Driver CD. Check Include this location in the search, uncheck the

other box, type in E:\, and click Browse.

4. Points specify a location, example E:\SATA Raid_2Port\ Sil3x12\ Win98_me

_2000_xp_nt4.0 \ Driver, click OK then Next.

5. When a warning message pops up, click Continue Anyway, then click Finish.

Verification of the Proper Installation for Windows Vista/2000/XP

1. Double click My Computer/Control Panel/System.

2. Click Hardware then click Device Manager.

3. Double click SCSI and RAID Controllers, then double click Silicon Image

Sil-3x12 SATA Raid Controller to display driver properties.

4. A message This device is working properly is displayed in the dialog box, the

driver has been correctly installed.

Thank you for purchasing a quality Rosewill Product.

Please register your product at : www.rosewill.com for complete warranty information and future support for your

product.

Table des matières

Autres manuels Rosewill Adaptateur

Rosewill

Rosewill RNX-N2LX Manuel utilisateur

Rosewill

Rosewill RNX-AC600NUBv2 Manuel utilisateur

Rosewill

Rosewill AC600 Manuel utilisateur

Rosewill

Rosewill RNX-N250PCEv2 Manuel utilisateur

Rosewill

Rosewill RCW604 Manuel utilisateur

Rosewill

Rosewill RNX-N2LX Manuel utilisateur

Rosewill

Rosewill WIRELESS N ADAPTER RNX-N150UBE Manuel utilisateur

Rosewill

Rosewill RNX-AC1200PCEv2 Manuel utilisateur

Rosewill

Rosewill User for RNX-N100 RNX-N100 Manuel utilisateur

Rosewill

Rosewill RX81-CW-DS BLK/SLV Manuel utilisateur

Rosewill

Rosewill RNX-N180UB Manuel utilisateur

Rosewill

Rosewill RNX-N600PCE_v2.0 Manuel utilisateur

Rosewill

Rosewill RNX-N180PCE Manuel utilisateur

Rosewill

Rosewill RNX-N250PC Manuel utilisateur

Rosewill

Rosewill RNX-AC600HGUBE Manuel utilisateur

Rosewill

Rosewill RNX-BT402 Manuel utilisateur

Rosewill

Rosewill RPLC-500 Manuel utilisateur

Rosewill

Rosewill RNX-AC600HGUBEv2 Manuel utilisateur

Rosewill

Rosewill RNX-N2X Manuel utilisateur

Rosewill

Rosewill RNX-N180UBE Manuel utilisateur

Rosewill

Rosewill RPLC-200 Manuel utilisateur

Rosewill

Rosewill RNX-N250PCe Manuel utilisateur

Rosewill

Rosewill RNX-N600UBE Manuel utilisateur

Rosewill

Rosewill AC1200UBE Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
