Wireless Bluetooth Headset

RF-QX4/RF-QX4-T/

RF-QX4-E/RF-QX4-J

User Guide

2RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

Wireless Bluetooth Headset

Contents

Important safety instructions.......................................................3

Introduction........................................................................................4

Features................................................................................................4

Package contents..................................................................4

Components ...........................................................................5

Using your headset ..........................................................................6

Headset functions.................................................................6

Charging the battery ...........................................................7

Turning the headset on or off...........................................7

Pairing the headset with a compatible phone...........7

Disconnecting the headset from the phone...............8

Reconnecting the headset to the phone .....................8

Making a call ...........................................................................8

Answering or ending a call................................................9

Rejecting a call .......................................................................9

Redialing the last number dialed....................................9

Muting a call............................................................................9

Using voice dialing ...............................................................9

Adjusting the headset volume...................................... 10

Switching between the headset and phone............ 10

Erasing all pairing information......................................10

Turning the indicator on or off...................................... 10

Checking the battery status ...........................................11

Resetting the headset (hardware reset)..................... 11

RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

Maintaining...................................................................................... 11

Troubleshooting............................................................................. 12

Specifications.................................................................................. 12

Legal notices.................................................................................... 12

One-year limited warranty ......................................................... 13

Important safety instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not expose the headset to water.

6Clean only with a dry cloth.

7Do not plug in the wall charger near any heat sources such as

radiators, heat registers, stoves, or other chargers that produce

heat.

8Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with one

wider than the other. A grounding type plug has two blades and a

third grounding prong. The wide blade or the third prong are

provided for your safety. If the provided plug does not fit into your

outlet, consult an electrician for replacement of the obsolete

outlet.

9Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

where they exit from the charger.

10 Only use attachments/accessories specified by the manufacturer.

11 Unplug this charger during lightning storms or when unused for

long periods of time.

12 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

13 To reduce the risk of fire or electric shock, do not expose the

charger to rain, moisture, dripping, or splashing.

4RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

14 An apparatus with a three-prong, grounding-type plug is a Class I

apparatus, which needs to be grounded to prevent possible

electric shock. Make sure that you connect this Class I device to a

grounding-type, three-prong outlet.

15 In order to charge your headset correctly, the wall outlet must be

in correct working condition.

16 Batteries should not be exposed to excessive heat.

Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type.

Warning: If the volume is set too high, excessive sound pressure from earphones and

headphones can cause hearing loss.

Introduction

Congratulations on your purchase of the RF-QX4 wireless headset.

This headset represents the state of the art in wireless headset design

and is designed for reliable and trouble-free performance.

Note: Your RF-QX4 model number may end in a letter depending on what region you

are in. We use RF-QX4 in this User Guide to refer to all of the following models:

•RF-QX4—United States

•RF-QX4-T—Canada

•RF-QX4-E—Europe

•RF-QX4-J—Japan

Features

Package contents

•RF-QX4headset

• Ear loop

• Earbuds (small, medium, and large)

• USB charging cable and A/C wall charger

• Quick Setup Guide

Note: The ear loop and medium earbud come preattached.

RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

Components

#Component Description

Power/Send/End button • Switches the headset on and off.

• Answers incoming calls.

• Ends active calls.

• Rejects incoming calls.

2Microphone Transmits your voice.

3Earpiece Transmits the caller’s voice.

4– (volume down button) Press to decrease the headset volume.

Indicator light Power on—Lights solid green for one second and the headset beeps once.

Pairing mode— Rapidly flashes green-red.

The flashing continues for approximately three minutes or until the headset is

connected to a compatible phone. If the headset is not connected to a phone

during this time, the headset enters connectable status.

Connectable—Flashes green once every 2.5 seconds.

Connection active—Flashes green every 5 seconds.

Incoming call—Flashes green two times every 1 second.

Active call—Flashes green every 5 seconds.

Power off—Lights solid red for 1 second and the headset beeps once.

Low battery—Alternately flashes red and green, and the headset beeps

every 300 seconds.

6RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

Using your headset

Headset functions

6+ (volume up button) Press to increase the headset volume.

Charger connector Connect the USB charging cable to the AC adapter and a power outlet to

charge the battery.

Connect the USB charging cable to this jack and to a USB port on a computer.

Headset function Button presses

Voice dial Press the Power/Send/End button.

Redial Double-press the Power/Send/End button.

Answer a call Press the Power/Send/End button.

End (cancel) a call Press and hold the Power/Send/End button for

two seconds.

Reject a call Double-press the Power/Send/End button.

Transfer a call between connected

devices

Double-press the Power/Send/End button while

in a call to transfer the call to the handset.

Mute or unmute Press the +(volume up) and –(volume down)

buttons at the same time.

Adjust the headset volume Press the +(volume up) or –(volume down)

button.

Erase all pairing information When the headset is turned off, press and hold the

Power/Send/End and –(volume down) buttons.

Turn the indicator on When the headset is connected to a phone, press

and hold the Power/Send/End and

+(volume up) buttons for three seconds.

Turn the indicator off When the headset is connected to a phone, press

and hold the Power/Send/End and

–(volume down) buttons for three seconds.

Check the battery status Press and hold the Power/Send/End for two

seconds.

#Component Description

RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

Charging the battery

Before using the headset, you must charge the battery for

approximately two hours. When the battery is fully charged, it

provides up to 7 hours of talk time or up to 250 hours of standby

time.

To charge the battery:

• Connect the AC wall charger to the headset and to a power outlet.

While the battery is charging, the indicator lights red. When the

battery is fully charged, the indicator lights green.

Turning the headset on or off

To turn the headset on or off:

1To turn on the headset, press and hold the Power/Send/End button

for about two seconds. The headset beeps and the indicator blinks

green. (The first time you turn on the headset, you have to press

and hold the power button for five seconds.)

2To turn off the headset, press and hold the power button for

about four seconds. The headset beeps and the indicator briefly

lights red.

Pairing the headset with a compatible phone

Pairing is the process of linking the headset with a Bluetooth-enabled

mobile phone. After you pair the headset with a phone, you can only

use the headset with the paired phone. If you want to use the

headset with a different phone, you must repeat the pairing process

with the new phone. The headset can be paired with up to eight

compatible phones, but it can be connected to only one phone at a

time.

To pair the headset with a compatible phone:

1Make sure that a compatible phone is turned on and within 33

feet (10 meters) of the headset.

2Turn on the headset and make sure that the battery is fully

charged.

3Press and hold the Power/Send/End button for about four seconds.

The indicator rapidly flashes green.

4Release the button. The headset is now in pairing mode.

8RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

5Activate the Bluetooth connection from the phone. See the

documentation that came with the phone for instructions.

6Set the phone to start searching for Bluetooth devices.

7Select RF-QX4 from the list of found devices displayed on the

phone.

8If necessary, enter the PIN code 0000 to pair and connect the

headset with your phone. With some phones, you need to make a

connection separately after pairing.

Disconnecting the headset from the phone

To disconnect the headset from the phone:

• Turn off the headset.

Or,

• Disconnect the headset in the phone’s menu.

Or,

• Move the headset more than 33 feet (10 meters) away from the

phone.

Note: You do not need to delete the pairing with the headset to disconnect the

headset. When you reconnect the headset to a phone it has been paired with, you do

not have to enter the code 0000 again.

Reconnecting the headset to the phone

Note: The headset connects to the last connected phone by default. If the last phone is

out of the Bluetooth operating range or you are not using the last phone, the headset

searches and connects to the other paired phones.

To reconnect the headset to the last phone used:

• If the headset is turned off, turn it on. It automatically connects to

the phone.

Note: If the headset is out of Bluetooth operating range (33 feet/10 meters), the

headset sounds a warning tone. If you move the headset back into operating range

within two minutes, it automatically reconnects with the phone.

If the headset is out of Bluetooth operating range for more than two minutes, go

back into range then press and hold the Power/Send/End button until a beep sounds to

indicate the connection is reactivated.

Making a call

To make a call:

• Use the phone in the normal way. See the phone’s documentation

for instructions.

RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

Answering or ending a call

When you receive a call, you hear a ringing tone through the headset.

To answer or end a call:

• Press the Power/Send/End button to answer a call.

• Press and hold the Power/Send/End button for two seconds to end a

call.

Note: Some phones have an Auto Answer function. If the phone has this function, you

can use it with the headset.

Rejecting a call

To reject a call:

• Double-press the Power/Send/End button.

Redialing the last number dialed

To redial the last number dialed:

• While no call is in progress, double-press the Power/Send/End

button.

Muting a call

To mute a call:

• Briefly press the volume up and volume down buttons at the

same time. Press the volume up and volume down buttons again

to unmute the call.

Using voice dialing

If the paired phone has a voice dialing feature, you can use it with the

headset.

To use voice dialing:

• When no call is in progress, press the Power/Send/End button. A tone

indicates that you can start saying the voice tag. The phone plays

the voice tag and dials the related phone number.

10 RF-QX4/RF-QX4-T/RF-QX4-E/RF-QX4-J

Adjusting the headset volume

To adjust the headset volume:

• Press the +(volume up) or –(volume down) button.

Switching between the headset and phone

To switch between the headset and phone:

• While a call is in progress, double-press the Power/Send/End button

or use the switching function on the phone.

Erasing all pairing information

To erase all pairing information:

1Turn off the headset.

2At the same time, press and hold the Power/Send/End and –(volume

down) buttons until the indicator flashes red and green

alternately. After erasing all pairing information, the headset

enters pairing mode automatically.

Turning the indicator on or off

You can turn the indicator on or off when the headset is connected to

a phone.

To turn the indicator on or off:

• At the same time, press the Power/Send/End button and the

+(volume up) button for about three seconds to turn on the

indicator.

• At the same time, press the Power/Send/End button and the

–(volume down) button for about three seconds to turn off the

indicator.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rocket Fish casque

Rocket Fish

Rocket Fish RF-MAB2 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX3 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX5 Manuel utilisateur

Rocket Fish

Rocket Fish RF-MAB2 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX3 Manuel de la liste des pièces

Rocket Fish

Rocket Fish RF-SH230 Manuel utilisateur

Rocket Fish

Rocket Fish RF-GPS31126 Manuel d'installation et d'exploitation

Rocket Fish

Rocket Fish RF-EX7 Manuel utilisateur

Rocket Fish

Rocket Fish RE-GUV1202 Manuel utilisateur

Rocket Fish

Rocket Fish RF-GPS31204 Manuel utilisateur

Rocket Fish

Rocket Fish RF-GPS3007 Manuel utilisateur

Rocket Fish

Rocket Fish RF-PH4101 Manuel de la liste des pièces

Rocket Fish

Rocket Fish RF-MAB2 Manuel de la liste des pièces

Rocket Fish

Rocket Fish RF-BTHP01 Manuel utilisateur

Rocket Fish

Rocket Fish RF-PH4101 Manuel d'installation et d'exploitation

Rocket Fish

Rocket Fish RF-QX5 Manuel utilisateur

Rocket Fish

Rocket Fish RF-GUV1201 Manuel utilisateur

Rocket Fish

Rocket Fish RF-BTHP02 Guide de démarrage rapide

Rocket Fish

Rocket Fish RF-BTHP02 Manuel utilisateur

Rocket Fish

Rocket Fish RF-SH430 Manuel utilisateur

Rocket Fish

Rocket Fish RF-PH4101 Manuel utilisateur

Rocket Fish

Rocket Fish RF-QX3 Guide de démarrage rapide

Rocket Fish

Rocket Fish RF-QX4-E Manuel utilisateur

Rocket Fish

Rocket Fish RF-GPS31204 Manuel de la liste des pièces

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Plantronics

Plantronics Blackwire 3200 Series Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur
