Risco WiComm Pro Manuel d'instructions

Page 1

WiComm Pro Quick User Guide

This guide describes the main user operations of the various system accessories. For

detailed instructions, refer to the full user manual at our website: www.riscogroup.com

NOTES:

1. For additional information, refer to the instructions packaged with each device.

2. The SMS commands text is not case sensitive. A separator between command

words is not required although it is accepted.

“Away” (Full) Arming

 Quick mode: Press .

 High security mode: Press ,

then enter code or use proximity

tag.

Press

 Quick mode: Press .

 High security mode: Press ,

then enter code.

[Web application]: Click Full

Arm.

[Smartphone app]: Press .

[SMS]: Enter code + A

Example: 1234A

“Stay” or “Home” (Partial) Arming

 Quick mode: Press .

 High security mode: Press ,

then enter code or use proximity

tag.

Press

 Quick mode: Press .

 High security mode: Press ,

then enter code.

[Web application]: Click Part

Arm.

[Smartphone app]: Press .

[SMS]: Enter code + H

Example: 1234

Page 2

Partition Arming

 Quick mode: Press partition

number (1–3), then press Full

arming ( ) or Partial arming

().

 High security mode: Press

partition number (1–3), press Full

arming ( ) or Partial arming

(), then enter code or use

proximity tag.

 Quick mode: Press partition number

(1–3), then press Away arming

() or Stay arming ( ).

 High security mode: Press partition

number (1–3), press Away arming

() or Stay arming ( ), then

enter code.

[Smartphone app]: Partition arming

(Away and Stay) via Smartphone app.

[SMS]: Code +A or H + Partition No.

Quick Zone Bypass

Press and enter code > At

Activities menu press > at

Bypass Zone press > Scroll to

zone to bypass > For each zone define

Y/N using > Press to save

[Smartphone app]: Quick zone bypass

via Smartphone app.

[SMS]: Enter Code + B + Zone number

Full System Disarming

Press then enter code or use

proximity tag.

Press

 Quick mode: Press .

 High security mode: Press ,

then enter code.

Web Application]: Enter user

code, then click Disarm.

[Smartphone app]: Press .

[SMS]: Enter code + D

Partition Disarming

Press partition no. (1–3), press .

Enter code or use proximity tag.

Press (for all assigned

partitions)

 Quick mode: Press partition

number (1–3), then press .

 High security mode: Press

partition number (1–3), press ,

enter code

[Smartphone app]: Partition

disarming via Smartphone app.

[SMS]: Code + D + Partition

number

Page 3

View System Status

Press for 2 seconds and then

view status on the LCD display

[Smartphone app]: View system

status via Smartphone app.

[SMS]: Code + ST

View Last Alarm

Press for two seconds.

[Smartphone app]: View last

alarm from Event log via [SMS]:

Code + AL

Police (Panic) Alarm

Press and simultaneously

for 2 seconds

Press and

simultaneously.

Press small button (if installer

defined)

Fire Alarm Emergency/Medical Alarm

Press and simultaneously

for 2 seconds.

Press and simultaneously

for 2 seconds

System Chime On/Off Main Panel Speaker Volume

Press for 2 seconds

Press for 2 seconds. Select

volume level from 0—4 (no sound

to full volume), and then

press .

Page 4

Keypad Settings (Contrast, Brightness,

Buzzer Volume)

Changing Keypad Language

Press for 2 seconds.

Use the keys to choose

from menu,

press to select, then use

keys to adjust the keypad's

parameters and press

Press simultaneously for 2

seconds. Select the language and

press to confirm

Sound Indicators

Intrusion alarm: Continuous, rapid beeping.

Fire alarm: Staggered, rapid beeping.

Exit delay: Slow buzzer beeps until the Exit Delay time period expires.

Entry delay: Slow buzzer beeps until the Entry Delay time period expires.

Confirm operation: 1-second tone.

Reject operation: Three rapid error beeps.

Arm/Disarm chirp:

1 siren chirp = system armed

2 siren chirps = system is disarmed

4 siren chirps = system disarmed after an alarm

Page 5

Main Panel Indication LEDs

Power LED

Color State Status

Green ON Power OK

Red ON AC trouble

Orange ON Battery trouble.

Status LED

Red

ON System armed

(Away or Stay)

Rapid flash Alarm

Slow flash System is in

entry/exit delay

Green ON System ready

Slow flash

System in Exit

delay with front

door open

Orange

ON System Trouble

Off System not ready

for arming

Communication LED

Green ON GSM/IP OK

Slow flash Cloud connected

Orange Slow flash GSM/IP Trouble

Orange Slow flash

Battery

Replacement

mode (service

mode)

All LEDs Green Sequence flash

Wireless Learn

mode

Page 6

Wireless Panda Keypad LED Indicators

Cloud LED

On: System connected to cloud.

Slow Flash: Cloud connectivity

trouble.

Off: No cloud connectivity

Arm/Alarm LED

On: System armed (Away or

Stay).

Rapid Flash: Alarm.

Slow Flash: System in Exit /

Enty Delay.

Off: Disarmed

Ready LED

On: System ready.

Off: Open zones.

Slow Flash: Ready to arm

with open entry/exit zone.

Trouble LED

On: Trouble in the system.

Off: System is operating

normally.

Tamper LED

On: Tamper in the system.

Off: No tamper in the system.

Stay LED (Red)

On: System partially (Stay)

armed or bypass zones.

Off: No bypass zones.

Assign and Edit Users (User Codes) Assign Proximity Tag

1. Press and enter code.

2. Scroll to Codes/Tags, then press .

3. Scroll to User Codes, then press .

4. Scroll to New/Change, then press .

5. Scroll to select the index number (to designate

to a system user), then press .

6. Enter (or re-enter) the new code.

7. Re-enter the new code; the system beeps and

“Accepted” displays.

8. Repeat the above steps for additional codes.

1. Press and enter code.

2. Scroll to Codes/Tags, then press .

3. Scroll to Proximity Tags, then press .

4. Scroll to New/Change, then press .

5. Scroll to select the index number (to

designate to a proximity tag user), then

press .

6. Within 10 seconds, hold the proximity tag

at 1–2 cm from the keypad's top right

corner; a long beep indicates the tag has

been registered.

NOTE: If the tag was already registered, 3

beeps will sound, and a message will

display.

Page 7

Registering to the RISCO Cloud

1 . Go to www.riscocloud.com/register

2 . Fill in your first and last name.

3 . Enter your e-mail address as the Login Name (required for 1st-time activation).

4 . Define password (minimum of 6 characters and at least one digit), and then confirm.

5 . Enter the 15 digits Panel ID as it appears on the sticker located on the side of the panel (or as

printed on the package of the main panel).

6 . Complete registration form, and then press Register.

7 . Open the e-mail received at the email account you had defined as the Login Name in step 3,

and click the link to activate your registration to the Cloud.

Logging in to the RISCO Cloud / Accessing the Web User Application

1 . Go to www.riscocloud.com. Enter your User Login Name and password (as defined during

the registration process).

2 . Enter the passcode (user code), and click Enter.

iRISCO Smartphone App

Download the iRISCO Smartphone app from the Apple App store or the Android Play Store.

Page 8

02/2018 5IN2485
