Riso ComColor FT Series Manuel utilisateur
RISO ComColor
New FT Series
Getting Started Guide
Making Copies
RISO UK Ltd
2] A4 / A3 Producing a Copy
3] Enlarging A4 to A3
4] Reducing A3 to A4
5] Producing Double Sided (Duplex) Copies
6] Image Repeat
7] Combine
8] Stapling (Optional Finisher Unit required)
9] Other Useful Functions
10] Operational Panel Layout
Contents
Please Note
This publication is intended as a brief introduction to the basic Copy Mode functions
of the RISO ComColor FT Series printer.
For full instructions please refer to the user guides supplied with the machine.
Load the original(s) in the ADF of the FT Series
scanner in the following orientation:
The “Copy Mode” panel will now appear:
1). The “Color Mode” should be set to “Auto”
This can be changed to “Black” if you want to convert
colour documents to black and white
2). “Feed Tray” should be set to “Auto”
In this setting the output paper size will be matched to
your original size.
A
C
B
2
A4 / A3 Producing a Copy
Select number of copies required.
1). Press blue “Start” button
2). Press red “Pause” button to pause job if
required
D
A4 A3
Select “Copy” Mode
Please note login may be required.
Note: The RISO FT5000 can not print a full A3 size as it has a maximum print width of 210mm.
The “Copy Mode” panel will now appear:
1). The “Color Mode” should be set to “Auto”
This can be changed to “Black” if you want to convert
colour documents to black and white
2). Select “Reproduction Size”
3). Choose: “Enlarge”
141% A4 - > A3
4). Select OK
3
Enlarging A4 to A3
Load the A4 original(s) in the ADF of the
FT Series scanner:
A
C
B
Select “Copy” Mode
Please note login may be required.
In the Copy Mode panel select “Paper Selection”
1). Ensure you select the feed tray containing
the A3 paper
2). Select OK and choose your number of copies
and press Start
D
Note: The RISO FT5000 can not print a full A3 size as it has a maximum print width of 210mm.
4
Reducing A3 to A4
The “Copy Mode” panel will now appear:
1). The “Color Mode” should be set to “Auto”
This can be changed to “Black” if you want to convert
colour documents to black and white
2). Select “Reproduction Size”
3). Choose: “Reduce”
71% A3 - > A4
4). Select OK
Load the A3 original(s) in the ADF of the
FT Series scanner in the following orientation:
A
C
B
Select “Copy” Mode
Please note login may be required.
In the Copy Mode panel select “Paper Selection”
1). Ensure you select the feed tray containing
the A4 paper
2). Select OK and choose your number of copies
and press Start
D
2). For duplex originals and/or copies specify how
the pages are turned in “Paging Direction”
A). B).
3). Select OK and choose your number of copies
copies and press Start
Duplex or Double Sided Copies
Firstly complete sections A to C as shown
on page 2
1) Select the “Duplex / Simplex” panel
The “Duplex / Simplex” panel will appear:
1). Select one of the following options:
Simplex / Simplex
- Single sided originals to single sided copies
Simplex / Duplex
- Single sided originals to double sided copies
Duplex / Duplex
- Double sided originals to double sided copies
Duplex / Simplex.
- Double sided originals to single sided copies
A
B
5
Firstly complete sections A to C as shown
on page 2
1) Select “Image Repeat” Tab
A
B
2). Specify how many of the same images to be
placed on one sheet:
Select 2, 4, or 8 images per sheet
3). Select OK and choose your number of
copies and press Start
Image Repeat (Same Image Multi-up)
6
Original data
Image Repeat
Combine (Dierent Image Multi-up)
7
Firstly complete sections A to C as shown
on page 2
1) Select “Image Repeat” Tab
A
B
2). Specify how many of the same images to be
placed on one sheet:
Select 2, 4, or 8 images per sheet
3). Select OK and choose your number of
copies and press Start
Original data
in page number
order
1
12
12
34
21
7
6
5
4
3
8
Firstly complete sections A to C as shown
on page 2
1) Select “Staple / Punch”
A
B
In the “Staple / Punch” section:
2). With “Binding Edge” select side of sheet(s)
to be stapled.
Choose Left, Right or Upper
3). In “Staple” select stapling option:
Choose 1 Position (Corner) or 2 Position” (Side)
4). Select OK and choose your number of
copies and press Start
Stapling (Optional nishing unit required)
1 Position
2 Position
8
9
Firstly complete sections A to C as shown
on page 2
1) Select “Booklet”
A
B
In the “Booklet” section:
2). With “Layout Order” select required page
number direction / Orientation
See “Layout Order” diagram below
3). In “Binding” select required option:
Choose “O”, “Fold and Staple” or “Fold”
4). Select OK and choose your number of
copies and press Start
Booklet (Optional nishing unit required)
LAYOUT ORDER
