Ronix RP-4100 Manuel utilisateur

MULTI-FUNCTIONAL CLEANING EQUIPMENT
RP-4100


USER MANUAL 3
PRODUCT SPECIFICATIONS
Model RP-4100
Voltage 220-240V
Frequency 50-60Hz
Carwash power 1500W
Carwash max pressure 130Bar
Motor Type Universal
Max Flow 8L/min
Max Air Flow 1.4m³/min
Vacuum cleaner power 800W
Max Blowing 16KPa
Supplied In Ronix color box
Includes
Quick connector Water inlet Turbo
nozzle Adjustable nozzle 5m PVC
hose Detergent bottle Gun sofa
Brush Flat nozzle soft hose middle
lance

MULTI-FUNCTIONAL CLEANING EQUIPMENT
4
PARTS LIST
Telescopic Handle
Fan Nozzle
Nozzle Holder
Water Outlet
Wheel
Gun
Blow air outlet
All purpose brush
Water Inlet
Dusting Brush
Turbo Nozzle
High-pressure
Hose
Spray Wand
Power Cord
Dust Tank
Air Inlet
Vacuum Hose
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Please read and comply with these original instructions prior to the initial
operation of your appliance and store them for later use or subsequent owners.
Apart from the notes contained herein the general safety provisions and
rules for the prevention of accidents of the legislator must be observed.
Warnings and notes that are attached on the appliance provide important
notes for the safe operation.
.HAZARD LEVELS
DANGER
Pointer to immediate danger, if not avoided, which leads to severe

USER MANUAL 5
injuries or death.
WARNING
Pointer to a possibly dangerous situation, if not avoided, which can lead
to severe injuries or death.
CAUTION
Pointer to a possibly dangerous situation, if not avoided, which can lead
to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation, which can lead to property damage.
.ELECTRIC COMPONENTS
DANGER
Risk of electric shock.
Never touch the mains plug and the socket with wet hands.
Check the power cord with mains Plug for damage prior to every use. Do
not use the machine if a supply cord or important parts of the machine
are damaged, e.g. safety devices, high pressure hoses, trigger gun.
All current-conducting parts in the working area must be protected
against jet water.
The mains plug and the coupling of an extension cable must be watertight
and must never lie in water. Moreover, the coupling may never lie on the
ground. The use of cable reels that ensure that the sockets are at least
60 mm above the ground is commended.
Make sure that the power cord or extension cable is not damaged by
running over, pinching, dragging or the like. Protect the power cords
from heat, oil, and sharp edges.
Always switch off the mains disconnecting switch when leaving the
appliance unattended.

MULTI-FUNCTIONAL CLEANING EQUIPMENT
6
WARNING
An unsuitable electrical extension cable can be hazardous. Only use an
electrical extension cable which has been approved and labeled for this
purpose and has an adequate cable cross-section outdoors: 1 - 10 m:
1.5 mm2;10 - 30 m: 2.5 mm2
Always fully unreel the extension cable from the cable drum.
An unsuitable electrical extension cable can be hazardous.
.SAFE HANDLING
DANGER
The user must be the appliance as intended. The person must consider
the local conditions and must pay attention to other persons in the
vicinity when working with the appliance.
Check important components, such as high pressure hose, hand
spray gun and safety installations, for damage prior to every operation.
Immediately replace damaged components. Do not operate appliance
with damaged components.
The appliance has been designed for use with the cleaning agent supplied
or recommended by the manufacturer. The use of the other cleaning agents
or chemicals may adversely affect the safety of the appliance.
High-pressure jets can be dangerous if subject to misuse. The jet must
not be directed at persons, live electrical equipment or the machine itself.
Do not direct the jet against yourself or others in order to clean clothes
or foot-wear.
Do not use the appliance within range of persons unless they wear
protective clothing.
Wear appropriate Personal Protective Equipment (PPE) while operating
the appliance.
Do not direct the jet against yourself or others in order to clean clothes
or foot-wear.

USER MANUAL 7
WARNING
The appliance must not be operated by children or untrained personnel.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capacities, or lack of experience
and knowledge.
Children must not play with this appliance.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
Supervise children to prevent them from playing with the appliance.
Create stability for the appliance prior to any work on or with the appliance
to prevent accidents damage.
The water jet that is emitted from the high-pressure nozzle results in a
repulsion power acting on the hand spray gun. Make sure that you have a
firm footing and are also holding the hand spray gun and spray lance firmly.
Never leave the appliance unattended as long as it is in operation.
ATTENTION
In case of extended breaks, switch the appliance off at the main switch
or pull the mains plug.
Do not operate the appliance at temperatures below 0ºC
CAUTION
Don’t pull the cord to unplug, when yon would like to retract the cable,
hold the plug and then press the Turn back button.
Keep off from ovens and stoves, etc.
Don’t suck at large fragments or sharp objects.
Don’t wrest, tramp and haul the hose.
Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.
Do not use to pick up flammable or combustible liquids, such as gasoline,
matches, or use in areas where they may be present.
Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.

MULTI-FUNCTIONAL CLEANING EQUIPMENT
8
Do not use without dust bag and/or filters in place.
.OTHER RISKS
DANGER
The appliance may not be operating in explosive atmospheres.
Risk of explosion - Do not spray flammable liquids.
Never draw in fluids containing solvents or undiluted acids and solvents!
This includes petrol, paint thinner and heating oil. The spray mist is highly
inflammable, explosive and poisonous. Do not use acetone, undiluted
acids and solvents, as they corrode the materials used on the appliance.
Never use the product with inflammable or toxic liquids, or liquids with
characteristics incompatible with its proper operation.
Keep packaging films away from children, there is a risk of suffocation!
WARNING
According to applicable regulations, the appliance must never be used
on the drinking water net without a system separator. Ensure that the
connection of your building water installation on which the high pressure
cleaner is operated is equipped with a system separator pursuant
Water that has flown through backflow preventers is considered to be non-potable.
High-pressure hoses, fittings and couplings are important for the safety
of the appliance. Only use high-pressure hoses, fittings and couplings
recommended by the manufacturer.
To ensure applicable safety, use only original spare parts from the
manufacturer or approved by the manufacturer.
Switch the product off and disconnect it from the power supply removing
the power plug from the socket outlet before assembly, cleaning,
adjustments, maintenance, storage and transportation or converting the
product to another function.
CAUTION
Mind the weight of the appliance when selecting the storage location

USER MANUAL 9
and during transport to prevent accidents or injuries.
Several hours of continuous use of the appliance can lead to numbness
in the hands in rare cases.
- Wear gloves.
- Keep hands warm.
- Take breaks at regular intervals. Working with detergent
WARNING
The improper use of detergents can cause severe injuries or oxidation.
Store cleaning agent away from the reach of children.
Discharge residual pressure before disconnecting the hose from the product.
Check before each use, and at regular intervals, that all metal fasteners
are tight and the product’s components are in good condition; inspect
for broken or worn parts.
Be aware of kick-back: Hold with Both Hands.
.RESIDUAL RISKS
Even if you are operating this product in accordance with all the safety
requirements, potential risks of injury and damage remain. The following
dangers can arise in connection with the structure and design of this
product:
Health defects resulting from vibration emission if the product is being
used over long periods of time or not adequately managed and properly
maintained.
Danger of injury and property damage caused by flying objects.
Injuries and damage to property due to broken accessories or the
sudden impact of hidden objects during use.
.SAFETY DEVICES
CAUTION
Safety installations serve the protection of the user and may not be
modified or by past.

MULTI-FUNCTIONAL CLEANING EQUIPMENT
10
.POWER SWITCH
The appliance switch prevents unintentional operation of the appliance.
.LOCK TRIGGER GUN
This lock locks the lever of the trigger gun and prevents the inadvertent
start of the appliance. Overflow valve with.
Water that has flowed through backflow preventers is considered to be
non-potable.
.PRESSURE SWITCH
If the lever on the trigger gun is released the pressure switch turns off the pump,
the high pressure jet is stopped. If the lever is pulled the pump is turned on again.
.MOTOR PROTECTION SWITCH
The motor protection switch off the device if the power consumption is high.
.PERSONAL PROTECTIVE EQUIPMENT
CAUTION
Wear protective clothing and safety goggles to protect against splash
back containing water or dirt.
During the use of high-pressure cleaner’s aerosols can develop. Inhaling
aerosols can cause health damage.
-Depending on the application, completely shielded nozzles (e.g. surface
cleaner)that significantly reduce the emission of aqueous aerosols can
be used for high-pressure cleaning.
-The use of such shielding is not possible with all applications.
PROPER USE
Use this pressure washer for private households only:
If connection is made to a potable water system, the system shall be
protected against backflow.
