Rosen G8 Quick Reference Card

TURN ON THE SYSTEM

PLAY A DVD OR CD

a. Press and release the SOURCE

button on the remote (FIG 2) or the front

control panel (FIG 1) until "INTERNAL

DVD" appears.

b. Insert a disc, label side up, into the

disc slot (FIG 3). Most DVD's and CD's

will load or play immediately. If a

DVD menu appears on the screen,

press PLAY (FIG 2) on the remote

or overhead control panel.

Rosen T10/T12 Quick Reference Card

USE THE HEADPHONES

a. Turn on by pressing the ON/OFF button,

located on the ear piece. The power

LED on the ear piece should illuminate -

if not, check that the batteries are

inserted properly.

b. Turn down the volume knob on the ear

piece. Put over ears and re-adjust volume.

Note: The headphones must have a clear

line of sight to the T10/T12 screen to operate properly.

a. Turn vehicle ignition to ON or ACC

b. Press POWER on the remote (FIG 2) or

OPEN on the front control panel (FIG 1).

NOTE: The operating temperature range of

the system is from 32Oto 140OF.

Power

Stop

Play

Speaker

REMOTE

Pause

Day/Night

FIG 2

Source

Domelight

FRONT CONTROL PANEL

OPEN

Eject

Play/Pause Domelight

Source

FIG 1

Disc Slot

AUX

Input

Screen

Angle

Adjust

FIG 3

Power

ON/Off

switch

Volume

Knob

Adjust

Size Here

Batteries

FIG 4

Rosen T10/T12 Quick Reference Card

RES PN 9101047-90 - REV A



Speaker Sound on 87.9

Press to adjust

FIG 6

a. Press the SPEAKER on the remote

control (FIG 2) or press and on

the control panel (FIG 6) for five

seconds. The screen will display:

“SPEAKER SOUND on 87.9

Press to adjust”

b. Turn the vehicle’s radio on, and

tune to the FM frequency set by

the installer (see Owner’s Manual

for more detail).

c. Make sure radio and T10/T12 are on

and set to the same FM frequency.

PLAY INTERNAL VIDEO GAMES

a. Press any button on the game

controller to activate. Make sure

that the controller A/B switch is

set to “A.” The Controller

LED will blink when ready.

b. Press the SOURCE button on the front

control panel or on the remote control

until “INTERNAL GAME” appears

on the screen.

c. Use the game controller's left and right

arrow keys to choose a game.

d. Press the START button on the game

controller to choose the game.

e. Use the "A & B" buttons for fire, jump

or other action.

f. Press RESET to return to the main menu.

Start

GAME CONTROLLER

FIG 5

Reset

Directional

Control

Joystick

LED

A/B

Switch
