Roborock S7 Manuel utilisateur

Roborock S7

Read this user manual carefully before using this product and

store it properly for future reference.

Robotic Vacuum Cleaner User Manual

004

Contents

005 Safety Information

009 Roborock Robotic Vacuum Cleaner Troubleshooting

010 Product Overview

016 Installation

021 Connect to the App

023 Instructions

027 Routine Maintenance

037 Basic Parameters

038 Errors

040 Common Issues

042 EU Declaration of Conformity

046 WEEE Information

047 Warranty Information

005

Restrictions

This product is designed for indoor oor cleaning only, do not use it outdoors

(such as on an open-ended terrace), on any surface other than the ground (such

as a sofa), or in any commercial or industrial environment.

Do not use this product on elevated surfaces without barriers such as the oor

of a loft, an open-ended terrace, or on top of furniture.

Do not use the product when the ambient temperature is higher than

40°C (104°F), lower than 4°C (39°F).

Before using the product, move wires o the ground or place them to the side to

prevent them being pulled on by the cleaner.

To prevent blocking the product and to avoid damage to valuables, remove light-

weight items (such as plastic bags) and fragile objects (such as vases) from the

oor before cleaning.

Children should be supervised to ensure that they do not play with the appliance.

This product is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the

product by a person responsible for their safety (CB).

Safety Information

006

Safety Information

This product can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of

the product in a safe way and understand the hazards involved. Children shall

not play with the product. Cleaning and user maintenance shall not be made by

children without supervision (EU).

Keep the main brush cleaning tools out of reach of children.

Do not place any object (including children and pets) on the product, whether it

is in operation or not.

Keep hair, loose clothing, ngers, and all parts of the body away from openings

and moving parts.

Do not use the product on burning objects (such as cigarette butts).

Do not use the product on high pile carpets (product eectiveness may also be

reduced on dark carpets).

Do not use the product to clean hard or sharp objects (such as decoration

wastes, glass and nails).

Do not carry the product using the vertical bumper, upper cover or bumper.

The product must be switched o and the plug must be removed from socket

outlet before cleaning or maintaining the product.

007

Do not charge non-rechargeable batteries.

For the purposes of recharging the battery, only use the detachable supply unit

roborock CDZ11RR or CDZ12RR provided with this product.

Do not dismantle, repair or modify the battery or charging dock.

Keep the charging dock away from heat (such as radiators).

Do not wipe the charging contacts with wet cloth or wet hands.

If the power cord is damaged, stop using it immediately. It must be replaced by

the manufacturer, its service agent, or similarly qualied persons to avoid a hazard.

Make sure the product is powered o before shipment.

Use of the original packaging is advised.

Safety Information

Battery and Charging

WARNING

Do not use wet cloth or liquids for cleaning the product.

Use the product according to the manual. Any loss or damage caused from im-

proper use will be borne by the user.

This product contains batteries that are only replaceable by skilled persons.

008

If placing the robot into storage, charge it fully and turn it o before placing it in

a cool dry place. Recharge it at least every three months to prevent the battery

over discharging.

To satisfy RF exposure requirements, a separation distance of 20 cm or more

should be maintained between this device and persons during device operation.

To ensure compliance, operations at closer than this distance is not recommended.

The antenna used for this transmitter must not be co-located in conjunction with

any other antenna or transmitter.

Safety Information

009

Roborock Robotic Vacuum Cleaner Troubleshooting

Name Troubleshooting

Robot

Problem listed in the User Manual

Charging dock

The product cannot be powered on

The main brush, side brush, fan, or main wheels do not work

Power cable

The robot does not receive power

The charging dock cannot be supplied with power

010

Robot

Clean/Power

Press to clean

Press and hold to

turn on/o

Power Indicator

Dock

Press to return to the dock

Note: Press any button to pause the robot when cleaning or returning to

the dock.

Spot Clean/Child Lock

Press to Spot clean

Press and hold for 3 seconds

to turn the child lock on/o

White: Vacuuming

Blue: Vacuuming and mopping

Orange: Alert

Green: Docking/Recharging

Status Indicator Light

Product Overview

White: Battery level ≥ 20%

Red: Battery level < 20%

Breathing: Charging or

starting up

Flashing red quickly: Error

011

Parts List

Charging Dock VibraRise Mop Cloth Mount

VibraRise Mop ClothPower Cable

Product Overview

012

Robot

System Reset

Air Vent

VibraRise Mop

Cloth Mount

Water Tank

WiFi Indicator

Dustbin

Filter Cover

Dustbin Latch

Washable Filter

Filter Cover Latch



Product Overview

Note: Remove this piece if using

the Roborock Auto-Empty Dock.

Available for purchase separately.

Visit www.roborock.com for

details.
