RKI Instruments EAGLE 2 Manuel utilisateur

www.rkiinstruments.com

Eagle 2 Data Logger

Management Program

Operator’s Manual

Part Number: 71-0170RK

Revision: H

Released: 8/9/21

2 •

Warranty

RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in materials and

workmanship, and performance for a period of one year from date of shipment from RKI Instruments,

Inc. Any parts found defective within that period will be repaired or replaced, at our option, free of

charge. This warranty does not apply to those items which by their nature are subject to deterioration

or consumption in normal service, and which must be cleaned, repaired, or replaced on a routine basis.

Examples of such items are:

Warranty is voided by abuse including mechanical damage, alteration, rough handling, or repairs

procedures not in accordance with the instruction manual. This warranty indicates the full extent of our

liability, and we are not responsible for removal or replacement costs, local repair costs, transportation

costs, or contingent expenses incurred without our prior approval.

This warranty is expressly in lieu of any and all other warranties and representations, expressed or

implied, and all other obligations or liabilities on the part of RKI Instruments, Inc. including but not

limited to the warranty of merchantability or fitness for a particular purpose. In no event shall RKI

Instruments, Inc. be liable for indirect, incidental, or consequential loss or damage of any kind

connected with the use of its products or failure of its products to function or operate properly.

This warranty covers instruments and parts sold to users only by authorized distributors, dealers, and

representatives as appointed by RKI Instruments, Inc.

We do not assume indemnification for any accident or damage caused by the operation of this gas

monitor and our warranty is limited to replacement of parts or our complete goods.

Absorbent cartridges Batteries

Pump diaphragms and valves Filter elements

Fuses

• 3

Table of Contents

Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Eagle 2 Data Logging Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Overwriting Data in the Eagle 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 2: Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Installing the Eagle 2 Data Logger Management Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

IrDA Downloading Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 3: Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Launching the Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting an Instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Downloading Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Turning Off an Instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Chapter 4: Instrument Information Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Chapter 5: Data Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Calibration History Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Event Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Interval Trend Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Alarm Trend Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Deleting Data in the Data Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Changing the Delete Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Chapter 6: Last Calibration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Viewing & Printing Last Calibration Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Deleting Last Calibration Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Chapter 7: Set Window (Calibrating An Eagle 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Chapter 8: Set Window (Instrument Parameters) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Changing Instrument Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Changing User and Station IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Conversion Table Tab for Catalytic Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

4 •

PID Sensor Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Obtaining a Relative Response Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Chapter 9: Set Window (Program Appearance) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Chapter 10: Spare Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

CAUTION: Read and understand this manual before using the Eagle 2 Data Logger

Management Program. Also read and understand the Eagle 2 Operator’s Manual

included with the Eagle 2 portable gas detector.

Chapter 1: Introduction • 5

Chapter 1: Introduction

Overview

Using an advanced detection system consisting of up to six gas sensors, the Eagle 2 Gas Monitor

detects the presence of combustible gases, oxygen (O2), carbon monoxide (CO), hydrogen sulfide

(H2S), and 2 other gases simultaneously. The Eagle 2’s compact size and easy-to-use design make it

ideally suited for a wide range of applications as described in the Eagle 2 Operator’s Manual. Please

read the Eagle 2 Operator’s Manual first before using the Eagle 2 Data Logger Management Program.

The Eagle 2 Data Logger Management Program downloads stored data in the Eagle 2 to a Windows-

based PC. After the data has been downloaded, you can view, save, or print it using your computer and

the Eagle 2 Data Logger Management Program.

The purpose of this manual is to explain how to use and set up the Eagle 2 Data Logger Management

Program. You will learn how to:

• install and launch the program

• install the downloading cable (if needed)

• download data from the Eagle 2

• view, print, and save data

• change data logging parameters

• perform a calibration

• change the appearance of the program screens

• change the color of graphed readings for a particular gas

Before you get started, be sure to review the system requirements in the next section.

CAUTION: The Eagle 2 detects oxygen deficiency and elevated levels of oxygen, combustible

gases, carbon monoxide, and hydrogen sulfide, all of which can be dangerous or life

threatening. When using the Eagle 2, you must follow the instructions and warnings

in the Eagle 2 Operator’s Manual to assure proper and safe operation of the unit

and to minimize the risk of personal injury.

CAUTION: The operator of this instrument is advised that if the equipment is used in a manner

not specified in this manual, the protection provided by the equipment may be

impaired.

6 • Chapter 1: Introduction

System Requirements

To use the Eagle 2 Data Logger Management Program , your personal computer must meet the

following requirements:

•Operating Systems: Windows®7, Windows®8, or Windows® 10.

•Processor: IBM®compatible PC running Pentium®2 or higher.

•Memory: 32 MB RAM minimum

•Available Hard Disk Space: 32 MB minimum

• Infrared port or

USB port and a USB/IrDA adapter cable

Eagle 2 Data Logging Capacity

Table 1 above lists the Eagle 2’s data logging capacity for a 4-gas unit for each interval trend time

setting assuming no alarms or other events. The interval trend time setting can be set using the Set

Window (see “Changing Instrument Parameters” on page 55). It can also be set in the Eagle 2 Setup

Mode (see the Eagle 2 Operator’s Manual).

Table 1: Data Logging Capacity, 4-gas Eagle 2

Interval Trend Time Data Logging Hours

5 seconds 239 hours (10 days)

10 seconds 479 hours (20 days)

20 seconds 959 hours (40 days)

30 seconds 1439 hours (60 days)

60 seconds 2879 hours (120 days)

180 seconds (3 minutes) 8639 hours (360 days)

300 seconds (5 minutes) 14,399 hours (600 days)

600 seconds (10 minutes) 28,798 hours (2,000 days)

Chapter 1: Introduction • 7

Overwriting Data in the Eagle 2

The Eagle 2’s Data Log Overwrite function is factory set to On so that when the Eagle 2’s data logging

memory becomes full, it begins to overwrite the oldest interval trend data with new internal trend data.

Download data regularly to avoid over-writing data in the Eagle 2 before it can be downloaded. The

Data Log Overwrite function is accessible using the Eagle 2 Setup Mode. To set the Data Log

Overwrite function to Off, see the Eagle 2 Operator’s Manual. When the Data Log Overwrite function

is set to off, the Eagle 2 will stop saving data when its data logging memory is full.

The Data Log Overwrite function applies only to interval trend data. All other data, such as alarm trend

data, event data, or calibration data, will continue to be saved when the memory is full. If the

maximum number of each of these types of data has been reached, the oldest data will be overwritten.

8 • Chapter 2: Setup

Chapter 2: Setup

Installing the Eagle 2 Data Logger Management Program

1. Launch Windows®.

2. Exit from all applications and open windows.

3. Go to www.rkiinstruments.com/eagle2.

4. Click on the Download tab.

5. Click the EAGLE 2 Data Logger Software link.

6. A .zip file will begin to download. Select whether you want to open or save the .zip file.

7. Extract the contents of the .zip file.

8. Double click the setup.exe file.

9. After a few seconds, a screen appears indicating that the InstallShield Wizard is preparing to install

the Data Logger Management Program, then the Eagle 2 InstallShield Wizard window appears to

guide you through installation.

10. Follow the on-screen instructions in the InstallShield Wizard Window to install the program.

11. If the InstallShield Wizard finds versions of Windows®files on your computer newer than those in

the downloaded .zip file, it will ask you if you want to keep these newer files. Click Ye s .

12. When the InstallShield Wizard indicates that installation is complete, click the Finish button.

Figure 1: Eagle 2 Data Management Installation Program

Chapter 2: Setup • 9

IrDA Downloading Cable

The Eagle 2 communicates with a computer via an on-board infrared communication port that

complies with IrDA protocol standards.

NOTE: If your computer has a built-in infrared port, you do not need an adapter cable to download

data.

If your computer does not have an infrared port, you will need to install an IrDA/USB adapter cable on

your computer to use the Eagle 2 Data Logger Management Program with your Eagle 2. The IrDA/

USB cable is available from RKI Instruments, Inc. See the Spare Parts List at the end of this manual

for the RKI part number.

Some versions of Windows®already have several infrared device drivers loaded in Windows®and

will automatically recognize a cable during the installation process and guide you in installing the

drivers. Other versions of Windows®will require you to load device drivers provided by the

manufacturer of the cable during the installation process. RKI makes no warranty for the operation or

compatibility of the drivers with any particular device.

Installing an IrDA Adapter Cable

After installing the Eagle 2 Data Logger Management Program, connect the IrDA/USB cable to your

computer and follow the manufacturer’s instructions for installing the cable on your computer. Make

sure the cable is compatible with your Windows®operating system.

If you do not have instructions from the cable manufacturer for installing your cable, see your

Windows documentation. In general, you must go to the Control Panel and use the Add Hardware

Wizard to install the cable drivers.

Windows®Infrared Operation Note

When using an IrDA adapter cable and the Eagle 2 Data Logger Management Program on a

Windows®computer, it is necessary to make a special setting in the Infrared Configuration window for

proper communication between the Eagle 2 and the Eagle 2 Data Logger Management Program. This

must be done before attempting to use the program.

NOTE: If you have a Windows 7 computer, the Infrared Configuration window may not appear. If

the Infrared Configuration window does not appear, disregard the directions below.

Follow these steps to make this setting:

1. Click Start on the Windows®Icon Tray.

2. If Control Panel is available to select in the Start menu, select it. The Control Panel will appear.

If Control Panel is not selectable in the Start menu but Settings is, select Settings, then select

Control Panel. The Control Panel will appear.

10 • Chapter 2: Setup

3. If the Control Panel is viewed by category, open the Hardware and Sound folder then click “Send

or Receive a File” under the Infrared section. The Infrared Configuration window will appear.

If the Control Panel is viewed by icon, click the Infrared icon. The Infrared Configuration

window will appear.

4. Click on the Image Transfer tab.

5. Deselect the selection box for “Allow digital cameras to use infrared to transfer images directly to

my computer”.

6. Click OK.

7. Close the Control Panel window.

Figure 2: Image Transfer Tab

Deselect

Autres manuels pour EAGLE 2

Table des matières

Autres manuels RKI Instruments Enregistreur de données

RKI Instruments

RKI Instruments GX-6000 Manuel utilisateur

Manuels Enregistreur de données populaires d'autres marques

TESTO

TESTO 176 Manuel utilisateur

HT Italia

HT Italia XL421 Manuel utilisateur

HBM

HBM SOMAT XR CX22B-R Manuel utilisateur

Agtrix

Agtrix 380i Manuel utilisateur

Hobo

Hobo H8 Pro Manuel utilisateur

Beijing ART Tech

Beijing ART Tech PCI2320 Manuel utilisateur

Athena

Athena GET SL1 Manuel utilisateur

Motec Systems

Motec Systems C185 Manuel utilisateur

Beijing ART Tech

Beijing ART Tech USB2832 Manuel utilisateur

Rotronic

Rotronic HygroLog HL20 Manuel utilisateur

MRC

MRC DW-6092 Manuel utilisateur

Racelogic

Racelogic VBOX LapTimer Manuel utilisateur

Edu-Logger

Edu-Logger 900-240 Manuel utilisateur

Elma

Elma DT173 Manuel utilisateur

MadgeTech

MadgeTech PRTemp140 Fiche technique

Comet

Comet U0121M Manuel utilisateur

pico Technology

pico Technology PT-104 Manuel utilisateur

Soil Instruments

Soil Instruments GTecLink Manuel utilisateur
