Rite‑Hite®Installation/Service/Owner's Manual FasTrax®XL
Publication: AMEN00316 2020-07-06 3
NOTICE TO USER
Thank you for purchasing a Rite-Hite product.
The FasTrax XL is a unique fabric door that helps to
maintain and separate dierent atmospheres.
Read and understand manual before beginning the
installation, operation or servicing of this door.
Before work begins, verify space clearance requirements
from architectural drawings.
Use i-COMMTM 3 manual with this manual for complete
installation and operation instructions.
Complete "Final Checklist" (page 58) before leaving site.
Store manual near the unit.
The English version of this manual shall prevail over any
error in, or conicting interpretation of, any translations.
Rite-Hite reserves the right to substitute and/or modify
parts and drawings (electrical and architectural) from
those contained in this manual. Separate prints may be
included with the unit.
When ordering parts, include your door serial or RHC
number located on the label on the side support tube
(see Figure 1 on page 6).
For best results, have this product serviced by an
authorized Rite-Hite representative.
A Planned Maintenance Program (P.M.P.), customized to
your specic operation is available and recommended.
For a P.M.P., contact your local Rite-Hite representative
or Rite-Hite technical support at (U.S.) 1-563-589-2722,
1-888-456-3625, (S.A.) +55 21 99616 4421,
(E.U.) +49-5693 98700.
NOTICE
Store dry between 40° and 80° F, [4° and 27° C].
The Rite-Hite®products in this manual are covered by one or more
of the following U.S. patents: 6192960, 6212826, 6330763, 6360487,
6481487, 6560927, 6598648, 6615898, 6688374, 6837296, 6901703,
6964289, 7034682, 7045764, 7111661, 7114753, 7151450, 7578097,
7699089, 7748431, 7757437, 8037921, 8167020, 8113265, 8863815,
8857498, 9222304, 9388634, 9309717, 9493984, 9556672, 9631427,
9771754 and may be covered by additional pending U.S. and foreign
patent applications.
Rite-Hite®, FasTrax®, FasTrax®FR, FasTrax®FR LD, FasTrax® LD,
FasTrax®Washdown, FasTrax®XL, i-COMM™ are trademarks
of Rite-Hite.
Manufactured by Rite-Hite Doors, Inc.
FCC Compliance
NOTE:This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
NOTE: Changes or modications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesirable operation.
