FS-1-WL Connection Guide
(Connect with the GX-100)
This guide shows you how to pair the FS-1-WL
wirelessly to the GX-100 using BLE MIDI.
“Pairing” involves registering the MIDI device that
you want to use (making the devices recognize each
other) with the FS-1-WL.
Pairing the FS-1-WL with another compatible
device lets you control that device via MIDI from the
FS-1-WL.
* You must update the GX-100 to Ver. 1.11 or later
to use the FS-1-WL.
https://www.boss.info/support/
01© 2022 Roland Corporation
What is“BLE MIDI”?
“BLE MIDI” is the technology used to transmit
and receive MIDI messages wirelessly via
Bluetooth® LE standard.
This is ocially known as “MIDI over Bluetooth Low
Energy”.
2
Connecting the FS-1-WL to the
GX-100
1. Turn on the GX-100 (to which the BT-DUAL is
attached) and the FS-1-WL, and place them
nearby.
2. Hold down the pairing button on the BT-DUAL
until the Bluetooth indicator blinks rapidly.
3. Press the [Bluetooth] (INSTRUMENT) button on
the FS-1-WL.
The Bluetooth indicator on the FS-1-WL blinks
white, and pairing begins.
The Bluetooth indicators on both units stop
blinking and remain lit when pairing is nished,
and now the GX-100 and FS-1-WL are paired.
If connected correctly, it will be in the following
state.
BT-DUAL Bluetooth indicator Lit blue
FS-1-WL [Bluetooth] (INSTRUMENT)
indicator Lit white
* If the devices do not pair after one minute has
passed, pairing mode is automatically canceled.
* The units automatically connect next time they
are restarted.
3
The FS-1-WL remembers the information
for the last Bluetooth device to which it was
connected.
When connecting to a dierent device after
connecting to the GX-100, or when turning
o the power while the Bluetooth indicator is
blinking white (not connected), or when doing
a factory reset of the FS-1-WL, the unit does not
pair automatically.
In this case, you must start from step 1 to
congure the settings.
4
Connecting the GX-100, FS-1-WL,
and BOSS TONE STUDIO for GX-100
at the same time
When connecting at the same time, the following
two steps are required.
STEP 1: Connect the GX-100 and the FS-1-WL
STEP 2: Connect the FS-1-WL and the BOSS TONE
STUDIO for GX-100 (iOS/Android)
1. Turn on the GX-100 (to which the BT-DUAL is
attached) and the FS-1-WL, and place them
nearby.
2. Hold down the pairing button on the BT-DUAL
until the Bluetooth indicator blinks rapidly.
3. Press the [Bluetooth] (INSTRUMENT) button on
the FS-1-WL.
The [Bluetooth] (INSTRUMENT) indicator on the
FS-1-WL blinks white, and pairing begins.
The Bluetooth indicators on both units stop
blinking and remain lit when pairing is nished,
and now the GX-100 and FS-1-WL are paired.
5
4. Press the [Bluetooth] (Smartphone/PC) button on
the FS-1-WL.
The unit enters pairing mode, and the
[Bluetooth] (Smartphone/PC) indicator on the
FS-1-WL blinks blue.
5. On the BOSS TONE STUDIO for GX-100 app, select
“FS-1-WL+”.
The [Bluetooth] (Smartphone/PC) indicator on
the FS-1-WL stops blinking and remains lit when
pairing is nished.
If connected correctly, it will be in the following
state.
BT-DUAL Bluetooth indicator Lit blue
FS-1-WL [Bluetooth] (INSTRUMENT)
indicator
Lit white
FS-1-WL [Bluetooth] (Smartphone/PC)
indicator
Lit blue
BOSS TONE STUDIO for GX-100
device name FS-1-WL+
6
The FS-1-WL remembers the information for the
last Bluetooth device to which it was connected.
When connecting to a dierent device after
connecting to the GX-100, or when turning
o the power while the Bluetooth indicator is
blinking white (not connected), or when doing
a factory reset of the FS-1-WL, the unit does not
pair automatically.
In this case, you must start from step 1 to
congure the settings.
NOTE
You cannot use the BOSS TONE STUDIO for GX-
100 and the FS-1-WL Editor at the same time.
* The GX-100 and FS-1-WL are connected
automatically next time they are restarted.
To connect the BOSS TONE STUDIO for GX-100
you must perform steps 4 and 5 each time.
* If the devices do not pair after one minute has
passed, pairing mode is automatically canceled.
7
GX-100 Settings
Assign the CC numbers that correspond to the
FS-1-WL in ASSIGN SETTING - SOURCE, found in the
GX-100 “CTL/EXP” settings.
The default CC numbers for the FS-1-WL are set as
shown below.
Parameter MIDI CC numbers
PEDAL L CC#80
PEDAL C CC#81
PEDAL R CC#82
EXP CC#11
CTL1 CC#85
CTL2 CC#86
