QUICK START

SMC™FLEX

BULLETIN 150

This guide provides you with the basic information required to start up your SMC Flex controller. When reading

this document, look for this symbol “Step x” to guide you through the four basic steps required to install, start-up,

and program the SMC Flex.

The information provided in this Quick Start guide does not replace the User Manual which can be ordered or

downloaded by visiting www.ab.com. The Quick Start guide assumes the installer is a qualified person with

previous experience and basic understanding of electrical terminology, configuration procedures, required

equipment, and safety precautions.

For safety of maintenance personnel as well as others who might be exposed to electrical hazards associated with

maintenance activities, follow all local safety related work practices (for example, the NFPA 70E, Part II in the

United States). Maintenance personnel must be trained in the safety practices, procedures, and requirements that

pertain to their respective job assignments.

For detailed SMC Flex information including set-up, programming, precautions, and application considerations,

refer to the following documentation.

For product technical support:

Title Publication Number Availability

SMC Flex User Manual 150-UM008* www.ab.com/literature

SMC Flex Application Guide 150-AT002* www.ab.com/literature

Online Support www.ab.com/support

Telephone Support 440-646-5800 (option 2, option 4 or use

direct dial code 804)

2SMC™ Flex Quick Start

Step 1 - Read the General Precautions

• Only personnel familiar with the controller and associated machinery should plan or implement the

installation, start-up, and subsequent maintenance of the system. Failure to do this may result in personal injury

and/or equipment damage.

• Hazardous voltage is present in the motor circuit even when the SMC-Flex controller is off. To avoid shock

hazard, disconnect main power before working on the controller, motor, and control devices such as Start-Stop

push buttons. Procedures that require parts of the equipment to be energized during troubleshooting, testing,

etc., must be performed by properly qualified personnel, using appropriate local safety work practices and

precautionary measures.

• Failure of solid state power switching components can cause overheating due to a single-phase condition in the

motor. To prevent injury or equipment damage, the use of an isolation contactor or shunt trip type circuit

breaker on the line side of the SMC is recommended. This device should be capable of interrupting the motor’s

lock rotor current.

• Hazardous voltages that can cause shock, burn, or death are present on L1, L2, L3, T1, T2, T3, T4, T5, and T6.

Power terminal covers for units rated 108…480 A can be installed to prevent inadvertent contact with

terminals. Disconnect the main power before servicing the motor controller, motor, or associated wiring.

WARNING

SMC™ Flex Quick Start 3

• The controller contains ESD- (electrostatic discharge) sensitive parts and assemblies. Static control precautions

are required when installing, testing, servicing, or repairing the assembly. Component damage may result if

ESD control procedures are not followed. If you are not familiar with static control procedures, refer to

applicable ESD protection handbooks.

• Stopping modes are not intended to be used as an emergency stop. The user is responsible for determining

which stopping mode is best suited to the application. Refer to the applicable standards for emergency stop

requirements.

• Pump Stopping may cause motor heating depending on the mechanical dynamics of the pumping system.

Therefore, select the lowest stopping time setting that will satisfactorily stop the pump.

• Slow Speed running is not intended for continuous operation due to reduced motor cooling.

• The fan jumpers have been factory installed for 110/120V AC input. Refer to page 9 for 220/240V AC fan

wiring (5…480 A devices only).

• Two peripheral devices can be connected to the DPI port. The maximum output current through the DPI port is

280 mA.

• When installing or inspecting protective modules, make sure that the controller has been disconnected from the

power source. The protective module should be inspected periodically for damage or discoloration. Replace if

necessary.

• An incorrectly applied or installed controller can damage components or reduce product life. Wiring or

application errors such as under sizing the motor, over sizing the controller, incorrect or inadequate AC supply,

excessive ambient temperatures, or power quality may result in malfunction of the system.

• The Motor Overload parameter must be programmed by the installer to provide proper protection. Overload

configuration must be properly coordinated with the motor.

• This product has been designed and tested as Class A equipment for EMC compatibility. Use of the product in

domestic environments may cause radio interference, in which case, the installer may need to employ

additional mitigation methods.

• Disconnect the controller from the motor before measuring insulation resistance (IR) of the motor windings.

Voltages used for insulation resistance testing can cause SCR failure. Do not make any measurements on the

controller with an Insulation Resistance (IR or Megger) tester.

NOTICE

4SMC™ Flex Quick Start

Step 2 - Installation

Mounting

Controllers rated 625…1250 A

Device must be lifted only at the designated lift points identified with labels.

Enclosure Ratings

Standard Device Rating IP00 (NEMA Open Type)

Minimum Required Enclosure IP23 (NEMA Type 1)

Recommended Enclosure IP54 (NEMA Type 12), sizing guide in User Manual

Enclosure Internal Temperature -5…50 °C (23…122 °F)

Orientation and Clearance

Mounting Orientation Vertical

Minimum horizontal clearance 0 cm (0 in.)

Minimum vertical clearance 15 cm (6 in.)

Lifting Points

SMC™ Flex Quick Start 5

Dimensions

For detailed dimensions, please refer to the SMC Flex User Manual.

Dimensions are in millimeters (inches).

Controller Rating [A] Height (B) Width (A) Depth (C) Approximate Shipping

Weight

5…85 321.0 (12.60) 150.0 (5.90) 203.0 (8.00) 5.7 kg (12.5 lb)

108…135 443.7 (17.47) 196.4 (7.74) 212.2 (8.35) 15.0 kg (33.0 lb)

201…251 560.0 (22.05) 225.0 (8.86) 253.8 (9.99) 30.4 kg (67.0 lb)

317…480 600.0 (23.62) 290.0 (11.42) 276.5 (10.89) 45.8 kg (101 lb)

625…780 1041.1 (41.00) 596.9 (23.50) 346.2 (13.63) 179 kg (395 lb)

970…1250 1041.1 (41.00) 596.9 (23.50) 346.2 (13.63) 224 kg (495 lb)

23 24 25 26 27 28 29 30 31 32 33 34

11 12 13 14 15 16 17 18 19 20 21 22

SMC-Flex

Lang

Esc Sel

6SMC™ Flex Quick Start

Power Wiring

Refer to the product nameplate or the SMC Flex User Manual for device specific information.

Control Terminals

SMC Rating

[A]

Lug Kit

Cat. No.

Wire Strip

Length

Conductor

Range

Max. No. Lugs/Pole Tightening Torque

Line Side Load Side Wire - Lug Lug - Busbar

5…85 — 18…20 mm 2.5…85 mm2

(#14…3/0 AWG) ——

11.3 N•m

(100 lb•in) —

108…135 199-LF1 18…20 mm 16…120 mm2

(#6…250 MCM) 11

31 N•m

(275 lb•in)

23 N•m

(200 lb•in)

201…251 199-LF1 18…20 mm 16…120 mm2

(#6…250 MCM) 22

31 N•m

(275 lb•in)

23 N•m

(200 lb•in)

317…480 199-LG1 18…25 mm 25…240 mm2

(#4…500 MCM) 22

42 N•m

(375 lb•in)

28 N•m

(250 lb•in)

625…780 100-DL630 32 mm/64 mm 70…240 mm2

(2/0…500 MCM) 22

45 N•m

(400 lb•in)

68 N•m

(600 lb•in)

970 100-DL860 26 mm/48 mm 120…240 mm2

(4/0…500 MCM) 11

45 N•m

(400 lb•in)

68 N•m

(600 lb•in)

1250

100-DL630 32 mm/64 mm 70…240 mm2

(2/0…500 MCM) 11

45 N•m

(400 lb•in)

68 N•m

(600 lb•in)

100-DL860 26 mm/48 mm 120…240 mm2

(4/0…500 MCM) 11

Terminal Description Terminal Description Footnotes

11➂➃ Control Power Input (+) 23➀PTC Input

➀Do not connect any additional loads to these

terminals. These “parasitic” loads may cause

incorrect operation.

➁When set for External Bypass mode, the SMC

Flex can be used to control a properly sized

external contactor and overload once the motor

reaches full speed. The SMC-Flex overload

functionality is disabled in this mode.

➂RC Snubbers are required on inductive type

loads connected to auxiliary contacts.

➃Control power on units rated 625…1250 A is

pre-wired internally, from terminal block CP1.

12➂➃ Control Power Common 24➀PTC Input

13➀Controller Enable Input 25 Tachometer Input

14 Ground 26 Tachometer Input

15➀➂ Option Input #2 27➀Ground Fault Transformer Input

16➀➂ Option Input #1 28➀Ground Fault Transformer Input

17➀➂ Start Input 29➁➂ Aux Contact #2

18➀➂ Stop Input 30➁➂ Aux Contact #2

19➁➂ Aux Contact #1 31➁➂ Aux Contact #3

20➁➂ Aux Contact #1 32➁➂ Aux Contact #3

21 Not Used 33➁➂ Aux Contact #4

22 Not Used 34➁➂ Aux Contact #4

23 24 25 26 27 28 29 30 31 32 33 34

11 12 13 14 15 16 17 18 19 20 21 22

SMC™ Flex Quick Start 7

Control Wiring

Refer to the product nameplate for additional details. Depending on the specific application, additional control

circuit transformer VA capacity may be required.

Controllers rated 5…480 A

Control power is connected to the product through terminals 11 and 12.

Controllers rated 625…1250 A

Control power is connected to the product through terminal block CP1, at terminals 1 and 4.

Conductor Range 0.75…2.5 mm2(18…14 AWG)

Torque 0.6 N•m (5 lb•in)

Maximum Number of Wires per Terminal 2

AC Control Voltage Input 100…240V AC or 24V AC (+10/-15%)

Supply Type 1-phase, 50/60 Hz

24V AC Power Requirement 130VA

100…240V AC Power Requirement 75VA

DC Control Voltage Input 24V DC (+10/-15%)

Inrush Current 5 A

Inrush Time 250 ms

Transient Watts 60 W

Transient Time 500 ms

Staedy State Watts 24 W

Recommended Supply 1606-XLP50E

Fan Power Input (AC only) separately wired

F5…F135 20VA

F201…F251 40VA

F317…F480 60VA

Conductor Range 0.75…2.5 mm2(18…14 AWG)

Torque 0.6 N•m (5 lb•in)

Maximum Number of Wires per Terminal 2

Control Voltage Input 110/120V AC or 230/240V AC, (+10/-15%)

Supply Type 1-phase, 50/60 Hz

Control Power Input 800VA (includes controller, bypass, and fans)

8SMC™ Flex Quick Start

Typical Wiring Diagrams

Typical Power Wiring Examples

L1 L2 L3

T1 T2 T3

Motor

T6 T4 T5

L1 L2 L3

T1 T2 T3

Motor

Diagrams per NEMA Symbology

Delta Connection with

Isolation Contactor

(Optional Mode)

Line Connection with

Isolation Contactor

(Default Mode)

L1 L2 L3

U1V1W1

Diagrams per IEC Symbology

L1 L2 L3

T1 T2 T3

Motor

T6 T4 T5

Delta Connection with

Shorted SCR Protection

(Optional Mode)

Delta Connection with

Isolation Contactor

(Optional Mode)

Line Connection with

Isolation Contactor

(Default Mode)

Delta Connection with

Shorted SCR Protection

(Optional Mode)

U1V1W1W2U2V2

SMC™ Flex Quick Start 9

Typical Control Wiring Examples

11 12 13 14 15 16 17 18 19 20 21 22

23 24 25 26

SMC Flex Control Terminals

Aux#1

Aux#4

27 28 29 30 31 32 33 34

Aux#3Aux#2

Hold In

11 12 13 14 15 16 17 18 19 20 21 22

23 24 25 26

SMC Flex Control Terminals

Aux#1

Aux#4

27 28 29 30 31 32 33 34

Aux#3Aux#2

Hold In

2 Wire

Device

Up-to-Speed

Indication

Fault

Indication

L1 (L+)

N (L-)

Programming Notes:

Aux#4 – Set for Fault

Parameter#132 – Set for Diable

Programming Notes:

Aux#1 – Set for Normal

Aux#4 – Set for Up to Speed

FAN

Start

L1 (L+)

N (L-)

FAN

K1 A1

Stop

Connection Required

for DPI Control

Fig 1.x

3 Wire Control (With or Without DPI control), Isolation Contactor (K1),

and Up-to-Speed Indication

Fig 1.x

2 Wire Control (No DPI control or Option Stopping) with Fault Indication

Fan Power Terminations Example

(Separately Wired for F5...F480 Devices)

Factory Default Position

110/120 VAC

Optional Configuration

220/240 VAC

Jumpers

Supply

Supply Jumper

10 SMC™ Flex Quick Start

Typical Control Wiring Examples, Continued

11 12 13 14 15 16 17 18 19 20 21 22

23 24 25 26

SMC Flex Control Terminals

Aux#1

Aux#4

27 28 29 30 31 32 33 34

Aux#3Aux#2

Hold In

11 12 13 14 15 16 17 18 19 20 21 22

23 24 25 26

SMC Flex Control Terminals

Aux#1

Aux#4

27 28 29 30 31 32 33 34

Aux#3Aux#2

Hold In

Alarm

Indication

Programming Notes:

Aux#1 – Set for Normal

Aux#4 – Set fot Alarm

Start

L1 (L+)

N (L-)

FAN

K1 A1

Stop

Fig 1.x

3 Wire Control with Option Stopping, DPI control, Isolation Contactor (K1),

and Alarm Indication

Option Stop

Programming Notes:

Aux#1 – Set for Normal

Parameter

#87 - Logic Mask must be set for DPI Control.

- Value of 4 enables HIM control only

- Value of 32 enables Communication Port control only

- Value of 44 enables ALLDPI ports for control

L1 (L+)

N (L-)

FAN

K1 A1

Fig 1.x

Start and Stop Control via DPI Communication ONLY with Isolation

Contactor (K1)

Table des matières

Autres manuels Rockwell Automation Contrôleurs

Rockwell Automation

Rockwell Automation Allen-Bradley Logix 5000 Series Manuel du propriétaire

Rockwell Automation

Rockwell Automation Allen-Bradley PLC-2/30 Guide de configuration

Rockwell Automation

Rockwell Automation Allen-Bradley Logix5000 Manuel du propriétaire

Rockwell Automation

Rockwell Automation ALLEN-BRADLEY SMC-3 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley MicroLogix 1400 Manuel utilisateur

Rockwell Automation

Rockwell Automation GV3000/SE 230 Manuel d'installation et d'exploitation

Rockwell Automation

Rockwell Automation Allen-Bradley 1756 ControlLogix Manuel du propriétaire

Rockwell Automation

Rockwell Automation Allen-Bradley Logix 5000 Series Manuel utilisateur

Rockwell Automation

Rockwell Automation PowerFlex 753 Manuel utilisateur

Rockwell Automation

Rockwell Automation CompactLogix series Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley CompactLogix 5370 L2 Series Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley AADvance T9110 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley SMC-50 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1769-OA16 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley Micro800 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley CompactLogix 1769-L32E Manuel utilisateur

Rockwell Automation

Rockwell Automation MPMA Manuel utilisateur

Rockwell Automation

Rockwell Automation MicroLogix 1500 Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley AADvance T9110 Manuel utilisateur

Rockwell Automation

Rockwell Automation PowerFlex 700S Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 150-E Manuel utilisateur

Rockwell Automation

Rockwell Automation PowerFlex 40 Manuel utilisateur

Rockwell Automation

Rockwell Automation Samsung NX700 Series Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

3M MicroTouch EX113 Manuel utilisateur
