ROSE DISPLAYS ROPOLE-SPIDER Manuel utilisateur

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

The RoPole is a registered trademark of Rose Displays, Ltd. Neither

the manufancurer nor any sales agent may be held liable for injury, loss

or damage resulting from the use of these products. Part #INSSPRP

To install

Assemble poster, sign holders, hooks and anchor onto RoPole head

(see illustration). Rest heel of RoPole on floor. Loosen telescopic

joints and extend pole to the ceiling. Lock the RoPole joints. If you

have the spring lock RoPole press button on pole, raise upper part

of pole until button snaps into the desired stop determined by the

ceiling height. Line up the wings of the RoPole head under the

ceiling grid (Fig. 1). Push up lightly against the grid. Twist the

RoPole to the right until the anchor locks.

To remove

Rest heel of RoPole on floor. Loosen telescopic joints and extend

pole to the ceiling. Firmly lock the RoPole joints.

Line up RoPole head parallel with grid as shown (Fig.2). Push up

lightly. With the anchor engaged in the RoPole head, turn the

RoPole to the left until the anchor releases. Lower slowly.

Sign

RoPole

Ceiling

Sign

Spider

Head

Helpful Hints

• Practice makes perfect!

•Those not yet familiar with the RoPole should first practice

installing and removing the anchor from the ceiling without a

poster a few times. Keep the RoPole vertical and directly

beneath the anchor.

Spider RoPole®Instructions

Ceiling Grid

Wings

Figure 2 Anchor Head

Wings

RoPole

head

Sign

Holder

Anchor

Hook

Clip

Ceiling Grid

Wings

Figure 1 Anchor
