Instruction Manual
& Operating Guide
Weigh Platforms
Spring Balance Model 327G
Electronic Model 327GE
Spring Balance Model 327G
Electronic Model 327GE
Contents
Weigh Platforms - Models 327g & 327ge
Pages
Safety Notes and Warnings ...................................................... 4
Introduction and Intended Use / Features and Specifications .... 5
Installation ............................................................................... 6
Fitting the Spring Balance Head................................................ 7
Operating Instructions.............................................................. 8
Maintenance ............................................................................ 9
Electronic Weigh Head - Instructions for use.................... 10 - 13
Electronic Weigh Head - Safe Installation / Maintenance ........ 14
3
Rev. A
4
Safety Notes and Warnings
!Ensure the operator in charge of the weighing operation is an experienced stock
person who can maintain a high standard of animal welfare.
Ensure that there is sufficient space in the area designated for weighing to allow the
operator to work safely and efficiently.
The adjoining Race and Penning to the weigher should be of sufficient build for the
safety of both animals and operators.
Do not have any auxiliary hurdles or gates attached directly to the crate as this will
provide inaccurate readings. If hurdles are to be used these should be attached to
the posts provided which fit into the sockets on the weigh platform base.
!
!
Note: Check also the instruction leaflet provided by Salter Brecknell (Electronic weigh head
manufacturer) provided with this product for details on EMC compliance and declaration of
conformity.
Retain all instructions in a safe place for future reference.
!
5
Introduction and Intended Use
Ritchie weigh platforms models 327G (spring balance) and 327GE (electronic) were designed
for, and intended to be used by, the agricultural industry for the weighing of animals.
The unit has been designed to operate with the Ritchie Cattle handling Crate model numbers
300g, 339 and 339g.
However other makes of cattle handling crates may be fitted using the fastenings supplied and
fitted in accordance with our instructions.
The platform requires a ‘back weight’ of 350 - 500 kgs which is normally provided by the unladen
weight of a handling crate in order to zero the weigh head.
The platform may be used for other weighing purposes providing an alternative ‘back weight’ is
fitted. i.e. Heavy steel plate floor.
Note:- The platform does not conform to DTI certification and is illegal to be used for selling
by weight.
These weighers should only be used by an experienced stock person, who can maintain
a high standard of animal welfare.
Deviations from the intended use should not take place without the notice and approval
of David Ritchie (Implements) Ltd.
!Robust RHS frame
!Pivotting centre pillar allows complete access to side of cattle crate.
!Eight sealed self aligning bearings.
!Ground clearance allows access by forklift tines for around farm movement.
!Raised corner pads to keep mechanism muck free.
!Lugsare providedtoattach theRitchie CattleHandling Crate No. 300g, 339 and 339g allowing
easy transportation as a complete unit.
!Hot Dipped galvanised finish.
Weigh Heads:-
!Spring Balance model 327G - weight capacity 1500 kgs.
!Electronic weigh head model 327GE - is supplied complete with the Salter electronic weigh
head no. LS300, which can read to 1500 kgs and is rated to IP65 making it ideal for use in the
harshest of environments. The unit is fitted with an internal battery and is supplied with a
charger unit. Features include on/off zero, lbs/kgs, print and hold facilities.
Features & Specifications
6
Installation
Site the weigh platform on a level and firm
base.Failure todo somay result ininaccurate
weighing.
The crate can be positioned with the weigh
head on either the left or right side.
Note that the weigh platform has a single
pivot to one end with a double pivot to the
opposite end.
Lower the Ritchie Continental Cattle Crate
or improved access cattle crate onto the
weigh platform and attach the single pivot
end first using the ‘U’ bolts provided.
Important! -Ensure that the load supports
are sitting parallel to the crate floor as Fig 1,
with the ‘U’ bolt 20 - 25mm up from the
bottom of the post.
Fig 2 - illustrates incorrect fitting!
Fix the ‘U’ bolts to the opposite double
20 - 25 mm
PARALLEL
Single Pivot
End
‘U’ Bolt
Load Support
Fig 1
Incorrectly
fitted
NOT PARALLEL
Fig 2
Forother makes of cattle crate- brackets may
have to be fabricated to suit utilising the ‘U’
bolt locations on the load supports.
It is recommended that you do not weld
directly onto the weigh platform!
pivotting end, again ensuring the load
supports and the cage floor are parallel.
7
Fitting the Spring Balance Head
If the weigh head is supplied separately
or has been removed, attach the weigh
head using the hook bolt provided.
Next attach the lower end of the weigh
head to the link bar using the bolt
provided.
Adjust the top nut of the
hookbolt till the cam rests
at the 11 o’clock
position in the foot
pedal catch, Fig 4.
Emptythe contentsof
the oil bottle into the
dash pot of the
weigh head.
To zero:-
To zero the scale,
ensure the column
carrying the weigh head is
in the vertical position, and
that the crate is empty. Depress
the foot pedal and hold the pedal in
the down position and turn the tare
screw to zero the needle pointer.
Hook Bolt
Tare Screw
Dash Pot
Link Bar
Handle
with oil bottle in
transit location Fig 3 Fig 4 Foot Pedal
Cam
See page 10 for Electronic weigh head instructions.
8
Operating Instructions
Fig 5
To operate:-
Do not have any auxiliary hurdles or gates
attached directly to the crate as this will
provide inaccurate readings. If hurdles are to
beused attach them to the two verticalposts
supplied with the weigh platform, Fig 5.
If using a Ritchie model 300g cattle crate it
will be necessary to shorten these posts to
10mm above the hurdle lug as shown, Fig 6.
Ensure the column carrying the weigh head
is in the vertical position.
Allow the animal to enter the handling crate
and settle.
To weigh, depress the foot pedal and hold
thepedal in the down positionwhen reading
the weight.
When weighing an animal is complete,
remove your foot from the foot pedal. When
the animal is released from the handling
crate, the cam will return to the ‘locked’
position on the foot pedal mechanism.
Togain access viathe sidedoors of theRitchie
Cattle Handling Crates, pull the handle on
the upright column towards you and pivot
the column to either the left or right side to
suit, Fig 5.
Important - No weighing can take place
whilst the column is in a pivoted position.
Fig 6
10 mm
Attach
Hurdles
to Post
9
All bearings are sealed and do not require
grease. However nipples are provided and
grease can be applied at your discretion,
Fig 7 (circled).
Whilst in use, periodic greasing of the cam
and light oiling of the pedal pivot is
recommended, Fig 8, (circled).
Maintenance
Fig 7
Fig 8
10
Electronic Weigh Head LS300
The LS300, with its specially designed animal
averagingsoftware,hasbeendesignedtogive
a quick and easy method for obtaining an
accurate weight of a live animal, even if the
animal is moving around.
The indicator comes as standard with an
inbuilt rechargeable battery and a back-lit
displayto allow you to useit in poorly lit areas
andwheremains power maynotbe available.
Installation
Unpack the indicator and components from
the box.
Charge the indicator as instructed opposite.
Fig 9
When the indicator is fully charged, attach it
to the load cell assembly with the knobs
provided.
Connect the load cell cable to the left hand
socket on the underside of the indicator and
switch on the unit.
Recharging the indicator
Disconnectthe load cellcable and removethe
indicator from the load cell assembly.
Attach one end of the charger unit to the
centresocketontheundersideoftheindicator
andtheotherendto a power socket(indoors).
It will take around 12 hours to fully charge
the battery.
Load Cell Cable Power Socket
