Rose electronics QuadraVista Manuel utilisateur

QUADRAVISTA™ QUAD VIDEO KVM SWITCH

10707 Stancliff Road Phone: (281) 933-7673

Houston, Texas 77099 WWW.ROSE.CO

Quick Installation Guide

QuadraVista Quick Start Guide

The QuadraVista has been designed to take the guesswork out of the installation

process. The auto-sensing features will determine the type of video monitor

each of the four connected computer has, digital or analog. QuadraVista also will

determine the type of keyboard (USB, PC1, PC2, PC3) and mouse (USB, PS/2,

PS/2 wheel). With these features, you will be up and running in no time.

First, make sure that power is off on QuadraVista and all computers being

connected. Next, connect your KVM user station as shown below. Connect a

USB mouse and USB keyboard to the corresponding USB ports. If a PS/2

keyboard and mouse are used, a PS/2 to USB converter must be used. Next,

connect a VGA or DVI monitor to the DVI-I port. If a VGA monitor is used, a VGA

to DVI converter cable must be used.

Connect up to four computers to the corresponding video (DVI-I),

keyboard/mouse ports on the QuadraVista as shown below.

If a VGA (HD15F) connector is on the computer, a VGA to DVI cable must be

used. If the keyboard and mouse are PS/2, use a PS/2 "Y" cable.

Apply power to the QuadraVista, then computers and user

station monitor. The KVM user stations monitor will display

in the quad mode, all connected computers video.

Refer to the Installation and Operations manual for

additional information about the on-screen menus and other

configurations that can be performed.

KVM user station

QuadraVista Quick Start Guide

Keyboard commands

(Default "HOTKEY" is the CTRL + ALT keys pressed at the same time

followed by the needed command)

Command* Description

"HOTKEY" + Q Change display to quad mode

"HOTKEY" + F Change display to full screen mode

"HOTKEY" + P Change display to PIP function

"HOTKEY" + 1 Switch to computer 1 (Full Screen)

"HOTKEY" + 2 Switch to computer 2 (Full Screen)

"HOTKEY" + 3 Switch to computer 3 (Full Screen)

"HOTKEY" + 4 Switch to computer 4 (Full Screen)

"HOTKEY" + F1 Switch to quad mode and activate channel 1

"HOTKEY" + F2 Switch to quad mode and activate channel 2

"HOTKEY" + F3 Switch to quad mode and activate channel 3

"HOTKEY" + F4 Switch to quad mode and activate channel 4

"HOTKEY" + O Invoke the on-screen menu system

"HOTKEY" + I PIP menu

"HOTKEY" + V Reset video resolution to default setting

(640 x 480 @ 60 Hz)

The QuadraVista has been designed to take the guesswork out of the

installation process. The auto-sensing features will determine the type of

video monitor each of the four connected computer has, digital or analog.

QuadraVista also will determine the type of keyboard (USB, PC1, PC2, PC3)

and mouse (USB, PS/2, PS/2 wheel). With these features, you will be up and

running in no time.

First, make sure that power is off on QuadraVista and all computers being

connected. Next, connect your KVM user station as shown below. Connect

a USB mouse and USB keyboard to the corresponding USB ports. If a PS/2

keyboard and mouse are used, a PS/2 to USB converter must be used.

Next, connect a VGA or DVI monitor to the DVI-I port. If a VGA monitor is

used, a VGA to DVI converter cable must be used.

Connect up to four computers to the corresponding video (DVI-I),

keyboard/mouse ports on the QuadraVista as shown below.

If a VGA (HD15F) connector is on the computer, a VGA to DVI cable must be

used. If the keyboard and mouse are PS/2, use a PS/2 "Y" cable.

KVM user station

QuadraVista Quick Start Guide

Apply power to the QuadraVista, then computers and

user station monitor. The KVM user stations monitor will

display in the quad mode, all connected computers

video.

Refer to the Installation and Operations manual for

additional information about the on-screen menus and

other configurations that can be performed.

Keyboard commands

(Default "HOTKEY" is the CTRL + ALT keys pressed at the same time

followed by the needed command)

Command* Description

"HOTKEY" + Q Change display to quad mode

"HOTKEY" + F Change display to full screen mode

"HOTKEY" + P Change display to PIP function

"HOTKEY" + 1 Switch to computer 1 (Full Screen)

"HOTKEY" + 2 Switch to computer 2 (Full Screen)

"HOTKEY" + 3 Switch to computer 3 (Full Screen)

"HOTKEY" + 4 Switch to computer 4 (Full Screen)

"HOTKEY" + F1 Switch to quad mode and activate channel 1

"HOTKEY" + F2 Switch to quad mode and activate channel 2

"HOTKEY" + F3 Switch to quad mode and activate channel 3

"HOTKEY" + F4 Switch to quad mode and activate channel 4

"HOTKEY" + O Invoke the on-screen menu system

"HOTKEY" + I PIP menu

"HOTKEY" + V Reset video resolution to default setting

(640 x 480 @ 60 Hz)

〒103-0014

東京都中央区日本橋蛎殻町 1-16-11

TEL:03-3668-8089 FAX:03-3668-9872

URL:http://www.cybernetech.co.jp
